Operating and installation instructions Ceramic cooktops with induction To prevent the risk of accidents or damage to the appliance, it is essential to read these instructions before it is installed and used for the first time. en-AU, NZ M.-Nr. 10 032 900...
Contents Warning and Safety instructions................ 4 Caring for the environment ................ 15 Overview....................... 16 Cooktop......................... 16 Controls / Indicators....................17 Cooking zone data ....................19 Using for the first time .................. 20 Cleaning the cooktop for the first time..............20 Switching on the cooktop for the first time ............
Page 3
Safety instructions for installation.............. 47 Safety distances .................... 48 Cooktops with frame or bevelled edge ............. 50 Installation notes ....................50 Building-in dimensions..................51 KM 6366-1...................... 51 Installation ......................52 Flush-fitted cooktops.................. 53 Installation notes ....................53 Building-in dimensions..................54 KM 6367-1......................
They contain important notes on installation, safety, use and maintenance. Miele cannot be held liable for non- compliance with these instructions. Keep these instructions in a safe place and ensure that new users are familiar with the contents.
Page 5
This cooktop is not suitable for outdoor use. It is intended only to cook food and keep it warm. Any other use is not supported by Miele and could be dangerous. This appliance is not intended for use by persons (including...
Page 6
Warning and Safety instructions Safety with children Young children must not be allowed to use this appliance. Older children may only use the appliance when its operation has been clearly explained to them and they are able to use it safely, recognising the dangers of misuse.
Page 7
Repairs and other work by unqualified persons could be dangerous. Installation, maintenance work and repairs to electrical appliances must only be carried out by a Miele approved service technician. A damaged appliance is dangerous. Check it for any visible damage.
Page 8
The manufacturer's warranty will be invalidated if the appliance is not repaired by a Miele approved service technician. Faulty components must only be replaced by genuine Miele spare parts. The manufacturer can only guarantee the safety of the appliance when Miele replacement parts are used.
Page 9
Warning and Safety instructions If the cooktop is installed behind a furniture panel (e.g. a door), ensure that the door is never closed whilst the cooktop is in use. Heat and moisture can build up behind a closed furniture panel and cause subsequent damage to the cooktop, the housing unit and the floor.
Page 10
Warning and Safety instructions Correct use The cooktop gets hot when in use and remains hot for a while after being switched off. There is a danger of burning until the residual heat indicators go out. Due to the high temperatures radiated, objects left near the cooktop when it is in use could catch fire.
Page 11
Warning and Safety instructions When the appliance is switched on either deliberately or by mistake, or when there is residual heat present, there is the risk of any metal items left on the cooktop heating up, with the danger of burning.
Page 12
Warning and Safety instructions Pans which boil dry can cause damage to the ceramic glass. Do not leave the cooktop unattended whilst it is being used. Only use pots and pans with smooth bases. Rough bases will scratch the ceramic glass. ...
Page 13
Warning and Safety instructions Do not use two pans on a cooking zone, extended zone or PowerFlex zone at the same time. If the pan only partially covers the cooking zone, the handle could become very hot. Ensure that you always place the pan in the middle of the cooking zone.
Warning and Safety instructions Cleaning and care Do not use a steam cleaning appliance to clean this appliance. The steam could reach the electrical components and cause a short circuit. If the cooktop is built in over a pyrolytic oven, the cooktop should not be used whilst the pyrolytic process is being carried out, as this could trigger the overheating protection mechanism on the cooktop (see relevant section).
Caring for the environment Disposal of the packing Disposing of your old material appliance The transport and protective packaging Electrical and electronic appliances has been selected from materials which often contain materials which, if are environmentally friendly for handled or disposed of incorrectly, disposal, and can normally be recycled.
Overview Cooktop a PowerFlex cooking zone with TwinBooster b PowerFlex cooking zone with TwinBooster ab can be combined to form PowerFlex cooking area c PowerFlex cooking zone with TwinBooster cf can be combined to form PowerFlex cooking area d PowerFlex cooking zone with TwinBooster de can be combined to form PowerFlex cooking area e PowerFlex cooking zone with TwinBooster f PowerFlex cooking zone with TwinBooster...
Overview Controls / Indicators Sensor controls a For switching the cooktop on/off b For activating/deactivating Stop & Go ab For activating/deactivating the system lock c Timer Switching on and off - For switching between timer functions - For selecting a cooking zone (see "Switching a cooking zone off automatically") d For setting a minute minder / switch-off time...
Page 18
Overview e For switching the keeping warm function on and off f For selecting the power setting g For switching the PowerFlex cooking area on/off Indicator lights h The system lock has been activated k Timer i Cooking zone display ...
Using for the first time Please stick the extra data plate for Switching on the cooktop for the appliance supplied with this the first time documentation in the space provided The metal components have a in the "After sales service, data plate, protective coating which may give off a warranty"...
Induction The induction principle When the appliance is switched on either deliberately or by mistake, An induction coil is located under each or when there is residual heat cooking zone. When a cooking zone is present, there is the risk of any metal switched on, this coil creates a items placed on the cooktop (e.g.
