6 S P E C I F I C A T I O N S
This section provides technical information about the MultiSync LT81/LT100 Projector's performance.
Optical
TM
DMD
Lens
Lamp
Image Size
Projection Distance
Electrical
Inputs
Video Bandwidth
Color Reproduction
Horizontal Resolution
Power Requirement
Input Current
Mechanical
Dimensions (LT81)
Dimensions (LT100)
Net Weight
Operational Temperatures
Regulations
Single Chip Digital Micromirror Device(DMD
Manual zoom, manual focus
F 2.44 f =26-30 mm
Metal halide lamp 280 W
610-7620 mm (24-300 inches) diagonal
1.2 – 12.3m
Video (NTSC / PAL / SECAM / NTSC 4.43)
RGB LT81: (H : 15 – 60 kHz, V : 50 – 85 Hz)
LT100: (H : 15 – 85 kHz, V : 50 – 85 Hz)
RGB: 60 MHz
Full color, 16.7 million colors simultaneously.
NTSC / YCbCr 550 (LT81 : 500), PAL 350, SECAM 350, NTSC4.43 350 TV lines
RGB LT81: 800 dots horizontal, 600 dots vertical
LT100: 1024 dots horizontal, 768 dots vertical
100 – 120 / 220 – 240 VAC, 50 / 60 Hz
4.6 A (100 – 120 VAC) / 2.2 A (220 – 240 VAC)
9.7" (W) 5.1" (H) 12.8" (D) / 246 mm (W) 130 mm (H) 325 mm (D) (Including lens hood and feet)
9.7" (W) 5.1" (H) 12.7" (D) / 246 mm (W) 130 mm (H) 310 mm (D) (Not including lens hood)
9.8" (W) 5.6" (H) 13.4" (D) / 250 mm (W) 142 mm (H) 340 mm (D) (Including lens hood and feet)
9.8" (W) 5.6" (H) 12.6" (D) / 250 mm (W) 142 mm (H) 320 mm (D) (Not including lens hood)
LT81: 9.9 lbs / 4.5 kg
LT100: 10.8 lbs / 4.9 kg
Projector: 41 – 95 F (5 to 35 C), 30 – 85% humidity
Remote control: 32 – 140 F (0 to 60 C)
Remote mouse receiver: 32 – 140 F (0 to 60 C)
UL Approved (UL 1950, CSA 950)
Meets DOC Canada requirements
Meets FCC Class A requirements
TM
), 800 600 dots (LT81) / 1024 768 dots (LT100)
Digital Light Proccessing, DLP, Digital Micromirror
Device and DMD are trademarks of Texas Instruments.
93
