- Page 1 TRINITY ADVANCED PRO Instruction manual ATTENTION! THIS MANUAL IS ONLY FOR PROFESSIONAL BICYCLE MECHANICS AT AUTHORIZED GIANT DEALERS. IT IS NOT INTENDED FOR THE CONSUMER/END-USER. Version 9 /2015...
-
Page 2: Table Of Contents
CONTENTS SELECTING THE CORRECT FRAME SIZE ------------------------------------------------------------- 3 ARMREST STACK AND REACH RANGE ---------------------------------------------------------------- 4 FORK STEER LENGTH -------------------------------------------------------------------------------------------- 5 COCKPIT PARTS ASSEMBLY CHART -------------------------------------------------------------------- 6 STEM/BASEBAR PARTS ASSEMBLY CHART -------------------------------------------------------- 7 HANDLEBAR & STEM ASSEMBLY INSTRUCTIONS --------------------------------------------- 8 ARMREST AND EXTENSIONS ------------------------------------------------------------------------------ 10 ----------------------------------------------------------------------------------- 10 ASEBAR EIGHT... -
Page 3: Selecting The Correct Frame Size
Selecting the Correct Frame Size The Trinity Advanced Pro is available in 4 frame sizes to fit a wider range of riders. While each individual’s unique body proportions will determine which frame size offers the best fit, beginning with the rider’s height .inseam. saddle and height provide a narrower range of sizing options: ※We recommend first performing the rider fit using the Right Ride System or a... -
Page 4: Armrest Stack And Reach Range
Trinity frame size, in both the triathlon and TT conf igurations. Tri Version UCI Version Frame Size Version Arm Pad Stack Arm Pad Reach (mm) 428-488 436-496 422-482 430-490 415-475 423-483 403-463 411-471 Trinity Advanced Pro TT Trinity Advanced Pro Triathlon Version 9 /2015... -
Page 5: Fork Steer Length
Steer Length (mm) Steer Version Model Frame Size Length (mm) 46(XS) M 49(S) M MY16 Trinity Advanced Pro 51.5(M) M 54.5(L) M Triathlon 45(XXS) W 121.5 48(XS) W 121.5 MY16 Avow Advanced Pro/ MY16 Avow Advanced Pro-FF TM 51(S) W 136.5... -
Page 6: Cockpit Parts Assembly Chart
Cockpit Parts Assembly Chart Specification Quantity Torque range [1] Armrest pad [2] Armrest Right Left [3] Armrest bolt M5X8 tapered 3 Nm [4] Extension plug [5] Extension [6] Extension clamp Right Left [7] Tear drop spacer 10mm 20mm [8] Handlebar [9] Handlebar plug Front Rear... -
Page 7: Stem/Basebar Parts Assembly Chart
Stem/Basebar Parts Assembly Chart Specification Quantity Torque range [1] Headset compression bolts M6X30 6 Nm [2] Upper stem bolts M5X15 6 Nm [3] Upper stem [4] Stem bolts M5X25 6 Nm M5X35 3 Nm (w/o stem bottle) M5X45 3 Nm (w/ stem bottle) [5] Handlebar bolt M4X25... -
Page 8: Handlebar & Stem Assembly Instructions
Handlebar & Stem Assembly Instructions Warning: Please ensure you are using correct assembly parts in the correct order. Assemble extension bar on the handlebar with M5 screws, locking torque Assemble armrest pad to clamp with Hexagon socket countersunk head screws, locking torque 3Nm Handlebar alignment and assembly... - Page 9 Assemble upper stem to the fork steering tube. Lock M6 screws first then M5 screws, locking torque Assemble handlebar in upper stem with M4 screws, locking torque4Nm Assemble stem spacer at fork with M5 Hexagon socket countersunk head screws, locking torque Assemble lower stem with M5 screws and M5 Hexagon socket...
-
Page 10: Armrest And Extensions
Armrest and Extensions Basebar Height Adjustment By inverting the handlebar, you can choose either the low position or the high position. The height difference between the two is 40mm. Armrest Pad Height Adjustment The armrest supports height can be adjusted up to 40mm with the teardrop spacers. -
Page 11: Extension Width Adjustment
Extension Width Adjustment By positioning the extension clamps to face outside or inside, you can choose either a wide or a narrow extension setup. You can refine your extension setup by turning the extension’s bend inward or outward. Additionally, the extensions can slide in the clamps. You can adjust the extensions both fore and aft. -
Page 12: Armrest Pad Reach Adjustment
Armrest Pad Reach Adjustment The armrests can be bolted onto the extension clamps in 4 positions and reversed to achieve 5 different armrest fore/aft positions. With 15mm increments between positions, Trinity offers a total of 60mm of adjustment range. The 0mm mark represents the shortest armrest reach adjustment attainable for each given frame size. - Page 13 Pad locking to clamp: Second and fourth hole Pad locking to clamp: Third and fourth hole Version 9 /2015...
