1 0G7908A 1 ASSY, CRANKCASE WITH SLEEVE
2 0E9843A 1 SEAL, 38 I.D. CRANKSHAFT GREEN
3 0G0919 5 SCREW, HHFCS M6-1.0 X 12 G8.8
4 0G9100 1 ASSEMBLY, BREATHER DUAL BREATHER
5 0C3005 1 GASKET, BREATHER COVER
6 0E3372C 2 SEPARATOR, OIL BREATHER
7 0H1760A 1 ASSY,HEAD #1
8 071983 4 RETAINER, PISTON PIN 20
9 0C2981C 1 ROCKER, COVER NO OIL FILL
11 0K0988 2 PISTON, FLAT TOP DIA 90
12 0G2565 2 RING SET, PISTON DIA 90
13 0G7940 2 PIN, PISTON (20Kw)
14 0D4041 1 ASSY, CAMSHAFT & GEAR (13,14,16,17Kw)
0G7974 1 ASSY, CAMSHAFT & GEAR (20Kw)
15 0C2977 1 GASKET, CRANK CASE
16 0C5943 1 SEAL, OIL PASSAGE
17 0E4357E 1 ASSY, CRANK & GEAR (13,14,16,17Kw)
0G5001E 1 ASSY,C'SHAFT 0.D. 41 (20Kw)
18 0J8969 2 ASSY,CONNECTING ROD (13,14,16,17Kw)
0J8968 2 ASSY,CONNECTING ROD (20Kw)
19 0G6431 2 SCREW SHC SEMS M6-1.0 X 50 G8.8
20 0E6098 1 SCREEN, OIL PICKUP
21 0D4123B 1 ASSEMBLY, OIL PUMP W/O O-RING
22 0E8152 1 O-RING .49 ID X .07 THICK
23 0C3011 2 COVER, OIL RELIEF
24 0C3009 2 SPRING, OIL RELIEF
25 0C3010 2 BALL, 1/2D OIL RELIEF
27 0F5458 1 SCREW, PLASTITE HI-LOW #10
28 0C3027 1 O-RING, 3/8" X 1/2"
29 0C5998 1 CLAMP, OIL TUBE
31 0F2664L 1 ASSEMBLY, DIPSTICK WITH HANDLE
32 0C5305 1 TUBE, DIPSTICK
33 0D6147 5 SCREW HHFC M6-1.0 X 10mm
34 043790A 1 BARBED ELBOW 90 3/8NPT X 3/8 VS
35 0E9842A 1 SEAL, 42 I.D. CRANKSHAFT GREEN
36 0F8054 1 GEARCOVER / ADAPTOR GTH-990
37 0C3006 10 SCREW, HHFC M10-1.5 X 55
38 080318 8 SCREW HHFC M6-1.0 X 25
39 093064 1 ASSEMBLY, OIL FILL CAP
40 0K4867 2 LIFT HOOK
41 0D2723B 1 ROCKER, COVER WITH OIL FILL
42 0C2979 2 GASKET, VALVE COVER
43 086515 8 KEEPER, VALVE SPRING
44 0D2274 4 RETAINER, VALVE SPRING
45 0D3867 4 SPRING, VALVE
46 078672 2 SEAL, VALVE STEM D7
47 0C5371 4 WASHER, VALVE SPRING
48 072694 4 STUD, ROCKER ARM PIVOT
49 0D5313 4 ROCKER ARM
50 0D3998 4 NUT HEX M8-1.0 G8 YEL CHR
51 0G8552 2 PLATE, PUSH ROD GUIDE (20KW)
52 0C2976 12 SCREW HHFC M8-1.25 X 65
53 086516 2 VALVE, EXHAUST
54 0C2229 2 VALVE, INTAKE
55 083897 4 TAPPET, SOLID
56 0H1760B 1 ASSY, HEAD #2 (20Kw)
57 0D9853D 4 PUSHROD, 147
58 0C2978 2 GASKET, HEAD
59 0D4010 1 KIT GASKET
60 0D4012 1 KIT BREATHER ASSEMBLY
61 0D8675A 1 KIT HEAD ASSEMBLY CYLINDER 1
62 0D8675B 1 KIT HEAD ASSEMBLY CYLINDER 2
63 0D4015 1 KIT OIL RELIEF
64 078699C 2 SLEEVE DOWEL PIN 14 DIA.
65 078699B 4 SLEEVE DOWEL PIN 12 DIA.
158 0G8558 1 DIVERTER, BREATHER GTH
