Harris DX 25U Technical Manual page 119

550 0858 000 POT 5K OHM .5W 10%
550 0956 000 POT 2000 OHM 1/2W 10%
550 0958 000 POT 10K OHM 1/2 W 10%
604 0904 000 SW, TGL SPDT
604 0905 000 SW, PB MOMENTARY
610 0679 000 PLUG, SHORTING, .25" CTRS
610 0900 000 HEADER 3 CKT STRAIGHT
610 0981 000 HDR 20C 2ROW VERTICAL
610 0998 000 HDR, 6 PIN, PC BD
610 1027 000 HEADER, MALE 12 PIN
612 0904 000 JACK, PC MT GOLD PLATED
612 1184 000 SHUNT JUMPER 0.1" CENTERS
817 2150 007 AIR SENSE ANGLE
839 7855 175 SCHEM, DRIVER ENCODER
843 5100 093 PWB, DRIVER ENCODER
999 2569 001 HARDWARE LIST
HARRIS P/N DESCRIPTION
354 0309 000 TERM SOLDER
358 2399 000 STUD, PC BD 4-40 X 1/2
380 0083 000 XSTR, 2N2369 ESD
382 0360 000 IC, 7915 ESD
382 0783 000 IC, 74HC76 ESD
382 1010 000 IC, DS0026CN/MMH0026CP1 ESD
382 1077 000 IC 301 ANALOG SWITCH SPDT ESD
384 0205 000 DIODE SILICON 1N914/4148 ESD
384 0431 000 RECT. 1N4001 ESD
386 0082 000 ZENER, 1N4744A 15V 1W 5% ESD
386 0093 000 ZENER, 1N4728A 3.3V ESD
386 0135 000 ZENER, 1N4733A 5.1V ESD
386 0429 000 ZENER 1N5346A 9.1V 5W 10% ESD
398 0015 000 FUSE,FAST CART .500A 250V
402 0129 000 CLIP, 1/4 DIA FUSE
404 0513 000 HEAT SINK PA1-1CB
404 0673 000 SOCKET 8 PIN DIP (DL)
404 0674 000 SOCKET 14 PIN DIP (D-L)
404 0675 000 SOCKET IC 16 CONT
404 0790 000 HEATSINK, 8-PIN DIP
414 0087 000 BEAD FERRITE SHIELD
492 0639 000 COIL, VAR 1.44-2.94UH
494 0196 000 CHOKE RF 100UH
500 0812 000 CAP, MICA, 30PF 500V 5%
500 0822 000 CAP, MICA, 75PF 500V 5%
500 0831 000 CAP MICA 250UUF 500V
500 0888 000 CAP, MICA, 3900PF 500V 5%
506 0230 000 CAP .001UF 100VAC 5%
506 0232 000 CAP .01UF 100V 5%
506 0234 000 CAP .0022UF 100V 5%
506 0236 000 CAP .0047UF 100/63V 5%
506 0237 000 CAP .0068UF 100V 5%
Rev.Y1: 5/24/1999
Table 7-9. OSCILLATOR - 992 8069 002
WARNING: Disconnect primary power prior to servicing.
2.0 EA R049 R060
1.0 EA R098
4.0 EA R017 R019 R050 R051
2.0 EA S001 S002
1.0 EA S003
1.0 EA P005
3.0 EA JP001 JP002 JP003
2.0 EA J001 J002
1.0 EA J004
1.0 EA J003
3.0 EA 3#J5
3.0 EA #JP001 #JP002 #JP003
1.0 EA #R091
0.0 EA
1.0 EA
1.0 EA
QTY/UM REF. SYMBOLS/EXPLANATIONS
11.0 EA E001 E002 E003 E004 TP001 TP002 TP003
TP004 TP005 TP006 TP007
2.0 EA #Y001 #Y002
6.0 EA Q001 Q002 Q003 Q004 Q005 Q006
1.0 EA U006
2.0 EA U001 U002
2.0 EA U003 U005
1.0 EA U004
7.0 EA CR002 CR003 CR006 CR007 CR008 CR009
CR010
1.0 EA CR005
1.0 EA CR001
2.0 EA CR011 CR012
1.0 EA CR004
1.0 EA CR013
2.0 EA F001 F002
4.0 EA #F001 #F002
1.0 EA #U006
3.0 EA #S001 #U003 #U005
1.0 EA XU004
2.0 EA XU001 XU002
1.0 EA #U003
2.0 EA L001
L002
1.0 EA L004
1.0 EA L003
2.0 EA C002 C004
1.0 EA C007
1.0 EA C005
1.0 EA C037
7.0 EA C013 C014 C017 C018 C027 C029 C030
2.0 EA C009 C019
1.0 EA C031
1.0 EA C032
1.0 EA C033
888-2297-002
Section VII - Parts List
7-13
