Giant TRANSEND DX W Datasheet

132
TRANSEND
DX W
Specifications
SIZES 14(XS),16(S),18(M), 20(L)
COLORS Blue
FRAME ALUXX-Grade Aluminum
FORK Alloy, Straight Blade
SHOCK N/A
HANDLEBAR Alloy Low Rise, 19 Degree Sweep, 25.4
STEM Alloy,17 Degree Rise
SEATPOST Alloy, 27.2
SADDLE Giant Venture W, SuperSoft Reflective
PEDALS Alloy/Kraton Comfort Platform
SHIFTERS
Shimano EF-50 EZ-Fire
FRONT DERAILLEUR Shimano C102
REAR DERAILLEUR Shimano Alivio
BRAKES Alloy Direct-Pull
BRAKE LEVERS Shimano EF-50
CASSETTE SRAM PG820 11x30, 8-speed
CHAIN KMC Z72, Nickel Plated
CRANKSET Alloy 3-Piece, 28/38/48
BOTTOM BRACKET Sealed Cartridge
RIMS Alloy, Double Wall
HUBS Alloy, 32h
SPOKES Stainless Steel
TIRES Kenda Kwick Trax, 700x35, Shielded
Rear Alloy Rack, Fenders,
EXTRAS
Kickstand, Bell
Specifications and availability subject to change without notice.
A PERFECT FRIEND IN THE CITY. STYLISH,
DEPENDABLE AND ALWAYS READY FOR THE
DAILY COMMUTE.
Frame Technology
Breeze through the traffic and get where you're going in comfort and style. A lightweight
aluminum frame and fast 700c wheels keep you rolling. The comfortable saddle, upright
positioning and handy racks make mundane trips fun.
Key Upgrades (over TranSend W)
— Alloy fork provides light weight and around-town steering precision
— 24-speed drivetrain to tackle the urban jungle
— Fenders, bell and rear rack for comfort, safety and convenience
frame geometry
Actual Part Head Seat
Frame Size Number Angle Angle*
inches degrees degrees
XS 14 357362 70.0 74.0
S 16 357363 70.0 73.0
M 18 357364 71.0 73.0
L 20 357365 71.0 73.0
*Seat angle is actual
**Toptube is measured from the center of the headtube horizontally back to the top of the effective extension of the seattube
***Standover height is based on the largest size tire that will fit the bike, not necessarily the included size tire
Toptube** Headtube Chainstay Wheelbase
inches inches inches inches
21.4 6.3 17.8 41.6
22.1 6.3 17.8 41.8
22.6 6.3 17.8 42.3
23.6 6.3 17.8 42.3
Standover
Height***
inches
22.1
22.7
23.5
24.2
