GAS GRILL
Natural Gas Grill Owner's Guide
Guía del Propietario de la Barbacoa de Gas Natural - Pg. 45
ESNA
Mode d'emploi du grill à gaz naturel - Pg. 79
SUMMIT
®
GRILL CENTER
YOU MUST READ THIS OWNER'S GUIDE
BEFORE OPERATING YOUR GAS GRILL.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
Leaking gas may cause a fire or explosion
which can cause serious bodily injury,
death, or damage to property.
WARNING:
1. Do not store or use gasoline or other
flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
#56568
WARNING: Follow all leak-check
procedures carefully in this manual prior
to barbecue operation. Do this even if the
barbecue was dealer-assembled.
NOTICE TO INSTALLER: These instructions
must be left with the owner and the owner
should keep them for future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not ignite this appliance
without first reading the BURNER
IGNITION sections of this manual.
56568 09/01/11 NG
US - ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SUMMIT GRILL CENTER 56568 and is the answer not in the manual?

Questions and answers

Related Manuals for Weber SUMMIT GRILL CENTER 56568

Summary of Contents for Weber SUMMIT GRILL CENTER 56568

  • Page 1 GAS GRILL Natural Gas Grill Owner’s Guide Guía del Propietario de la Barbacoa de Gas Natural - Pg. 45 ESNA Mode d’emploi du grill à gaz naturel - Pg. 79 SUMMIT ® GRILL CENTER #56568 YOU MUST READ THIS OWNER’S GUIDE WARNING: Follow all leak-check BEFORE OPERATING YOUR GAS GRILL.

  • Page 2: Warnings

    Combustible materials should never be within 24 inches construction. Ignoring this Warning could cause a fire or ® (61 cm) of the back or sides of your Weber gas barbecue. an explosion that can damage property and cause serious Do not put a barbecue cover or anything flammable on, or in bodily injury or death.

  • Page 3: Table Of Contents

    ROTISSERIE COOKING ......... . . 37 WEBER ®...

  • Page 4: Exploded View

    EXPLODED VIEW • DIAGRAMA DE DESPIECE • VUE ECLATEE SUMMIT_6Brn_Grill Center_NG_US_121610...
  • Page 5 ® Perilla de la estación de dorado Sear Station Parrilla de cocción Bouton Sear Station ® Grille de cuisson 19. Battery Housing 38. Smoker Box Compartimiento de las baterías Caja del ahumador Logement des piles Boîtier du fumoir WWW.WEBER.COM ®...
  • Page 6 EXPLODED VIEW • DIAGRAMA DE DESPIECE • VUE ECLATEE SUMMIT_Grill Center Left Cabinet_121610 Rotisserie Motor Left End Skirt Back Panel Motor del asador Faldón del extremo izquierdo Panel posterior Moteur de la rôtissoire Jupe d’extrémité gauche Panneau arrière Rotisserie Bracket Adjustable Leg 12.
  • Page 7 Shelf Bracket Door Handle 14. Bottom Panel Soporte del estante Asa de la puerta Panel inferior Support pour étagère Poignée de porte Panneau inférieur Left Frame 10. Back Panel Bastidor izquierdo Panel posterior Cadre de gauche Panneau arrière WWW.WEBER.COM ®...
  • Page 8 EXPLODED VIEW • DIAGRAMA DE DESPIECE • VUE ECLATEE SUMMIT_Grill Center SB Cabinet_122110 Side Burner Lid Wire Shelf 15. Shelf Bracket Tapa del quemador lateral Estante de alambre Soporte del estante Couvercle du brûleur latéral Etagère métallique Support pour étagère Wok Ring Control Knob 16.
  • Page 9 Porte Panneau inférieur Side Burner Head 13. Door Handle Cabezal del quemador lateral Asa de la puerta Tête du brûleur latéral Poignée de la porte Side Burner 14. Back Panel Quemador lateral Panel posterior Brûleur latéral Panneau arrière WWW.WEBER.COM ®...
  • Page 10 EXPLODED VIEW • DIAGRAMA DE DESPIECE • VUE ECLATEE SUMMIT_Grill Center Middle Cabinet_121610 Cooler Lid Door Assembly Right Back Panel Tapa del enfriador Ensamble de la puerta Panel derecho posterior Couvercle du refroidisseur Assemblage de la porte Panneau arrière droit Cooler Front Panel 10.
  • Page 11 Panel superior del gabinete de esquina Varilla de la bisagra de la puerta Panel inferior Panneau supérieur du meuble de coin Tige du gond de la porte Panneau inférieur Right Back Panel Door Panel derecho posterior Puerta Panneau arrière droit Porte WWW.WEBER.COM ®...
  • Page 12 EXPLODED VIEW • DIAGRAMA DE DESPIECE • VUE ECLATEE SUMMIT_Grill Center Social Center_121610 Condiment Holder Shelf Frame Right Frame Portacondimentos Bastidor del estante Bastidor derecho Support pour condiments Cadre de l’étagère Cadre de droite Table Shelf 12. Right Frame Skirt Mesa Estante Faldón del bastidor derecho...
  • Page 13 Cadre de droite Poignée de porte de droite Panneau inférieur Adjustable Leg 10. Back Panel 15. Left Door Handle Pata ajustable Panel posterior Asa de la puerta izquierda Pied ajustable Panneau arrière Poignée de la porte de gauche WWW.WEBER.COM ®...

