MODEL NO:
PWN3702P
Quick Installation Guide
Wireless-N Extender 300Mbps
AC Passthrough
Version 1.20
(English / Indonesian)
BEFORE GETTING STARTED
This document is designed to aid you to get started with the device. If you experience problems following these guides or need further information pertaining to the device,
please visit our website at www.prolink2u.com. All specifications are subject to the manufacturer's configuration at the time of shipping and may change without prior
notice, written or otherwise.
Advertisement
Table of Contents
Related Manuals for PROLiNK PWN3702P
Summary of Contents for PROLiNK PWN3702P
- Page 1 MODEL NO: PWN3702P Quick Installation Guide Wireless-N Extender 300Mbps AC Passthrough Version 1.20 (English / Indonesian) BEFORE GETTING STARTED This document is designed to aid you to get started with the device. If you experience problems following these guides or need further information pertaining to the device, please visit our website at www.prolink2u.com.
- Page 3 All specifications are subject to the manufacturer’s configuration at the time of shipping and may change without prior notice, written or otherwise. Items: One (1) unit of PROLiNK ® PWN3702P One (1) piece of Quick Installation Guide (QIG) Note: 1.
- Page 4 2. Overview Front View Left View Right View Back View Reset AC Passthrough Socket Reset : Press 1 - 5 seconds to reboot extender. Press > 5 seconds to reset to factory default and reboot. WPS : Press 1 second to trigger WPS function AC Power Input LED Indicators: Caution : If the device is used wrongly, this may lead to...
- Page 5 3. Hardware Installation Smartphone Tablet PWN3702P Laptop Cable / DSL Modem Router Router WiFi Range WiFi Extender Range EN 3...
- Page 6 4. Connecting to the Root AP Method 1 : With WPS button Step 1. Plug the PWN3702P into the electrical socket and power on the electrical socket. The Power on PWN3702P will illuminate. Wait until the WLAN and WPS LEDs light up.
- Page 7 Step 1. Connect your computer to PWN3702P via wireless. The wireless network (SSID) shall appear as “PROLiNK_xxxxxx”. Note: The Wi-Fi Key or password can be found on the label pasted on PWN3702P. Step 2. Open web browser and type http://192.168.123.253 in the browser’s address box. This is the default IP address for PWN3702P.
- Page 8 4. Connecting to the Root AP Select the wireless network or root AP that you want to connect to, and click on <Next>. Tick this checkbox if you want to set the Extender SSID and password same as the root AP. Key in the wireless password of the wireless router or root AP, and click on <Next>...
- Page 9 Check and confirm if the information are correct. Click <Finish> and the PWN3702P will attempt to connect to the root AP. Note: The Signal Strength LEDs will illuminate to show the link quality once connected to the root AP.
- Page 10 Wireless Password History...
- Page 11 All specifications are subject to the manufacturer’s configuration at the time of shipping and may change without prior notice, written or otherwise. Items: 1 Satu (1) unit PROLiNK® PWN3702P 2 Satu (1) buah Lembar Panduan Installasi Catatan: 1.
- Page 12 2. Penjelasa Tampak Depan Tampak Samping Kiri Tampak Samping Kanan Tampak Belakang Reset Reset : Tekan 1 - 5 detik untuk memulai kembali extender dari awal. AC Passthrough Socket Tekan > 5 Detik untuk mengembalikan settingan pabrik dan WPS : Tekan 1 detik untuk menaktifkan fungsi WPS memulai kembali dari awal.
- Page 13 3. Instalasi Perangkat Keras Smartphone Tablet PWN3702P Laptop Cable / DSL Modem Router Jangkauan Wifi Router Jangkauan WiFi Extender ID 3...
- Page 14 4. Bagaimana Cara Koneksi ke AP? Metode 1 : Dengan tombol WPS Langkah 1. Pasang PWN3702P ke soket listrik dan hidupkan soket listrik. Lampu Power LED menyala PWN3702P. Tunggu sampai indicator LED WLAN dan WPS LEDs menyala. Langkah 2. Tekan tombol on Proteksi Wi-Fi Protected Setup (WPS) pada router nirkabel atau AP.
- Page 15 4. Bagaimana Cara Koneksi ke AP? Metode 2 : Dengan Konfigurasi melalui Web Langkah 1. Hubungkan computer anda ke PWN3702P melalui jaringan nirkabel. Nama Jaringan nirkabel (SSID) akan muncul sebagai “PROLiNK_xxxxxx”. Catatan: Kunci Wi-Fi atau sandi dapat ditemukan pada label PWN3702P.
- Page 16 4. Bagaimana Cara Koneksi ke AP? Pilih jaringan nirkabel atau AP yang akan anda hubungkan, dan klik pada <Next>. Centang kotak ini jika Anda ingin mengatur SSID Extender dan password yang sama seperti AP root. Sandi Kunci pada jaringan nirkabel dari router nirkabel atau AP, dan klik pada <Next> untuk menjalankannya.
- Page 17 AP menggunakan kata sandi yang salah. Periksa dan pastikan apakah informasi sudah benar. Klik <Finish> dan PWN3702P akan melakukan koneksi ke AP. Catatan: Signal LED Strength akan menerangi untuk menunjukkan kualitas jaringan pada saat terhubung dengan AP. ID 7...
- Page 18 Catatan Sejarah Sandi Nirkabel...
- Page 19 1. Garansi Hanya Berlaku Jika : a. Diisi dengan jelas, lengkap dan benar. b. Jika telah dikirimkan dan diterima oleh PT. Prolink Intidata Nusantara. c. Memperlihatkan kartu garansi asli dan nota pembelian pada saat klaim service. 2. Garansi Tidak Berlaku Apabila : a.
- Page 20 S/N : Produk Nama ———: Model : Name Alamat Tgl. Pembelian —————— : ————: Purchase Date Address Dealer : ——— Toko Kota Kota: Kode Pos: ——— City Tel / Fax : Email : Pelanggan PT. Prolink Intidata Nusantara Cap Toko...
- Page 21 S/N : Produk Nama ———: Model : Name Alamat Tgl. Pembelian —————— : ————: Purchase Date Address Dealer : ——— Toko Kota Kota: Kode Pos: ——— City Tel / Fax : Email : Pelanggan PT. Prolink Intidata Nusantara Cap Toko...
- Page 22 Tempelkan perangko disini. Hanya untuk pengeposan di Indonesia Kepada Yth. Customer Service PT. PROLINK INTIDATA NUSANTARA Jl. Cideng Barat No.79 Jakarta Pusat 10150 - Indonesia KARTU GARANSI (for Indonesia region only)
- Page 24 Register Online For Your Product Warranty @ www.prolink2u.com/register PROLiNK® is a trademark of FIDA INTERNATIONAL (S) PTE LTD and is manufactured under its authority. All other brands, products, services, logos and company names mentioned herein are trademarks of their respective...