-
Page 14: Armrest Pad Width Adjustment
Armrest Pad Width Adjustment The armrest pads can be bolted onto the extension clamps in 3 positions, with additional adjustment range created by reversing the extension clamp orientation. Version 9 /2015... -
Page 15: Armrest Pad Rotation Adjustment
Armrest Pad Rotation Adjustment The armrest pads can be rotated on the mounting clamps, from 10-degrees inward to 8-degrees outward. Angle Inward 8° Angle Inward 10° Angle Outward 8° Version 9 /2015... -
Page 16: Brake Assembly
Brake Assembly Front Brake Assembly Assemble front brake at fork with M6 Assemble front brake cable by passing screws, locking torque 6Nm. through fork, pipe and brake. Adjust to the reasonable gap between brake pad and rim with M5 screws, locking torque 6Nm Assemble crown cover on the bottom of To ensure even brake pad position and the fork, to avoid the brake cable contact... -
Page 17: Rear Brake Assembly
Rear Brake Assembly Assemble the rear brake cable by routing through frame, pipe and brake. Adjust to reasonable gap between brake pad and rim. Assemble rear brake to the frame by M6 End of the brake cable forward with a cover screw, locking torque 6Nm. -
Page 18: Derailleur/Brake Cable Housing Guideline & Cable Routing
DERAILLEUR/BRAKE CABLE HOUSING GUIDELINE & CABLE ROUTING To ensure optimal shifting and braking operation, proper cable housing length is essential. Please see the following guideline for cable housing length for each system and frame size Di2 derailleur parts list & cable routing -Cable Length (mm) Size 1000... -
Page 19: Mechanical Parts List & Cable Routing
Mechanical parts list & cable routing - Cable Length (mm) FRONT REAR Size 1410 1460 1500 1550 Version 9 /2015... -
Page 20: Trinity Brake Routing
Trinity Brake Routing - Cable Length (mm) Size FRONT REAR 1025 1045 1075 1135 Front Brake Rear Brake Brake hose should be assembled into pipe Front brake cable in head tube correctly. should not touch rear brake cable. Version 9 /2015... -
Page 21: Aerovault Toptube Box Assembly (Di2)
AeroVault Toptube Box Assembly (Di2) The toptube box is secured with M5 screws. Slide the Di2 control box into the allocated position in the bento box after plugging in the Di2 wires. By pressing down on the blue location, the cover is secured in the closed position. -
Page 22: Aerovault Toptube Box Assembly (Mechanical)
AeroVault Toptube Box Assembly (Mechanical) The derailleur cable/ housing can be routed through the open slot of the toptube box The toptube box is secured with M5 screws. By pressing down on the blue location, the cover is secured in the closed position. Storage space is accessible from this position via the sides of the toptube box soft cover. -
Page 23: Di2 Battery Seatpost Installation
Di2 Battery Seatpost Installation -Assembly Assemble the dilator and support base After assembling, insert into seat tube affixed to the outer wall of the battery then lock dilator with M4 screws to fix battery inside the seatpost. -Charging Open the toptube box cover, remove the Open the anti-dust cover, plug in the Di2 junction box EW90 charging cable to charge the battery... -
Page 24: Aerovault Stem Hydration Assembly Chart
AEROVAULT STEM HYDRATION ASSEMBLY CHART Part Name Specification Outer cap Inner cap Fit all sizes Straw Straw holder Small for XS & S Bottle Large for M & L XS & M size Spacer S & L size XS & S size Decorate M &... -
Page 25: Aero Vault Stem Hydration Assembly
Aero Vault Stem Hydration Assembly Assemble straw and cover on the bottle Assemble latch and S-type parts to the upper stem with M5 screws, locking torque Assemble spacer with M3 screws in the Slide bottle into the spacer and fixed to bottle bracket the latch then it can be used Assemble bottle bracket in lower stem... -
Page 26: Aero Vault Down Tube Bottle Assembly
Aero Vault Down tube Bottle Assembly Assemble cage at the down tube with M5 Hexagon socket countersunk head screws. Slide bottle into bottle cage. Version 9 /2015...
