Owner's Manual
Phoenix
Model (8612)
Woodstove
OWNER'S MANUAL
INSTALLATION
AND
OPERATING INSTRUCTIONS
PLEASE READ THIS ENTIRE OWNER'S MANUAL BEFORE YOU INSTALL, AND USE,
YOUR NEW PHOENIX WOOD STOVE. To reduce the risk of fire, follow the installation
instructions. Failure to follow these instructions may result in property damage,
bodily injury, or even death.
CONTACT LOCAL AUTHORITIES HAVING JURISDICTION (BUILDING
DEPARTMENT or FIRE OFFICIALS) ABOUT PERMITS REQUIRED,
RESTRICTIONS AND INSTALLATION INSPECTION IN YOUR AREA.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!
Phoenix Model 8612
Manual # 6400-40413A
R: 5 - 3/13/2012
Advertisement
Table of Contents
Troubleshooting
Related Manuals for HearthStone Phoenix 8612
Summary of Contents for HearthStone Phoenix 8612
- Page 1 Phoenix Model (8612) Woodstove OWNER'S MANUAL INSTALLATION OPERATING INSTRUCTIONS PLEASE READ THIS ENTIRE OWNER’S MANUAL BEFORE YOU INSTALL, AND USE, YOUR NEW PHOENIX WOOD STOVE. To reduce the risk of fire, follow the installation instructions. Failure to follow these instructions may result in property damage, bodily injury, or even death.
- Page 2 Phoenix Model 8612 Intentionally Blank Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com...
-
Page 3: Table Of Contents
................................22 ASKETS ................................22 LASS ................................23 TROUBLESHOOTING ......................24 ..........................25 ROUBLESHOOTING UIDE REPLACEMENT PARTS & OPTIONAL ACCESSORIES ............ 26 SAFETY LABEL ........................27 Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 4: Introduction
2.4 grams per hour particulates other combustibles far away from the stove. Never emission, you can be proud to join the Hearthstone install the stove in a location where gasoline, family with our Phoenix Cast & Stone Wood kerosene, charcoal lighter fluid or other flammable Burning Stove. -
Page 5: Safety & Good Practices
Be sure the removable ash lip is in place while good indicator is when ashes reach the openings using the stove. If the ash lip is not installed in the “dog house”, or lower primary air inlet. Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 6: Emergency Procedures
Gaskets). Check hinge screws for tightness. To enhance the combustion efficiency and reduce the At the End of Every Season: emissions of the fire in your stove, Hearthstone has Dismantle the chimney connector and clean it developed a THERMO-CERAMIC baffle system. This thoroughly. -
Page 7: Specifications
Polished gray soapstone is a natural product and will vary from stone to stone. Various amounts of gray, charcoal, blue and green are usually evident, and vary according to the natural composition of the stone. Figure 1 – Phoenix 8612 Dimensions Hearthstone Quality Home Heating Products, Inc ®... -
Page 8: Installation
If you use a close clearance connector pipe, it must be NPACKING listed, and tested to UL standards. Check the listing of Hearthstone packages your Phoenix stove with the your pipe for actual clearances. The diagrams in this greatest care, so that it ships safely. Under certain... - Page 9 Contact your avoid structural members of the house. dealer for availability). outside air kit will attach to the bottom of the stove. Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com...
-
Page 10: Clearances T O Combustibles
* The National Fire Protection Agency has recommended minimum clearances non-combustible surfaces. when installing it into a mobile home. Following are two examples of NFPA 211 non-combustible walls. To make a wall non-combustible, protected it with a Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... - Page 11 C: Back wall to pipe: 5” (13 cm) D: Top of stove to ceiling: 36” (91 cm) The minimum alcove size: Height: 64” (163 cm) Width: 40” (102 cm) Max. Depth: 48” (122 cm) Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com...
- Page 12 5” (127 mm). For flooring, the floor protector’s minimum area must be under the chimney connector and 2” (50 mm) beyond each side. 1. 24 gauge, single wall pipe to wall = 18” (457 mm). 2. Close clearance pipe to wall = 5” (127 mm). Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com...
