Table of Contents

Our compliments for having chosen a top-quality Immergas product, able to assure well-being and safety for a long period of time. As an Immergas customer

you can also count on a qualified after-sales service, prepared and updated to guarantee constant efficiency of your boiler. Read the following pages carefully: you

will be able to draw useful suggestions regarding the correct use of the appliance, the respect of which, will confirm your satisfaction for the Immergas product.

Contact our area authorised after-sales centre as soon as possible to request commissioning. Our technician will verify the correct functioning conditions; he

will perform the necessary calibrations and will demonstrate the correct use of the generator.

For any interventions or routine maintenance contact Immergas Authorised Centres: these have original spare parts and boast of specific preparation directly

from the manufacturer.

The instruction book is an integral and essential part of the product and must be consigned to the new user also in the case of transfer or succession of ownership.

It must be kept well and consulted carefully, as all of the warnings supply important indications for safety in the installation, use and maintenance stages.

In compliance with legislation in force, the systems must be designed by qualified professionals, within the dimensional limits established by the Law. Installation

and maintenance must be performed in compliance with the regulations in force, according to the manufacturer's instructions and by professionally qualified

staff, intending staff with specific technical skills in the plant sector, as envisioned by the Law.

Incorrect installation can cause injury to persons and animals and damage to objects, for which the manufacturer is not liable. Maintenance must be carried

out by skilled technical staff. The Immergas Authorised After-sales Service represents a guarantee of qualifications and professionalism.

The appliance must only be destined for the use for which it has been expressly declared. Any other use will be considered improper and therefore potentially

dangerous. If errors occur during installation, running and maintenance, due to the non compliance of technical laws in force, standards or instructions

contained in this book (or however supplied by the manufacturer), the manufacturer is excluded from any contractual and extra-contractual liability for any

damages and the appliance warranty is invalidated. For further information regarding legislative and statutory provisions relative to the installation of gas

heat generators, consult the Immergas site at the following address: www.immergas.com

For the purpose and effect of the CE 2009/142 Gas Appliance Directive, EMC 2004/108/CE Directive, 92/42/CE Boiler Efficiency Directives and

2006/95/CE Low Voltage Directive.

The Manufacturer: Immergas S.p.A. v. Cisa Ligure n° 95 42041 Brescello (RE)

DECLARES THAT: the Immergas boiler model:

Victrix 26 2 I

is in compliance with the same European Community Directives

INDEX

INSTALLER

Boiler installation ...................................... 4

1.1 Installation recommendations. ................ 4

1.2

Main dimensions. ..................................... 4

1.3 Anti-freeze protection. ............................. 5

1.4 Connections. .............................................. 5

1.5 Remote controls and room chrono-

thermostats (Optional). ............................ 6

1.6 External probe (Optional). ...................... 7

1.7

Immergas flue systems. ............................ 7

1.8 Outdoor installation in partially protected

area. ............................................................. 7

1.9 Indoor installation. .................................10

1.10 Ducting of flues or technical

slots. ..........................................................12

1.11 Flue exhaust to

flue/chimney. ...........................................12

1.12 Flues, chimneys and chimney caps. ......12

1.13 System filling. ...........................................12

1.14 Filling of the

condensate trap. .......................................12

1.15 Gas system start-up. ................................12

1.16 Boiler start up (ignition). .......................13

1.17 Circulation pump. ...................................13

1.18 Kits available on request. ........................13

1.19 Boiler components. .................................14

Immergas S.p.A. declines all liability due to printing or transcription errors, reserving the right to make any modifications to its technical and commercial

documents without forewarning.

Dear Client,

General recommendations

DECLARATION OF CONFORMITY

page

USER

Instructions for use and maintenance. .15

2.1 Cleaning and maintenance. ...................15

2.2 General warnings. ...................................15

2.3 Control panel. ..........................................15

2.4 Using the boiler........................................15

2.5 Troubleshooting. .....................................16
