BATMAN 2CH IR HELICOPTER
INSTRUCTION MANUAL
PRODUCT INCLUDES:
(4) 1X Main Rotor (5) 1X Stabilizer Link (6) 1X USB Charging Cable (7) Spare Blades
Length: 7.8 Inches Width: 2.6 Inches
Product Description:
Flight Altitude: 32 ft
Flight Distance: 26-32 ft
Internal Battery: 3.7 V 220 Mah
Helicopter Materials:
Electronic Components, Hardware Fitting,
2.5 Channel Infared Remote Control
Helicopter, Energy Saving Function.
Incorrectly storing this RC helicopter
may cause the rotor blades to bend and/or warp,
which may make it unable to fly properly.
INSTALLING THE BATTERIES:
correct polarity. Shut the Battery Case and you are ready to fly!
Power Light
Throttle Stick
Power Switch
Helicoptor
Charger
Always turn off the power when charging. The charge time is about 40-60
minutes. The green power indicator lights up while charging. The red
power indicator will light up when the charging time has completed. When
the power indicator blinks, the helicopter is almost out of power and the
batteries must be charged or replaced. The USB Charging Cable light will
turn off while it is charging but it will light up when the battery has
charged.
(1) 1X RC Helicopter (2) 1X Remote (3) 1X User Manual
Main Rotor Blades
Height: 8.7 Inches
Charging Time: 40-59 min
Flight Time: 5-7 min
Open the Battery Case and insert 6 AA Batteries by the
Band Selector
(A. B. C.)
Flight Stick
Transmitter
Power
Light
Safe Battery Usage:
1) Use only AA batteries.
2) Do not mix different battery types.
3) Do not mix older and newer batteries.
4) Remove the batteries when the Helicopter is
not in use.
5) Do not recharge non-rechargeable batteries.
6) Insert the batteries with the correct polarity.
7) USE 6X1.5V AA BATTERIES (Not Included).
Balance Lever
Infrared Transmitter
Charging Socket
Power
Switch
Battery Case
Advertisement
Table of Contents
Related Manuals for World Tech Toys ZX-35886 Batman
Summary of Contents for World Tech Toys ZX-35886 Batman
-
Page 1: Instruction Manual
BATMAN 2CH IR HELICOPTER INSTRUCTION MANUAL PRODUCT INCLUDES: (1) 1X RC Helicopter (2) 1X Remote (3) 1X User Manual (4) 1X Main Rotor (5) 1X Stabilizer Link (6) 1X USB Charging Cable (7) Spare Blades Balance Lever Main Rotor Blades Length: 7.8 Inches Width: 2.6 Inches Height: 8.7 Inches Product Description:... -
Page 2: Flight Operation
FLIGHT OPERATION: To ensure a safe and stable flight, please follow these instructions: 1) On the transmitter, set the Channel Switch to A or B (avoid using the same frequency to other nearby RC devices). Turn the ON/OFF Switch on. 2) After the red light on the transmitter flashes, hold the Flight Stick in the middle position then move the Throttle Stick slowly up and then back down to calibrate it. -
Page 3: Lift Off Procedure
LIFT OFF PROCEDURE: 1) Place the Helicopter on a smooth surface. 2) Slowly increase the throttle. Make sure to focus on the Helicopter, not on the transmitter. 3) As soon as the Helicopter lifts off, slightly reduce the throttle. 4) Gently increase the throttle if the Helicopter is falling. 5) Gently reduce the throttle if the Helicopter goes too high. -
Page 4: Troubleshooting
CARE AND MAINTENANCE: - Always fly in a still indoor enviroment. Watch out for wind from an air conditioner or heater. - Fly in an area that is at least over 17ftx10ftx10ft (LengthxWidthxHeight) - Do not fly near fans, air conditioners, heater, lamps and other obstacles. SAFETY REGULATIONS: - Do not dispose the battery in a fire.
