Page 1: Table Of Contents
List of contents List of contents Page Elementary operator control Installation notes Installation 5 - 6 Connecting up Heating cycle setting/assembly Fitting/replacing the battery Setting the correct time Setting the switching times Setting the temperature levels Manual switch/operating modes Technical data Problems and remedies Cleaning and maintenance Service addresses... -
Page 2: Elementary Operator Control
2. Elementary operator control This room thermostat clock creates comfortable room temperatures in the simplest way possible. The two temperature levels = Comfort temperature = Lower temperature are set with the according knobs. Settings between 5 °C and 30 °C possible. manual switch can be used to switch between three operating modes: Operating mode = Automatic... -
Page 3: Installation Notes
3. Installation notes Assembly/installation should only be carried out by qualified person exercising due care. Switch off the heating system before assembly. Check and make sure that the connection wires are not live. Assembly note: – only use PVC-sheathed cables (solid wire) during installation –... -
Page 4: Installation
3.1 Installation Open the battery compartment lid and release the catch Remove the famoso from its base... - Page 5 3.1 Installation Feed the connection wires through the opening in the unit’s base max. 3,5 mm Attach the base on a firm surface or surface-mounted socket...
-
Page 6: Connecting Up
3.2 Connecting up The unit must be connected by a qualifeid person exercising due care. max. 2,5 mm max. 2,5 mm Check and make sure that the connecting wires are not live. Strip the connection wires properly and connect as shown in the circuit diagram. -
Page 7: Heating Cycle Setting/Assembly
3.3 Heating cycle setting/assembly The heating-cycle setting (CDF value) is for adapting to the control range. This is affected by: – Room size – Type of heating, e. g. convectors, storey heating – Type of assembly – Temperature control/thermostat The set value can be altered to achieve an optimum heating control. -
Page 8: Fitting/Replacing The Battery
4. Fitting/replacing the batteries Open the battery compartment lid Fit the batteries Battery type LR6/AA (2 batteries) Close the battery compartment lid... -
Page 9: Setting The Correct Time
5. Setting the correct time/weekday Type 600 day time switch Type 650 week time switch Slide the cover upwards and remove. Only turn in the direction of the arrow Day time switch e. g. 14.00 h Turn the ring in the direction of the arrow until the desired hour is aligned with the locating arrow. -
Page 10: Setting The Switching Times
6. Setting the switching times 6.1 Switching times for changing temperatures with the day time switch (famoso 600) e. g. 06.00 – 22.00 hours = Comfort- temperature e. g. 22.00 – 06.00 hours = Lower temperature Inside segments = Lower... -
Page 11: Setting The Temperature Levels
7. Switching the temperatures on/off The two temperature values – desired temperatures are set independently of each other. Comfort temperature e. g. +22 °C Lower temperature e. g. +15 °C ❄ Frost protection = +5°C... -
Page 12: Manual Switch/Operating Modes
8. Manual switch/operating modes manual switch selects on of three operating modes: Operating mode = Automatic The unit operates during the set times and switches between Continuous temperature operating modes = Comfort temperature = Lower temperature The selected temperature remains until a different operating mode is selected. -
Page 13: Technical Data
9. Technical data Dimensions H x W x D (mm) 158 x 75 x 36,5 Operating modes Automatic mode Operating voltage battery, type LR6/AA (2 batteries) Comfort temperature Switching capacity – at ohmic loads 5 A/250 V~ Lower temperature – at inductive loads 1 A/250 V~ cos ϕ... -
Page 14: Problems And Remedies
10. Problems and remedies Problems: Remedy: Page The room is too hot or cold Check temperature settings The heating system does not switch Check time and switching 10, 11 on or off on time time The heating system does not switch Check the manual switch on or off Unit is switched to continuous mode... -
Page 15: Cleaning And Maintenance
11. Cleaning and maintenance Use a dry cloth to clean the unit. Never use any caustic cleaning agents. 12. Service addresses GRÄSSLIN GmbH & Co. KG FEINWERKTECHNIK Postfach 1232 D-78104 St. Georgen/Schw. Telefon (07724) 933-0 Telefax (07724) 933-240... -
Page 16: Alphabetical Subject-Index
13. Alphabetical subject-index Key word Page Automatic mode 3 / 11 / 13 Battery CDF value Cleaning and maintenance Connections Continuous temperatures Cycle times Diagram Factory settings Faults Frost protection Heating mode 3 / 11 / 13 Heating-cycle setting Installation 5 - 6 Power supply Problems and remedies...
