Harris DX 25U Technical Manual page 117

386 0169 000 ZENER, 1N5352A 15V ESD
398 0019 000 FUSE, FAST CART 2A 250V
398 0020 000 FUSE, FAST CART 3A 250V
402 0129 000 CLIP, 1/4 DIA FUSE
404 0733 000 HEAT SINK
404 0745 000 HEAT SINK FOR DIP IC'S
494 0377 000 CHOKE RF 0.27UH
494 0386 000 CHOKE RF 1.50UH
506 0230 000 CAP .001UF 100VAC 5%
506 0233 000 CAP .1UF 63V 5%
506 0246 000 CAP .47UF 63V 5%
508 0378 000 CAP .22 UF 100V 10%
516 0081 000 CAP, DISC .01UF 1KV 20%
522 0255 000 CAP 15 UF 50V
526 0342 000 CAP 2.7UF 35V 10%
540 1600 011 RES 2.7 OHM 3W 5%
540 1600 017 RES 4.7 OHM 3W 5%
540 1600 201 RES 100 OHM 3W 5%
540 1600 312 RES 3K OHM 3W 5%
540 1600 320 RES 6.2K OHM 3W 5%
542 0060 000 RES 100 OHM 5% 12W
548 2400 101 RES 10 OHM 1/2W 1%
548 2400 230 RES 200 OHM 1/2W 1%
548 2400 301 RES 1K OHM 1/2W 1%
839 7855 099 SCHEMATIC, BUFFER AMP
843 5100 046 PWB, BUFFER AMP
929 9009 198 XFMR
HARRIS P/N DESCRIPTION
354 0309 000 TERM SOLDER
380 0125 000 XSTR, NPN 2N4401 ESD
380 0126 000 XSTR, PNP 2N4403 ESD
380 0653 000 XSTR, NPN MPS6602 ESD
380 0708 000 XSTR MPS6652 40V 1A ESD
382 0171 000 IC 3-TERM POS REG ESD
382 0184 000 IC, 340T-5/7805 +5V REG ESD
382 0291 000 IC, 75188/1488 ESD
382 0415 000 IC, 324 ESD
382 0428 000 IC, LM358 ESD
382 0605 000 IC 7905C ESD
382 0768 000 IC, 74HC00 ESD
382 0781 000 IC, 74HC74 ESD
382 1082 000 *IC, 74HC423 ESD
382 1084 000 IC, LP339N ESD
382 1199 000 IC, LM35 ESD
384 0321 000 DIODE 5082-2800/1N5711 ESD
384 0431 000 RECT. 1N4001 ESD
384 0610 000 LED, GREEN ESD
384 0611 000 LED, RED ESD
384 0612 000 DIODE 1N3070 ESD
Rev.Y1: 5/24/1999
Table 7-8. DRIVER ENC/TEMP - 992 8048 001
WARNING: Disconnect primary power prior to servicing.
1.0 EA CR005
1.0 EA F003
2.0 EA F001 F002
6.0 EA 2#F001 2#F002 2#F003
2.0 EA
1.0 EA #U001
1.0 EA L001
1.0 EA L002
1.0 EA C001
1.0 EA C002
4.0 EA C008 C009 C018 C020
1.0 EA C003
2.0 EA C019 C021
1.0 EA C010
1.0 EA C007
1.0 EA R022
5.0 EA R005 R008 R009 R010 R011
2.0 EA R001 R002
1.0 EA R020
2.0 EA R023 R024
1.0 EA R021
2.0 EA R006 R007
1.0 EA R004
1.0 EA R003
0.0 EA
1.0 EA
1.0 EA T001
QTY/UM REF. SYMBOLS/EXPLANATIONS
14.0 EA TP001 TP002 TP003 TP004 TP005 TP006
TP007 TP008 TP009 TP010 TP011 TP012
TP013 TP014
1.0 EA Q014
1.0 EA Q015
6.0 EA Q001 Q002 Q003 Q004 Q005 Q006
6.0 EA Q007 Q008 Q009 Q010 Q011 Q012
1.0 EA U013
1.0 EA U014
2.0 EA U001
U002
2.0 EA U009 U010
1.0 EA U018
1.0 EA U015
1.0 EA U008
1.0 EA U004
1.0 EA U012
4.0 EA U003 U007 U011 U019
2.0 EA U016 U017
3.0 EA CR015 CR016 CR019
4.0 EA CR008 CR009 CR011 CR013
3.0 EA DS004 DS005 DS006
3.0 EA DS002 DS007 DS008
3.0 EA CR001 CR002 CR012
888-2297-002
Section VII - Parts List
7-11
