Generac Power Systems Guardian 005240 Installation And Owner's Manual page 76

64 022145 1 WASHER FLAT M8 – 5/16
65 0C5136A 2 KNOB, AIR CLEANER (13,14,16,17Kw)
0C5136D 2 KNOB,AIR CLEANER (20Kw)
66 0C3024 1 COVER, AIRBOX NG/LP (13,14,16,17Kw)
0G5895 1 COVER, AIRBOX NG/LP (20Kw)
68 0C8127 1 ELEMENT, AIR CLEANER (13,14,16,17Kw)
0G5894 1 ELEMENT, AIR CLEANER (20Kw)
69 0F9255 1 ASSY, MIXER / AIRBOX 990 (13, 16Kw)
0G8297 1 ASSY, MIXER / AIRBOX 990 (14, 17 Kw)
0G8448 1 ASSY, MIXER / AIRBOX 999 (20Kw)
70 0E9582 4 SCREW SHLDR(8MM) M6-1.0 X 21
71 0D4417 4 WASHER,RUBBER 1/4" X 1/8" THICK
72 0E7585A 2 SPARKPLUG, RCY14 .040"GAP (13,14,16,17Kw)
0G0767A 2 SPARKPLUG, RC12 .040" GAP (20Kw)
73 0E6043 2 SCREW TAPTITE M5 – 0.8 X 8
74 0G7606 1 WRAPPER, LOWER CYLINDER 2 ZINC
75 0C3025 1 SWITCH, OIL PRESS
76 0F0452D 1 HOSE 3/8" 300PSI 6.5" LG OIL
77 070185E 1 OIL FILTER, 90mm
78 0D3083 1 ASSY, OIL DRAIN HOSE
79 0F2094 2 SCREW M3 – 0.5 X 6 SEMS
80 094090 1 SWITCH, THERMAL 293F
81 035461 2 BARBED STRAIGHT 1/4NPT X 3/8
82 0G3662B 5 CLAMP, HOSE OETIKER STEPLESS 18.5mm
83 0F0452C 1 HOSE 3/8" 300PSI 6" LG OIL
84 0E9506 1 COOLER, OIL
85 0C9764 4 SCREW PLASTITE 1/4-15 X 3/4
86 0C3043 2 GASKET, MANIFOLD / PORT
87 0C7694A 1 MANIFOLD CYLINDER 2
88 045756 4 SCREW, HHTT M6-1 x 10 LONG
89 082025 1 NUT, HEX LOCK M5-0.8 ZINC
90 0G3730 4 SCREW SHC M8 – 1.25 X 20 SEMS
91 090388 13 SCREW TAPTITE M6–1X12 CLEAR ZINC
92 0E4997 1 ASSY,GROUND WIRE CONNECTOR
93 0C3033 1 WASHER, 25MM I.D.
94 0C3034 1 NUT, HEX M24
95 0C9763 4 NUT, GROMMET 1/4 PLUG
96 0D1131 1 GUARD, FAN
97 0F1169K 1 HOUSING, BLOWER NG COOLER
98 0H4957 2 SCREW HHFCS M8 – 1.25 X 10 G8.8
100 0C3032 1 PLATE, FAN
101 0C3031 1 FAN, NYLON
102 0C3725B 1 ASSY, FLYWHEEL (13,14,16,17Kw)
0C3725D 1 ASSY, FLYWHEEL (20Kw)
103 0G4928C 1 PLATE, BACKING WITH CUT OUT
104 0C7693A 1 MANIFOLD CYLINDER 1
105 0C3041A 2 SLEEVE, RUBBER
106 082774 1 KEY, WOODRUFF 4 X 19D
107 0C3036A 1 HOSE BREATHER
108 0G7604 1 WRAPPER, LOWER CYLINDER 1 ZINC
109 0G7603 1 WRAPPER, UPPER CYLINDER 1 ZINC
110 0G7605 1 WRAPPER, UPPER CYLINDER 2 ZINC
111 0E9323 1 STARTER MOTOR HEAR REDUCED 1KW
112 061906 2 SCREW HHC M8 – 1.25 X 85 G8.8
113 022129 3 WASHER LOCK M8 – 5/16
114 0F1177 1 ASSEMBLY, GROUND WIRE
115 022097 2 WASHER LOCK M6 – 1/4
116 0G3110 4 SCREW TAPTITE M6 – 1.0 X 20 ZINC
117 0G3224A 1 ASSY, IGN COIL W/DIODE, CYLINDER 1
118 0G3224B 1 ASSY, IGN COIL W/DIODE, CYLINDER 2
119 0E9568 1 ASSY, THROTTLE SHAFT
120 0E9565 2 THROTTLE VALVE
121 074027 4 SCREW PPHM M3 – 0.5 X 5
122 0C3044 1 COVER, DUST, MIX/AIRBOX
123 0C4756 1 SPRING, IDLE ADJUST
124 075477 1 SCREW PPHM M5 – 0.58 X 20
125 043116 2 SCREW HHC M6 – 1.0 X 12
126 0E1644 1 SCREW BHSC M6-1.0 X 12 SS
127 0E9572 1 BRACKET, STEPPER MOTOR
129 0G6453 1 ASSY,CONTROLLER GTH990 HSB
131 0E9570 1 ASSY, THROTTLE ROD
132 0E9577 1 BELLOWS, INTAKE
133 0E5846 1 EXPANSION PLUG
134 0E9419 3 #10 O-RING
135 0C4760 1 PLUG, MANIFOLD
136 0F9253 1 ASSY, AIR BOX BASE
137 0G5970 1 PIN, FUEL SELECTOR (13, 16kW) NO STRIPES
0G8824 1 PIN,FUEL SELECTOR (14, 17 kW) 1 STRIPE
0G9133 1 PIN, FUEL SELECTOR (20kW) 3 STRIPES
138 0E9554 1 PIN, FUEL SEL STOP
139 0E9348 1 SOLENOID COVER
140 0E9599 1 LINKAGE, CHOKE
141 0E9595 4 SCREW PPPH HI-LO #6 X 1/2
142 090987 1 SCREW PHTT M3 – 0.5 X 8
143 0E9403 1 RETAINER, CHOKE RETURN SPRING
144 0E9571 1 SPRING, CHOKE RETURN
145 0E9380 1 WASHER, BELLEVILLE SPRING
146 0A6345 1 SCREW PPHM M2 – 0.4 X 8
147 0E9598 1 CHOKE ARM
148 0E9593 1 SCREW SHOULDER M3 – 0.5 X 6
149 0E9564 1 VALVE, CHOKE
150 0E9575 1 SHAFT, CHOKE
151 0E9357 1 SEAL, GOVERNOR ARM
152 0A7094 2 SCREW PHM #4 – 40 X 1/4
153 0E9574 1 BRACKET, SOLENOID
154 0F9273 1 SOLENOID, 6VDC
155 0F5467 1 NUT HEX M8 – 1.25 YELLOW ZINC
156 0E9557 1 SPRING, CHOKE VALVE ADJUST
157 0E1644 1 SCREW, BHSC M6-1.0 x 12
