Typical set-up time 5 – 10 minutes
Where to put the terminal
x
Although the VeriFone V 670 GPRS terminal is mobile,
we recommend best practices such as:
• Do not leave it in direct sunlight or inside vehicles
in extreme temperatures
• Avoid excessive dust and liquid submersion
• Avoid radiant heat
• Avoid close proximity to other devices using magnetic force or
similar frequencies
GPRS signal strength
Certain environmental factors, such as concrete walls and other
devices that use the same frequency, can have an impact on the
signal quality of the GPRS network. For best results, insure your
device is not in close proximity to any other GPRS or electronic
devices emanating magnetic fields. The SIM card in your device
is activated to work on the Rogers GPRS network in Canada,
so be sure the area where you will be using your terminal is
within the coverage area (validate online at
http:/ /www.rogers.com/web/content/wireless_network). If
you need to travel outside of Canada, please contact your POS
terminal help desk or customer service for assistance.

Loading the paper

Turn the terminal over, pop the printer cover's latch, and lift the
cover. Load a roll of paper (2 "-width thermal receipt paper of up
to 60 feet) into the printer. The thermal print side of the paper will
feed out facing the operator. Close the cover and tear off any
excess paper.
6

Charging the terminal

Insert charging
cable here
• Connect the two pieces of the AC power supply
• Connect the terminal charging cable to the power supply.
• Connect the charging cable (similar to a cell phone charger)
into the charging port at the bottom of the terminal on the
left hand side.
• Plug the power adapter into a surge protector (strongly
recommended) or a standard 120V electrical outlet
• The device status indicator will glow amber/orange
when charging
