Assembly And Installation Instructions
LEAVE THESE INSTRUCTIONS WITH THE OWNER.
If this fireplace is not properly installed, a house fire may result. To reduce the
risk of fire, follow the installation instructions. Contact local building or fire
officials about restrictions and installation inspection requirements in your
area.
This stove must be connected to (1) a chimney complying with the require-
ments for Type HT chimneys in the Standard for Chimneys, Factory-Built,
Residential Type and Building Heating Appliance, UL 103, or (2) a code-
approved masonry chimney with a flue liner.
Please read this entire manual before you install and use your new fireplace.
Failure to follow instructions may result in property damage, bodily injury, or
even death.
Malm Fireplaces, Inc.
Malm Fireplaces, Inc.
Malm Fireplaces, Inc.
Malm Fireplaces, Inc.
Malm Fireplaces, Inc.
368 Yolanda Avenue
Santa Rosa, Ca 95404
(707) 523-7755 - Fax: (707) 571-8036
Zircon 30
Tested to U/L Standard 737 & 1482
SAFETY NOTICE
DO NOT INSTALL THIS UNIT IN A MOBILE HOME.
Advertisement
Table of Contents
Related Manuals for Malm Fireplaces Zircon 30
Summary of Contents for Malm Fireplaces Zircon 30
-
Page 1: Assembly And Installation Instructions
Malm Fireplaces, Inc. Malm Fireplaces, Inc. Malm Fireplaces, Inc. Malm Fireplaces, Inc. Malm Fireplaces, Inc. 368 Yolanda Avenue Santa Rosa, Ca 95404 (707) 523-7755 - Fax: (707) 571-8036 Zircon 30 Tested to U/L Standard 737 & 1482 Assembly And Installation Instructions LEAVE THESE INSTRUCTIONS WITH THE OWNER. -
Page 2: Hearth Requirements
ASSEMBLY AND INSTALLATION INSTRUCTIONS 1. Carefully remove all components from the shipping cartons and inspect for damage. If any damage is noted contact the shipping company or your dealer immediately. DO NOT INSTALL THIS UNIT IF DAMAGED OR MISSING PARTS. 2. -
Page 3: Corner Installation
CLEARANCES CORNER INSTALLATION SIDEWALL AND BACKWALL INSTALLATION Unit to Adjacent Wall ------------------------------ 16" Unit to Sidewall ----------------------------------- 32" Connector to Adjacent Wall ----------------- 23 1/2" Unit to Backwall ----------------------------------- 16" Center of Connector to Adjacent Wall --------- 27" Connector to Sidewall ---------------------- 43 1/2" Center of Connector to Sidewall -------------- 47"... -
Page 4: Chimney Connector Installation
ASSEMBLY AND INSTALLATION INSTRUCTIONS Continued DO NOT CONNECT THIS UNIT TO A CHIMNEY FLUE SERVING ANOTHER APPLIANCE. This stove must be connected to (1) a chimney complying with the requirements for Type HT chimneys in the Standard for Chimneys, Factory-Built, Residential Type and Building Heating Appliance, UL 103, or (2) a code-approved masonry chimney with a flue liner. -
Page 5: Material List
Chimney Connector Instructions Insulated Pipe Type HT Ceiling Chimney System Single Wall Chimney Adapter Sheet Metal Screw - 3 Slip Connector. Sheet Minimum Metal Screw to Chimney Connector. Slip Connector Dura-Vent Universal Middle Pipe Section Bottom Fits Into Damper Section Adapter, Security UP Adapter, Metalbestos DS- CPA ,Or Single Wall... - Page 6 2" Clearance From Studs To Chimney Wall Header 12" Of Brick From Liner To Combustibles 5/8" Fireclay Liner Minimum or Equivalent 12" Minimum Sill/Support 12" Minimum MASONRY THIMBLE Figure 4 Page - 6...
-
Page 7: Operating Instructions
OPERATING INSTRUCTIONS Failure to properly use and maintain this appliance may void the manufacturer's warranty and could result in a house fire. CAUTION: HOT WHILE IN OPERATION. DO NOT TOUCH. KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. CONTACT MAY CAUSE SKIN BURNS. SEE NAMEPLATE AND INSTRUCTIONS. Do Not over fire. If any portion of the unit or flue starts to glow you are over firing. -
Page 8: Maintenance Instructions
NFPA is Batterymarch Park, Quincy, MA 02269. File these instructions for future reference. NEVER STORE OR ALLOW PAPERS, KINDLING, FIREWOOD OR ANY OTHER COMBUSTIBLES WITHIN 48 INCHES OF UNIT. Malm Fireplaces, Inc. Malm Fireplaces, Inc. Malm Fireplaces, Inc. Malm Fireplaces, Inc.
