3) Fix the sunshade cover
Fix the sunshade cover on the V-Screen with the tape as shown by the picture.

Using Power Adapter

To power by adapter, connect the DC Adapter to the DC Input on the back of
V-Screen.
Lithium Battery Installation
Insert lithium battery into the battery slot as shown below.
Note:
1. Lithium batteries should be purchased separately. You can use: Sony F970/F550/
NP-FM500H.
2. There's no need to remove the batteries when powered by adapter. DC power will
charge the batteries and battery power will be displayed in the top left corner of the screen.
AP-025
Monday, January 14, 2013 11:56:37 AM
6
Power Switch
Switch on the V-Screen by pressing the power switch. To power off,
hold the power switch for 2 seconds.
Note:
1. Power indicator lights red when connected with power.
2. Power indicator lights green when turned on.
3. A red battery indicator will blink on the screen when power is low. Replace
batteries immediately
Signal Input Switch
Press the < A/V> button to choose appropriate signal input mode. Ex: Switch to
HDMI mode to receive HDMI signal.
Supports HDMI Signal Output
V-Screen VS-2 not only supports HDMI signal input, but also has a unique HDMI
output function.
Enter Sleep Mode
Enters sleep mode after 30 seconds when there is no signal. Awake unit by
pressing any button except power switch.
4. Function and Operation
1. Before setting functions, make sure device is connected correctly.
2. Before entering the menu, the Direction Pad has several default functions:
< / > = brightness adjustment; < / > = contrast adjustment.
Note:
Refer to P9 to set shortcuts as needed.
3. Press <M> on the V-Screen to enter the menu. Press <
the main menu, including display, menu, function, and shortcut settings. Then
press < > to enter sub-menu. Press <
< / > to adjust parameters. Press <M> to confirm and return to the main menu.
Press once more to exit the menu.
7
/ > to choose from
/ > to navigate the sub-menu, and
