Elicom Electronic Ltd.
Electronic Scales
E V L
Models T and M
User's Manual
plus

Table of Contents

1.
Warranty card .......................... 3
2.
Brief description ...................... 5
3.
Main functions ......................... 5
4.
Technical data.......................... 5
5.
Scale Overview ........................ 6
6.
Preparing for use ..................... 7
7.
8.
Operation modes ..................... 8
8.1. Weighting Mode............... 9
8.2. Counting Mode .............. 19
Mode .............................. 20
8.4. Service Mode ................. 22
devices........................... 30
8.6. Error Mode..................... 31
9.
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVLplus T and is the answer not in the manual?

Questions and answers

Related Manuals for Elicom Electronic EVLplus T

Summary of Contents for Elicom Electronic EVLplus T

  • Page 1: Table Of Contents

    Table of Contents Page Warranty card ......3 Elicom Electronic Ltd. Brief description ...... 5 Main functions ......5 Electronic Scales Technical data......5 Scale Overview ......6 Preparing for use ..... 7 E V L plus Installation instructions... 8 Operation modes .....
  • Page 2 Scale Models Series EVLplus EVL+ xx LТ3 EVL+ xx LМ6 EVL+ xx BТ3 EVL+ xx BМ6...

  • Page 3: Warranty Card

    Elicom Electronic Ltd. 1. Warranty Card MODEL NAME: Electronic Scale ELVplus DATE OF PURCHASE………………………… SERIAL №………………………………… LIMITED WARRANTY The warranty period for the Electronic Scale is 12 months from the day of the purchase. To obtain and receive warranty service, you need to present the original Owner’s Manual along with Warranty Card in any authorized dealers and services.

  • Page 5: Brief Description

    Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 2. Brief Description The electronic scales from series EVLplus xx LM, LM, LT, BT, are precise measuring devices for determining the weight of goods in retail stores and warehouses. All scales from series ELVplus are designed to work in temperature range from -10°C to +40°C and to work without external power supply for up to 100 hours.

  • Page 6: Scale Overview

    Owner’s Manual Metal platter Size 300 х 250 mm 4.2. Technical data for all models Model Maximal Minimal Maximal Tare Value of the real Load Load check division e=d= EVL+ 3 3 kg 20 g minus 3 kg EVL+ 3/6 3/6 kg 20 g minus 6 kg...

  • Page 7: Preparing For Use

    Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 Base - plastic base with four adjustable legs Metal Platter - the measured loads are placed on top Plastic lid cover - covers the electronic unit and the load cell unit. It protects the keyboard, operator’s (8) and customer’s (7) display.

  • Page 8: Installation Instructions

    Owner’s Manual 7. Installation Instructions Open the box and pull out the contents, including: Scale Metal platter AC adaptor Operation Manual Passport Warranty card Installation of the metal platter – place the tray legs in the corresponding holes on the upper side of the scale.

  • Page 9: Weighting Mode

    Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 Model: LM, BM 8.1. WEIGHING Mode Place the load and wait till the scale stands still or until the indication for total price or the load indication blinks repeatedly. 8.1.1 Keyboard keys ON/OFF –...
  • Page 10 Owner’s Manual Keyboard keys 00 , 0 , 1 , 2 , 3 , 4 , 5 , 6 , 7 , 8 , 9 , C .are used in the Weighing mode for entering article prices. Wrong figures are deleted by pressing the C button and the price setting starts from the beginning.
  • Page 11 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 ____ If the price is wrong it can be deleted it by Remove the load from the platter – in the Price per kg field remains the last price entered. pressing the key.
  • Page 12 Owner’s Manual N E T Т If there is a previously set Tare for PLU 3. The After the load is removed the Tare is shown with Tare will be deducted from the load and only a negative sign and the “T” symbol is shown in the net weight will be indicated.
  • Page 13 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 N E T Т Enter price per kg of 3.00 (Example) and After the pot is removed the scale shows the remove the pot. weight of the Tare with a negative sign and the „Т”...
  • Page 14 Owner’s Manual Т Т key is also used to clear the Tare value. To clear the Tare, the scale must be unloaded. Note 1: The following steps are performed for accumulating of the Tare value: Set the Tare and place the first product as described above. Press the key, the scale shows the current Tare.
  • Page 15 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 -Р- __ _ ___ __   To add a number of fixed price articles to the Enter the price by pressing the 2 , 5 keys. customer’s bill (For example: 6 onions by 0.25 Press the to add the sale to the customer’s each).
  • Page 16 Owner’s Manual -Р-   With the are reviewed all of the sales recorded in the client’s bill. -Р- totAL   To go back to “Weighing Mode” press the “C” or “CP” keys. 8.1.5.3 To delete a particular sale, choose the desired sale by pressing .To delete press the MC key two times.
  • Page 17 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 To delete sale #1: -Р-   After the delete is shown the next sale in the Use the MС and MС keys to delete a sale. client’s bill. The total number of sales is now 1. 8.1.5.4.
  • Page 18 Owner’s Manual 8.1.6.1. When sale is completed, press the MR to go to the “Register of Sales”. The first screen shows the totals: weight and turnover of all clients’ bills. To go back to WEIGHING MODE use the C or CP keys °...

