Yamaha RX-V1067 Service Manual

RX-V1067/HTR-8063/
Note:
When IC502 of NET P.C.B. or NET P.C.B. is replaced, the network function of this unit will not operate properly
without additional setting.
In such case, report the serial number of this unit to the following e-mail address.
Yamaha Corporation will reply providing the setting procedure to make the network function of this unit operate
properly.
注意：
NET P.C.B. および IC502（NET P.C.B.）を交換した場合、本機のネットワーク機能が正常に動作しません。
正常に動作させるための設定方法は、YCJ（Yamaha Corporation Japan）からご連絡します。
はじめに、交換した本機のシリアルナンバーを下記の E-mail アドレスへ報告してください。
This manual has been provided for the use of authorized YAMAHA Retailers and their service personnel.
It has been assumed that basic service procedures inherent to the industry, and more specifi cally YAMAHA Products, are already known
and understood by the users, and have therefore not been restated.
WARNING:
IMPORTANT:
The data provided is believed to be accurate and applicable to the unit(s) indicated on the cover. The research, engineering, and service
departments of YAMAHA are continually striving to improve YAMAHA products. Modifications are, therefore, inevitable and
specifi cations are subject to change without notice or obligation to retrofi t. Should any discrepancy appear to exist, please contact the
distributor's Service Division.
WARNING:
IMPORTANT:
■ CONTENTS
TO SERVICE PERSONNEL ............................................2
FRONT PANELS .........................................................3-4
REAR PANELS ...........................................................5-8
REMOTE CONTROL PANELS .......................................9
SPECIFICATIONS / 参考仕様 ................................. 10-15
INTERNAL VIEW .......................................................... 16
SERVICE PRECAUTIONS / サービス時の注意事項 ..... 16
DISASSEMBLY PROCEDURES / 分解手順 ........... 17-20
UPDATING FIRMWARE /
ファームウェアの書き込み .....................................21-22
AMP ADJUSTMENT / アンプ部調整 .......................23-25
SELF-DIAGNOSTIC FUNCTION /
ダイアグ（自己診断機能） .......................................26-67
1 0 1 1 8 3
SERVICE MANUAL
E-mail: ycav-ysiss@gmx.yamaha.com
IMPORTANT NOTICE
Failure to follow appropriate service and safety procedures when servicing this product may result in personal injury,
destruction of expensive components, and failure of the product to perform as specifi ed. For these reasons, we advise
all YAMAHA product owners that any service required should be performed by an authorized YAMAHA Retailer or
the appointed service representative.
The presentation or sale of this manual to any individual or fi rm does not constitute authorization, certifi cation or
recognition of any applicable technical capabilities, or establish a principle-agent relationship of any form.
Static discharges can destroy expensive components. Discharge any static electricity your body may have
accumulated by grounding yourself to the ground buss in the unit (heavy gauge black wires connect to this buss).
Turn the unit OFF during disassembly and part replacement. Recheck all work before you apply power to the unit.
DISPLAY DATA .......................................................68-70
IC DATA ...................................................................71-90
PIN CONNECTION DIAGRAMS .............................91-94
BLOCK DIAGRAMS ................................................95-99
PRINTED CIRCUIT BOARDS ............................. 100-126
SCHEMATIC DIAGRAMS ................................... 127-145
REPLACEMENT PARTS LIST ............................ 147-177
REMOTE CONTROL ........................................... 178-180
ADVANCED SETUP ............................................ 181-183
本機の基本設定 / 初期化を行う ........................... 184-185
Copyright © 2010
This manual is copyrighted by YAMAHA and may not be copied or
redistributed either in print or electronically without permission.
AV RECEIVER
RX-A1000
All rights reserved.
P.O.Box 1, Hamamatsu, Japan
'10.08