Induction Noises When using an induction cooking zone, the following noises can occur in the pan, depending on what it is made of and how it has been constructed. On the higher power settings, it might buzz. This will decrease or cease altogether when the power setting is reduced.
Induction – Lift pans into position on the Pans cooktop. Sliding them into place can Suitable pans: cause scuffs and scratches. – Stainless steel pans with a base that – Often the maximum diameter quoted can be magnetised. by manufacturers refers to the diameter of the top rim of the pot or –...
Tips on saving energy – Use a lid whenever possible to minimise heat loss. – Select a smaller pan when cooking small quantities. A smaller pan uses less energy than a larger pan with very little in it. – Cook with as little water as possible. –...
Power level range Settings Melting butter 1–2 Dissolving gelatine Making milk puddings Warming small quantities of liquid Cooking rice Defrosting frozen vegetables Cooking pulses Warming liquid and semi-solid foods Making omelettes or lightly frying eggs Steaming fruit Cooking pasta Steaming vegetables, defrosting fish and reheating frozen food Bringing large quantities of food to the boil, e.g.
Operation Operating principles The glass ceramic cooktop is equipped with electronic sensor controls which react to finger contact. For safety reasons, in order to switch the cooktop on, the On/Off sensor needs to be touched for a little longer than the other sensors.
Operation Residual heat indicator Fire hazard! Do not leave the cooktop unattended If a cooking zone is still hot, the residual whilst it is being used. heat indicator will light up after it has Please note that the heating up time been switched off.
Operation PowerFlex cooking area The PowerFlex cooking zones can be combined to form a PowerFlex cooking area (see "Overview - Cooktop"). Settings for the cooking area are controlled by the front or left PowerFlex cooking zone. Switching on Touch the or sensor. ...
Operation Auto heat-up Continued Heat-up time cooking setting [min : sec] When Auto heat-up has been activated, the cooking zone switches on approx. 0 : 15 automatically at the highest setting and approx. 0 : 15 then switches to the continued cooking setting which you have previously approx.
Operation Cooking zones are networked in pairs Booster to supply the power for the Booster The cooking zones are equipped with a function. When the Booster function is Booster or TwinBooster (see "Overview selected, a proportion of energy is – Cooktop"). You can use the Booster taken away from the linked cooking function for a maximum of two cooking zone and the following happens within...
Page 31
Operation Switching on the Booster Switching off the Booster / TwinBooster Touch the 9 sensor twice for the Select a different power setting. cooking zone you wish. will appear in the cooking zone display. Switching on the TwinBooster, level 1 ...
Operation Switching the keeping warm setting Keeping warm on/off The keeping warm function is not Touch the sensor for the required designed to reheat food from the cold cooking zone. state. It is only for keeping food warm directly after cooking. If the keeping warm function has been activated, the cooking zone will switch off automatically after a maximum of 2...
Timer Switching a cooking zone off You can select a time up to a automatically maximum of 99 minutes. You can set a time after which the The timer can be used for two different cooking zone will switch off functions: automatically.
Timer If you want to show the times remaining Using both timer functions at which are counting down in the the same time background: The minute minder and automatic Touch the sensor repeatedly until switch-off functions can be used at the the display you require appears.
Additional functions Stop & Go Recall When Stop & Go is activated, the power If the cooktop is switched off in error of all cooking zones in use is reduced to during operation, this function can be power setting 1. used to reset all settings to the way The cooking zone power settings and they were.
Safety features System lock The system lock is deactivated if there is an interruption to the power supply. Your cooktop is equipped with a system lock to prevent it being switched on by mistake. If an unavailable sensor is touched whilst the system lock is activated, ...
Safety features Safety switch-off Safety switch-off with an overlong cooking time The safety switch-off mechanism is triggered automatically if one of the cooking zones is heated for an unusually long period of time. This period of time depends on the power setting selected.
– The set power level will be reduced. If, despite removing the cause, the – The cooking zone will switch off overheating protection mechanism automatically. will flash in the triggers again, contact Miele. display.
Cleaning and care Clean the entire cooktop after each use. Danger of burning! Allow it to cool down before cleaning. The cooking zones must be switched Dry the appliance after using water to off. The cooktop needs to cool clean it.
Page 40
(spots with a glass-ceramic surface and the frame metallic appearance) can be removed or the frame and the worktop with using the Original Miele ceramic and sharp, pointed objects. stainless steel cooktop cleaner. This could damage the seals.
Problem solving guide With the aid of the following guide, minor problems can be easily corrected without contacting Miele. If, after reading this guide, you can't remedy the problem yourself, please call Miele (see back cover for details). Please note, however, that a call-out charge will be applied to unnecessary service visits where the problem could have been rectified as described in these operating instructions.
Page 42
Problem solving guide Problem Possible cause and remedy After switching the The system lock has been activated. cooktop on, appears You need to deactivate the system lock (see in the timer display for "System lock"). several seconds. The symbol appears One or several of the sensors are covered, for in one or more cooking example, by finger contact, food boiling over or by an...