  • Page 19: Counting Mode

    Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 8.2. COUNTING Mode 8.2.1 Activating from Service mode 2. Press PRG, DW after that press the PRG key rapidly till the “cnt 0” is shown on the display. By pressing the C key from the numeric keyboard change the blinking „0”...

  • Page 20: Labeling And Pre-Labeling Mode

    Owner’s Manual Place the desired number of details. On the “Total Price” is displayed the number of the details blinking text „count”. 8.2.4 Work without PLU Perform the following steps Turn on the scale, after all tests are performed double click the „СР” key. As a result on the middle line of the display is shown „0”, on the weight line is shown „0.000”...
  • Page 21 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 Place a load of 200g or more and press PRN to print a test label Choose a number of the article (PLU), which will be weighed By using the numerical keyboard, enter the desired article number: For example: 85 followed by the PLU key.

  • Page 22: Service Mode

    Owner’s Manual In Service mode 1 are set prices and tare of the articles, battery condition, parameters for work with the scale. In Service Mode 2 is changed the presence of the decimal point and parameters for label print and other parameter for activation/deactivation on different functions of the scale.
  • Page 23 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 ____.__ The first mode is „Programming of price and tare” PRG , PRG - switching to programming of – described in detail in p.8.4.3. articles (in detail p. 8.4.3). This function is available only for price computing scales CALIb _ __...
  • Page 24 Owner’s Manual PRG - AUTO OFF – by using the numerical - software version keyboard is set time after which the scale automatically turns off. When turning the scale on after AUTO OFF, no initial test is preformed CALIb ___.__ - Au0-0 –...
  • Page 25 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 - Parameter for work with Scanner – Parameter for work with scanner By pressing PRG the scale is going back to “WEIGHING Mode” From each function of the Service Mode you can switch to “WEIGHING Mode” by pressing CP .
  • Page 26 Owner’s Manual Е nr – Setting-up the clock for real time. Use PRG - Counter number PRG set of the date and the time °nbr nbr PRG - Operator’s number - Logical number of the scale in LAN network rint no uto PRG - Enable/Disable automatic print of labels PRG –...
  • Page 27 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 cLiEnt ____.__ ____.__ PRG – Enable/Disable function CLIENT’S BILL PRG - party number 1 – To change use C . ____.__ ____.__ PRG - party number 2 PRG - party number 3 * The access to the parties numbers can be obtained in WEIGHING Mode with unloaded scale by pressing PRG followed by the PRN.
  • Page 28 Owner’s Manual ____.__ ____.__ PRG – switching between article by number PRG - going back to WIGHING Mode PLU (PLU1) or article by article’s number (Art1) – to change use C . For in detail description how to use PRE-LEBALING function, see p.8.3.4; For COUNTING FUNCTION, see p.
  • Page 29 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 1 , 2 , 1 - switch to article № 121 by – To confirm the entered number. As a entering the 3 digits! result is shown the set price and tare of the article PLU121 and the price is blinking Enter the desired price.

  • Page 30: Connecting With External Devices

    Owner’s Manual If battery is Low, the following message is PRG , PRG , PRG – battery status. If the displayed: “batLO” adapter is connected to the scale the sign „ – „ is changing consecutively: - =  - showing that the battery is charging After the message “batLO”, the display is turning off automatically.

  • Page 31: Error Mode

    Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 [baud] digit 4800 Electronica 1200 КА ORGTECHNICA 2400 КА Еlka 752, Datecs 4800 КА Karat, Deisy, Bimco scales 9600 КА Eltrade Protocol with continuous 19200 dispatching of the weight 38400 Connection with PC, PRN 4800 Scales Angel, CAS, DIBAL...

  • Page 32: Еo Declaration Of Conformity

    9. EO Declaration of conformity Declaration of conformity A non-automatic weighing instrument class: Manufacturer: Elicom electronic Ltd, Bulgaria, Silistra 7500, Saedinenie sq. Type/Model: EVLplus xx-xx-x-x-x Serial Number: NB1799 T051 № of the EC type-approval certificate Corresponds to the production model described in the EC type-approval certificate and tо...
  • Page 33 Electronic Scale – models EVLplus хх LМ1, BM1, LT1, BT1 HEAD OFFICE 7500 Silistra, Bulgaria 5, Saidinenie sq. PO Box 188 Tel.: +359/ 86 /820 200, 882 255 Fax: +359/ 86 /820 555 e-mail: info@elicom-bg.com OFFICE AND SERVICE 1784 Sofia, Bulgaria 131, Tsarigradsko shosse, "ATM Center", fl.
