Clas Ohlson il06 Operating Instructions

Handsfree Smartwatch
Art.no 38-6849 Model iL06
Please read the entire instruction manual before using the product and then
save it for future reference. We reserve the right for any errors in text or
images and any necessary changes made to technical data. In the event of
technical problems or other queries, please contact our Customer Services.
Things to consider:
• Other wireless equipment using the same frequency band can reduce
the transmission range.
• The range of all wireless equipment depends on the type of obstacles
located between the transmitter and the receiver (e.g. a concrete wall
will interfere with the signal more than a plasterboard wall).
If you experience problems, try the following:
• Turn off any other existing wireless equipment to check whether this is
the cause of the problem.
• Reposition the wireless equipment, shorten the distance between
the transmitter and the receiver or reduce the number of obstacles
(walls, furniture, etc.) between them.

Buttons and functions

1
2
3
1. Microphone
2. USB port for connecting a charger cable
3. Display
4. [ A ] Manage calls and make settings
5. [ B ] Manage calls and make settings
6. Speaker
Watch display in time display mode
7
7. Time display
8. Watch battery status
9. Bluetooth connection status
- watch connected via Bluetooth.
- watch not connected via Bluetooth.
- Bluetooth connection in progress.
10. Number of unread SMS text messages. Note: Only displayed on
Android telephones with app installed.
11. Number of missed calls. Note: Only displayed on Android telephones
with app installed.
GREAT BRITAIN • customer service tel: 020 8247 9300
Operating instructions

Charging

1. Connect one end of the included USB cable to a computer or other
USB charger and the other end to the input socket (2) on the watch.
The word "Charging" will be displayed whilst charging is in progress and
the words "Charge complete", when the battery is fully charged.
2. Charge the watch for at least 2 hours before using it for the first time.

App

The full range of available smartwatch functions is only accessible on
Android telephones by installing an app.
Download "IL06_SmartWatch" from GooglePlay (there is no app for iPhones).
The app is used for synchronising the watch and the phone.
The app has the following syncing functions:
• Weather
• Missed Calls
• Sync Time
• Unread SMS
• Interactive Seeking – The watch alarm is triggered if it moves too far
from the telephone (Android and iPhone). Find the watch using
the app (Android only).
• User guide
The table shows the watch functions when it is
used with an Android phone or with an iPhone
Note:
• The redial function works differently for different models of Android
4
telephones, some call up the last number dialled whilst others call up
the last number in the call history.
5
• If you use the redial function on the watch when it is connected to
an iPhone, it will redial the last number dialled.
6
Function Android with
installed app
Displays incoming call Yes
Displays name of incoming Yes
caller
Displays missed calls with Yes
return call option
Displays unread messages Yes
with option to read them
Alarm triggers when it is too far Yes
from the phone
8
Alarm function Yes
Enables the phone to find Yes
9
the watch
10 Accepts an incoming call Yes
Shows call history with option Yes
11
to use the numbers
Displays the time Yes
Displays weather forecast Yes
Time synchronisation Yes
Switching the watch on/off
Hold down [ B ] for 3 seconds.
e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.co.uk
Watch menu
1. Press [ A ] or [ B ] to light up the display on the watch.
2. Press [ A ] to open the main menu. The main menu has 6 submenus:
-
Time and date
- Call Record
- Unread SMS (text messages)
- Weather
- Alarm
- Stopwatch
3. Toggle between the menus using [ A ] or [ B ].
4. Open the menu by double-clicking [ A ] or [ B ].
5. Navigate through the values using [ A ], change the values using [ B ].
6. Hold down [ A ] or [ B ] to return to the starting display. If no settings are
being made in the submenus, the watch will automatically return to
the main menu after a few seconds.
iPhone

Bluetooth connection

(no app available)
1. Activate Bluetooth on the telephone which you intend pairing with the watch.
Yes
2. Hold down [ B ] to switch the watch on, after a few seconds the starting
Yes display will appear. Keep holding [ B ] down until "Pairing" appears on
the display, then release [ B ].
3. The watch will appear in the list of Bluetooth devices on your telephone
No
as IL06. Select it and pair it with your telephone in the normal way for
your model of telephone.
No
4. If you are prompted for a password, enter 6688.

Handsfree functions

Yes
• Answering incoming calls: Press [ A ] or [ B ].
• Ending a call: Hold down [ A ] or [ B ].
Yes
• Redialling: Press [ A ] or [ B ] twice in quick succession.
No
Note: The redial function works on iPhones without an app, but only on
Yes Android phones with the app installed.
Yes
Anti-lost
• If the watch gets too far away from the telephone it is paired with
Yes
(approx 10 m) it vibrates and the word "Disconnected" and
No
the symbol appear on the display.
• Press [ A ] or [ B ] to switch the warnings off.
Yes
• The watch automatically connects to the telephone when it is back
within range.

To find your telephone

1. Press [ A ] or [ B ] to light up the display on the watch.
2. Hold down [ A ] and [ B ] for 3 seconds.
3. Your telephone will vibrate and ring.
To find the watch
1. Open the app in your telephone.
2. Press Interactive Seeking.
3. The watch will emit an audible signal.
Care and maintenance
• Clean the product using a lightly moistened cloth. Use only mild cleaning
agents, never solvents or corrosive chemicals.
• Do not subject the watch to impacts or shocks and do not expose it to
extremely hot, cold or dusty environments.
• Never immerse the watch in water or any other type of liquid.
• Do not wear the watch while showering or bathing.
• Never attempt to dismantle the watch; it contains no
user-serviceable parts.
Troubleshooting guide
The watch won't • The battery might be flat. Recharge the battery.
turn on. Refer to the Charging section above.
No contact • Check the Bluetooth connection. Refer to
between the Bluetooth connection section above.
the watch and • Existing wireless equipment could possibly disrupt
your telephone. the Bluetooth connection. Switch off any such
equipment to see if that solves the problem.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.

Specifications

Bluetooth 2.1
Range Approx. 10 m
Battery 190 mA li-po
Charging time 2 hours

Declaration of Conformity

Hereby, Clas Ohlson AB declares that following product(s):
38-6849
IL06
is in compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC and 2006/95/EC.
Article 3.1a (Health): EN 62479
Article 3.1a (Safety) EN 60950-1
Article 3.1b (EMC): EN 301489-1
EN 301489-17
Article 3.2 (Radio): EN 300328
0700
Insjön, Sweden, Feb. 2015
Klas Balkow,
President.
Clas Ohlson, 793 85 Insjön, Sweden