Page 43
and numbers are The cooktop is incorrectly connected. flashing in the cooking Contact Miele or a qualified electrician. The zone displays and a cooktop must be connected to the mains tone sounds. according to the wiring diagram.
250 ml appliance. These can be ordered online at: Removes heavy soiling, limescale deposits and aluminium residues. or from Miele (see end of this booklet Original Miele all purpose microfibre for contact details). cloth Saucepans and frying pans Miele offer a wide range of pans which are perfect for Miele cooktops.
Con@ctivity Your cooktop is communication Further information regarding enabled and via the dongle supplied Con@ctivity is available on the internet with selected rangehoods can and in the instruction manuals of the communicate with the rangehood various components. (Con@ctivity). The cooktop sends information on its operating status to the rangehood.
Page 46
Con@ctivity Signing on If you want to sign on your cooktop to the Con@ctivity system, you will first need to sign on the rangehood. Disconnect the cooktop from the mains electricity supply. Connect the dongle to the cooktop (see the installation instructions for the dongle).
Safety instructions for installation The appliance must only be installed and connected to the electricity supply by a suitably qualified and competent person in strict accordance with current national and local safety regulations. Fit the wall units and rangehood before fitting the cooktop to avoid damaging the cooktop.
Safety distances Safety distance above the cooktop A minimum safety distance must be maintained between the cooktop and the rangehood above it. See the rangehood manufacturer's operating and installation instructions for details. If the manufacturer's instructions are not available for the rangehood, a minimum safety distance of 600 mm must be maintained.
Page 49
Safety distances Safety distances to the sides Minimum safety distances and back of the cooktop underneath the cooktop Ideally the cooktop should be installed To ensure sufficient ventilation to the with plenty of space on either side. cooktop, a certain gap must be left There may be a wall at the rear or a tall between the underside of the cooktop unit or wall on one side (right or left),...
Cooktops with frame or bevelled edge Tiled worktop Installation notes Seal between the cooktop and the worktop Grout lines and the hatched area underneath the cooktop frame must be smooth and even. If they are not, the cooktop will not sit flush with the worktop and the sealing strip Do not use sealant between the underneath the cooktop will not provide...
Cooktops with frame or bevelled edge Building-in dimensions KM 6366-1 a Front b Building-in depth c Mains connection box d Con@ctivity connection The mains connection cable (1440 mm long) is supplied separately with the cooktop.
Cooktops with frame or bevelled edge Installing the cooktop Installation Feed the mains connection cable Preparing the worktop down through the cut-out. Make the worktop cut-out as shown Place the cooktop centrally in the in "Building-in dimensions". Observe cut-out.
Flush-fitted cooktops The cooktop can be installed Installation notes – in a suitable cut-out in a natural stone Flush fit cooktops are only suitable for worktop. installation in natural stone (granite, marble), tiled or solid wood worktops. – in a suitable cut-out in a tiled or solid Certain models are suitable for wood worktop with a wooden building into glass worktops - please...
Flush-fitted cooktops Building-in dimensions KM 6367-1 a Front d Stepped cut-out b Building-in depth e Con@ctivity connection c Mains connection box The mains connection cable (1440 mm long) is supplied separately with the cooktop. Cut-out dimensions for granite or marble worktops. Please take careful note of the inset diagram.
Flush-fitted cooktops Solid wood / tiled / glass worktops Installation Granite and marble worktops a Worktop b Cooktop a Worktop c Gap b Cooktop d Wooden frame 13 mm (not supplied c Gap with appliance) As the ceramic glass and the worktop As the ceramic glass and the worktop cut-out have a certain dimensional cut-out have a certain dimensional...
Page 56
Flush-fitted cooktops Preparing the worktop Make the worktop cut-out as shown in "Building-in dimensions". Observe the safety distances (see "Safety distances"). Solid wood, tiled and glass worktops: Fix the wooden frame 7 mm below the top edge of the worktop (see diagram).
AC 230 V, 50 Hz repair work is dangerous to users. The voltage and rated load are given on Miele cannot be held liable for the data plate. Please ensure these damage or injury caused by incorrect match the household mains supply.
If the mains cable needs to be replaced, it must be replaced with a special connection cable, type H 05 VV-F (PVC insulated), available from Miele. The connection data is given on the data plate. Wiring diagram a b c d e...
After sales service, data plate, warranty After sales service In the event of any faults which you cannot easily remedy, please contact Miele. See back of this booklet for contact details. Please quote the model and serial number of your appliance when contacting Miele.
Page 63
Freemans Bay, Auckland 1011 Miele Experience Centre South Melbourne: 206-210 Coventry Street Miele Experience Centre South Melbourne, VIC 3205 Auckland: Miele Experience Centre and Office Sydney: 8 College Hill 3 Skyline Place Freemans Bay, Auckland 1011 Frenchs Forest, NSW 2086 Telephone:...
Page 64
KM 6366-1 / KM 6367-1 en-AU, NZ M.-Nr. 10 032 900 / 01...
