TECHNICAL SPECIFICATIONS
PORTS
• 1 x ADSL Line port RJ-11 • 1 x Telephone Line port RJ-11
• 2 x Telephone Handset ports RJ-11
• 4 x LAN port RJ-45 IEEE 802.3 10/100 Base-T, Auto-crossing
WAN / LAN INTERFACE
• G.992.5 (ADSL2+) • G.992.3 (ADSL2)
• G.992.1 • G.992.2
• ANSI T.413 Issue 2 • ATM QoS (UBR, CBR, VBR)
• Multiple PVCs (up to 8 supported)
• F4/F5 OAM Loop-backs / Send & Receive
• AAL ATM Attributes - AAL5 • ATM UNI support: UNI3.1/4.0
ENCAPSULATION SUPPORT
• PPPoE (RFC2516) • RFC 2684 (RFC 1483) Bridge
• PPPoA (RFC2364) • RFC 2684 (RFC 1483) Route
• Classical IP over ATM (RFC1577)
NETWORK SUPPORT
• Port forwarding rules for popular games / applications
• Static IP, dynamic RIP v1 / v2 routing support
• ARP
• IP/TCP/UDP/ICMP/ARP protocol support
• Network Address Translation (NAT)
• Port Address Translation (PAT)
• Port Triggering • DMZ host
• Transparent bridging & learning (IEEE 802.1d)
• IGMP Proxy • IGMP Snooping
• DHCP Server/Client/Relay • DNS
• Authentication protocols: CHAP / PAP
• VPN (IPSec / PPTP / L2TP) pass-through
• QoS: Layer 3 policy-based / IPQoS / ToS (Type of Service)
APPROVALS
• A-Tick N367
VoIP
• 2 x FXS, 1 X FXO • SIP (RFC3261)
• RTP (RFC1889) • Codec: G.711, G.723.1, G.729ab
• On/Off Hook Caller ID (ETSI based)
• Lifeline • SDP (RFC2327)
• Echo cancellation (G.168) • Silence suppression
SECURITY
• Stateful Packet Inspection (SPI)
• Packet filtering • Traffic conditioning
• Denial of Service (DoS) protection
• WFQ-based bandwidth management (Congestion management)
• HTTP proxy • Parental control
• Access Control • IP filtering
• MAC filtering
WIRELESS
• IEEE 802.11g/54Mbps, backward compatible with 802.11b
• Encryption: 64, 128-bit Wired Equivalent Privacy (WEP), Wi-fi
Protected Access (WPA)
• 802.1x RADIUS Authentication
• Channels: 13 Channels (Australia)
• Data Rate: Up to 11g/54Mbps
• 10, 25, 50, 100mW @ 22MHz channel bandwidth output power
level adjustments
• MAC Address Filtering • XPress TM Technology
• 54g Mode • Wi-Fi Multimedia (WMM)
TM
• Wireless Bridge (WDS) • AP Isolation
LED
• Power, ADSL, Line, Phone1, Phone2, LAN 4, LAN 3, LAN2,
LAN1, WLAN, Internet
DIMENSIONS
• 227 mm (W) x 40 mm (H) x 144 mm (D)
MANAGEMENT SUPPORT
• Web-based GUI (LAN or remote)
• 'root', 'support', 'user' access rights
• SNMP agent • SNTP client
• ILMI 4.0 • TR069
• Configuration backup and restoration
• Syslog (remote / local)
• Software upgrade via TFTP, FTP
• Local firmware upgrade via HTTP (Web GUI)
• Telnet • SSH
• Diagnostics report with troubleshooting help
ENVIRONMENTAL CONDITIONS
• Operating temperature 0 ~ 50°Celsius
• Relative humidity 5 ~ 90% (non-condensing)
POWER SUPPLY
• External power adapter 240 VAC (input) ~ 15VDC/1.6A (output)
PACKAGE CONTENTS
• NB9WMAXX ADSL2+ Modem Router
• 15VDC 1.6 Amps power supply
• RJ-11 ADSL Line connection cable
• RJ-45 10/100 Ethernet cable
• Driver/Manual & Utility Software CD
• Quick Start Guide
NetComm NB9WMAXX
ADSL2+ Wireless Broadband Modem Router with VoIP Gateway
NB9WMAXX MAXX Modem Router
•
Full featured ADSL2+ Broadband Modem
• Integrated VoIP Router and 11g/54Mbps Wireless Access Point
• Choose to call out on either your VoIP or Landline Telephone service
• QoS (Quality of Service) Layer 3 Router to maintain VoIP call quality
•
2 FXS Ports, 1 FXO Port (Lifeline) and 4-Port LAN Switch
• PSTN Lifeline support^
• Day-Time parental Control
• Supports advanced Call services – Caller ID, Call On-Hold, Call Forward, Call Waiting and Transfer
– service provider dependent†
• Simple Web based setup and configuration
• Xpress™ Wireless Booster functionality
^NetComm will not accept responsibility for failed Lifeline support.
†Note: The availability of some listed call features are dependent on the services supported by your VoIP service provider. Please consult them
for further information.
1 or 2 Analogue
Telephones
Computer connected
via Ethernet
Computer connected
via Ethernet
Your NetComm dealer:
NETCOMM LIMITED PO Box 1200, Lane Cove NSW 2066 Australia
ABN 85 002 490 486
P: 02 9424 2070 F: 02 9424 2010 E: sales@netcomm.com.au W: www.netcomm.com.au
Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Specifications are
subject to change without notice. Images shown may vary slightly from the actual product.
Laptop Computer
connected wirelessly
Telephone
Socket
ADSL/Modem
Phone
Computer connected
via Ethernet
Computer connected
via Ethernet
RJ-11 Telephone line
RJ-45 Ethernet cable
