INSTRUCTION MANUAL
Rotary Hammer
HR4001C
HR4010C
HR4011C
006305
DOUBLE INSULATION
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
1

Advertisement

loading

  Summary of Contents for Makita HR4001C

  • Page 1 INSTRUCTION MANUAL Rotary Hammer HR4001C HR4010C HR4011C 006305 DOUBLE INSULATION WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
  • Page 2: Specifications

    ENGLISH SPECIFICATIONS Model HR4001C HR4010C HR4011C Carbide-tipped bit 40 mm Capacities Core bit 105 mm No load speed (min 235 - 480 Blows per minute 1,350 - 2,750 Overall length 468 mm Net weight 6.3 kg 6.7 kg 6.7 kg Safety class •...
  • Page 3: Specific Safety Rules

    Do not abuse the cord. Never use the cord for 18. Do not use the power tool if the switch does carrying, pulling or unplugging the power tool. not turn it on and off. Any power tool that cannot Keep cord away from heat, oil, sharp edges or be controlled with the switch is dangerous and moving parts.
  • Page 4: Functional Description

    Do not leave the tool running. Operate the tool the switch trigger to stop. only when hand-held. FOR MODELS HR4010C/ HR4001C 12. Do not point the tool at any one in the area Trigger switch when operating. The bit could fly out and injure someone seriously.
  • Page 5: Speed Change

    5 and back to 1. Do not force it past 5 or 1, or chisel, scaling chisel, etc. the speed adjusting function may no longer work. For long time hammering (FOR MODELS HR4001C AND HR4010C ONLY) 1. Change lever 2.
  • Page 6: Side Handle

    For chipping, scaling or demolition operations, depress The green power-ON indicator lamp lights up when the the lock button and rotate the change lever so that the tool is plugged. If the indicator lamp does not light up, pointer points to the symbol.
  • Page 7 Bit angle (when chipping, scaling or demolishing) CAUTION: Always use the side grip to ensure operating safety 1. Change lever • HR4001C 2. Pointer when drilling in concrete, masonry, etc. HR4010C 3. Lock button The side grip swings around to either side, allowing easy handling of the tool in any position.
  • Page 8: Operation

    1. Pointer CAUTION: HR4011C 2. Change lever When the bit begins to break through concrete or if 3. Lock button • the bit strikes reinforcing rods embedded in concrete, the tool may react dangerously. Maintain good balance and safe footing while holding the tool firmly with both hands to prevent dangerous reaction.
  • Page 9 Wipe out the old grease inside and replace with a fresh and unplug the tool. grease (60 g). Use only Makita genuine hammer grease Loosen the four screws and remove the handle. Note (optional accessory). Filling with more than the specified that the top screws are different from other screws.
  • Page 10 Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. SDS-Max Carbide-tipped bits • SDS-Max bull point • SDS-MAX cold chisel •...
  • Page 12 Makita Corporation 884611A7...