  • Page 14: Warranty

    All remaining parts: 2 years Weber does not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment; and no when assembled and operated in accordance with the printed instructions accompanying it. Weber such representations are binding on Weber.

  • Page 15: Gas Instructions

    This is a typical installation of a Weber ® natural gas barbecue. gas from the source when the barbecue is disconnected.

  • Page 16: Type Of Gas

    See your local dealer. ® For safety and design reasons, the conversion of a Weber grill from operation using natural gas to operation using LP gas requires the change out of the entire gas Swivel connection supply system of the grill.

  • Page 17: Leak Check Preparation

    LED features: Be careful not to break or disconnect the wires for the control panel LED’s). E) Place the control panel on the towel covering the door assemblies (4). The grill illustrated may have slight differences than the model purchased. WWW.WEBER.COM ®...

  • Page 18: Check The Flexible Hose To Manifold Connection

    Note: All factory-made connections have been thoroughly checked for gas leaks. The burners have been flame-tested. As a safety precaution, however, you should recheck all fittings for leaks before using your Weber® gas barbecue. Shipping and handling may loosen or damage a gas fitting.
  • Page 19 Contact the Customer Service Representative in your area using the contact information on our web site. Log onto ® www.weber.com E) Side burner hose to quick disconnect connection, side burner line to valve and orifice connections (5). F) Hose to quick disconnect connection (6).

  • Page 20: Light Features

    ® GRILL OUT™ HANDLE LIGHT The Weber Grill Out™ Handle Light has a built-in “tilt sensor.” With the power button (1) activated, the light will come on when the grill lid is open. The light will turn off when the lid is closed.

  • Page 21: Hose Inspection

    If the hose is found to be damaged in any way, do not use the barbecue. Replace ® using only Weber authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 22: Main Burner Ignition & Usage

    WARNING: Check hose before each use of barbecue for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 23: Main Burner Manual Ignition

    OFF and wait five minutes to let the gas clear before differences than the model purchased. you try again. TO EXTINGUISH Push in and turn each burner control knob clockwise to OFF position. Turn gas supply off at the source. WWW.WEBER.COM ®...

  • Page 24: Grilling Tips & Helpful Hints

    Cooking conditions, such as wind and weather, may require adjustment of burner controls to obtain the correct cooking temperatures. Note: If grill loses heat while cooking, refer to the troubleshooting section of this manual. WARNING: Do not move the Weber ® gas barbecue when operating or while barbecue is hot.

  • Page 25: Cooking Methods

    For longer cooking times, add water to the foil pan to keep drippings from burning. The drippings can be used to make gravies or sauces. WWW.WEBER.COM ®...

  • Page 26: Side Burner Ignition & Usage

    WARNING: Check hose before each use of barbecue for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 27: Side Burner Manual Ignition

    If the hose is found to be damaged in any way, do not use the barbecue. Replace ® using only Weber authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 28: Side Burner Usage

    Wok Cooking The side burner also comes with a wok ring for wok cooking. IMPORTANT: Do not place a wok directly on the side burner. Only the Weber ® wok accessory should be used when cooking on the included wok ring.

  • Page 29: Sear Station Ignition & Usage

    WARNING: Check hose before each use of barbecue for nicks, cracking, abrasions or cuts. If the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber ® authorized replacement hose. Contact the Customer Service Representative in your area using the contact information on our web site.

  • Page 30: Sear Station Burner Manual Ignition

    USING THE SEAR STATION ® ® Your Weber gas barbecue includes a sear burner for searing meats such as steak, poultry parts, fish, and chops. Searing is a direct grilling technique which browns the surface of the food at a high temperature.

  • Page 31: Smoker Burner Ignition & Usage

    Customer Service Representative in your area using the contact information on our web site. ® Log onto www.weber.com A) Open the grill lid (1). B) Open smoker box lid (2). C) Fill smoker with water-soaked wood chunks or chips (3).

  • Page 32: Smoker Burner Manual Ignition

    SMOKER BURNER IGNITION & USAGE SMOKER BURNER MANUAL IGNITION A) Open the lid (1). DANGER Failure to open the lid while igniting the grill, or not waiting five minutes to allow the gas to clear if the grill does not light, may result in an explosive flare-up which can cause serious bodily injury or death.
