Specifications

Monitor
Specifications
Picture Tube
Viewable Image Size:
Input Signal
Display Colors
Synchronization
Range
Resolutions Supported
Resolution based on horizontal and
vertical frequencies only
Active Display Area
(Factory Setting)
Active Display Area
(Full Scan)
Power Supply
Current Rating
Dimensions
Weight
Environmental Considerations
Operating Temperature:
Storage Temperature:
Untitled-1
MultiSync
Monitor
Diagonal: 19 inch
18.0 inch
Radius: 1330 mm
Video: ANALOG 0.7 Vp-p/75 Ohms
Sync: Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative) (TTL Level)
Analog input: Unlimited number of Colors
Horizontal: 31 kHz to 92 kHz
Vertical: 55 Hz to 120 Hz
640 x 480 @ 55 to 120 Hz
800 x 600 @ 55 to 120 Hz
832 x 624 @ 55 to 120 Hz
1024 x 768 @ 55 to 112 Hz
1280 x 1024 @ 55 to 85 Hz ..................... NEC cites recommended resolution at
1600 x 1200 @ 55 to 73 Hz
Horizontal: 356 mm/14.0 inches
Vertical: 267 mm/10.5 inches
360 mm/14.2 inches
270 mm/10.6 inches
AC 100 – 120 V/220 - 240 V@, 50/60 Hz
2.0A @ 100 – 120 V/1.0A@ 220-240 V
447 mm (W) x 462 mm (H) x 479 mm (D)
17.6 inches (W) x 18.2 inches (H) x 18.9 inches (D)
23.5 kg
51.8 lbs
0 C to +35 C
Humidity: 30% to 80%
Feet: 0 to 10,000 Feet
-20 C to +60 C
Humidity: 10% to 90%
Feet: 0 to 45,000 Feet
NOTE: Technical specifications are subject to change without notice.
10
® E ™ Notes
900
90 deflection, 0.28 mm trio dot pitch,
medium short persistence phosphor,
multi-layered, anti-static screen coating,
semi-tint screen, Invar Shadow Mask and
OptiClear
Depends on display card used.
Automatically
Automatically
Some systems may not support
all modes listed.
85 Hz for optimal display performance
Dependent upon signal timing used,
and does not include border area.
Dependent upon signal timing used,
and does not include border area.
8
6/15/98, 1:25 PM
® screen surface.