-
Page 13: Venting Components & Configuration
Both these components become extremely hot during three sheet metal screws. Failure to properly secure use. Temperatures inside the chimney may exceed Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 14: Connecting Your Wood Stove
WARNING: DO NOT CONNECT THE STOVE TO A Make sure the chimney’s cleanout is complete and CHIMNEY FLUE SERVING ANOTHER APPLIANCE. working properly. To avoid a loss of draft, ensure the cleanout closes tightly. Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... - Page 15 (4 m). The maximum allowable chimney height liner system meeting type HT requirements or is 30 feet (9m). other approved material. Interior chimney requirements: Figure 3 – Chimney Height Requirements Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com...
- Page 16 C h im n e y is s u p p o r te d b y T e e S u p p o rt B r a c k e t. C h im n e y is s u p p o r te d b y C e ilin g . Figure 4 – Typical Venting Options Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com...
-
Page 17: Installation I N A Mobile Home
INTEGRITY OF THE MOBILE HOME WALLS, FLOOR, CEILING, AND ROOF WHILE YOUR STOVE IS INSTALLED, AND IN USE. WARNING: DISCONNECT CHIMNEY BEFORE TRANSPORTING MOBILE HOME! Typical Mobile Home Installation. Chimney is supported by Ceiling. Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 18: Operation
IREWOOD Juniper, Rocky Mtn 3,150 21.8 Elm, Red 3,112 21.6 Burn only natural firewood (known as cordwood) in the Phoenix 8612 Woodstove. This stove is not Coffeetree, Kentucky 3.112 21.6 designed, or certified to burn other fuels. Hackberry 3,247 20.8... -
Page 19: Buildinga Fire
As for Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 20: Buildinga Break I N Fire
This will fully uncover the primary air temperatures present during break-in shutter. A high burn rate is recommended once or procedure, creosote may build up rapidly. Your Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 21: Over -Fire Caution
If you suspect that your stove is over- firing, contact your dealer immediately. Damage done by over-firing is not covered by your warranty. Results of over-firing can include: warped or burned out internal parts, cracked stones, Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 22: Maintenance
When necessary, the glass can be cleaned with low If your glass remains dirty, your stove’s operating alkaline content commercial stove glass cleaners, temperatures are probably consistently lower than which are available from your local dealer. Never Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 23: Cast Iron
Remove the screws to separate the glass from the door. 4. Carefully lift the damaged glass from the door and discard. Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 24: Troubleshooting
Slightly opening a window in the same room as the This phenomenon of air starvation within the building stove during startup can help too. can be exacerbated if exhaust fans, such as clothes Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 25: Troubleshooting Guide
Do not over-fire the stove. Monitor stove temperatures. ENAMEL Use seasoned cordwood only. CASTING Excessive Draft Check the DRAFT. A damper may be required. Operate the stove at a LOW BURN range. Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 26: Replacement Parts & Optional Accessories
FRONT BAFFLE SUPPORT XX* - Specify finish color for enamel parts. Phoenix Model 8612 Woodstove Manufactured & Warranted by: Hearthstone Quality Home Heating Products, Inc. 317 Stafford Ave. Morrisville, VT 05661 Inquiry@hearthstonestoves.com www.hearthstonestoves.com Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... -
Page 27: Safety Label
Phoenix Model 8612 Safety Label Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com... - Page 28 Phoenix Model 8612 Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com...
- Page 29 Hearthstone Quality Home Heating Products, Inc. Warranty Department 317 Stafford Avenue Morrisville, VT 05661 NOTE: SENDING IN THE SIGNED WARRANTY REGISTRATION FORM IS NOT REQUIRED AS A CONDITION OF WARRANTY COVERAGE OR HEARTHSTONE’S PERFORMANCE. Hearthstone Quality Home Heating Products, Inc ® www.hearthstonestoves.com...
