Harris DX 25U Technical Manual page 116

DX-25U
494 0398 000 CHOKE RF 10.0UH
494 0402 000 CHOKE RF 22.0UH
500 0852 000 CAP, MICA, 1000PF 500V 5%
500 0902 000 CAP, MICA, 3300PF 500V 5%
506 0245 000 CAP.33UF 63V 5%
516 0375 000 CAP .01UF 50V -20/+80% Z5U
516 0453 000 CAP .1UF 100V 20% X7R
540 1600 209 RES 220 OHM 3W 5%
542 0005 000 RES 5 OHM 5% 8W
546 0295 000 RES 50 OHM 3.25W 5%
548 2400 166 RES 47.5 OHM 1/2W 1%
548 2400 201 RES 100 OHM 1/2W 1%
548 2400 269 RES 511 OHM 1/2W 1%
548 2400 293 RES 909 OHM 1/2W 1%
548 2400 301 RES 1K OHM 1/2W 1%
548 2400 347 RES 3.01K OHM 1/2W 1%
548 2400 365 RES 4.64K OHM 1/2W 1%
548 2400 368 RES 4.99K OHM 1/2W 1%
548 2400 401 RES 10K OHM 1/2W 1%
548 2400 426 RES 18.2K OHM 1/2W 1%
548 2400 466 RES 47.5K OHM 1/2W 1%
548 2400 485 RES 75K OHM 1/2W 1%
548 2400 501 RES 100K OHM 1/2W 1%
548 2400 542 RES 267K OHM 1/2W 1%
548 2400 566 RES 475K OHM 1/2W 1%
548 2400 601 RES 1MEG OHM 1/2W 1%
550 0858 000 POT 5K OHM .5W 10%
550 0958 000 POT 10K OHM 1/2 W 10%
604 1066 000 SW, PC MT SLIDE SPDT
610 0933 000 JUMPER, PWB TEST POINT
610 0980 000 HDR 20C 2ROW RT ANG
610 1001 000 HDR, 10 PIN RTANG
620 0515 000 RECP, SCREW ON SMC
839 7855 004 SCHEM, DRIVER SUPPLY REG
839 7855 030 HEATSINK
843 5100 018 PWB, DRIVER SUPPLY REG
922 0922 156 TRANSFORMER
999 2566 001 HARDWARE LIST
HARRIS P/N DESCRIPTION
380 0586 000 XSTR, MJE200 ESD
380 0587 000 XSTR, MJE210 ESD
380 0665 000 XSTR, MOS FET MTP15N06V ESD
382 1010 000 IC, DS0026CN/MMH0026CP1 ESD
384 0612 000 DIODE 1N3070 ESD
384 0662 000 LED RED ESD
384 0802 000 TRANSZORB, BIPOLAR 18V 5% ESD
7-10
Table 7-7. PWA, BUFFER AMP - 992 8038 001
WARNING: Disconnect primary power prior to servicing.
#Q002 #Q003 #Q004 #Q005 #Q006 #Q007
#Q008
1.0 EA L001
1.0 EA L002
2.0 EA C013 C014
2.0 EA C004 C005
1.0 EA C001
3.0 EA C002
C006 C007
6.0 EA C003 C008 C009 C010 C011 C012
2.0 EA R005 R067
6.0 EA R058 R059 R060 R061 R064 R065
1.0 EA R006
1.0 EA R021
8.0 EA R023 R026 R027 R032 R035 R036 R062 R063
1.0 EA R066
1.0 EA R003
2.0 EA R009 R016
1.0 EA R001
2.0 EA R044 R045
2.0 EA R008 R010
3.0 EA R020 R022 R033
1.0 EA R013
1.0 EA R014
1.0 EA R011
3.0 EA R004 R025 R034
2.0 EA R041 R042
2.0 EA R019 R024
13.0 EA R015 R046 R047 R048
R049 R050 R051 R052 R053 R054 R055 R056
R057
1.0 EA R002
1.0 EA R012
1.0 EA
7.0 EA TP001 TP002 TP003 TP004 TP005 TP006
TP007
1.0 EA J004
2.0 EA J002 J003
1.0 EA J001
0.0 EA
1.0 EA
1.0 EA
1.0 EA T001
1.0 EA
QTY/UM REF. SYMBOLS/EXPLANATIONS
1.0 EA Q001
1.0 EA Q002
2.0 EA Q003 Q004
1.0 EA U001
2.0 EA CR001 CR002
3.0 EA DS001 DS002 DS003
2.0 EA CR003 CR004
888-2297-002 Rev.Y1: 5/24/1999
