Harris DX 25U Technical Manual page 115

548 2400 205 RES 110 OHM 1/2W 1%
548 2400 212 RES 130 OHM 1/2W 1%
548 2400 218 RES 150 OHM 1/2W 1%
548 2400 251 RES 332 OHM 1/2W 1%
548 2400 269 RES 511 OHM 1/2W 1%
548 2400 301 RES 1K OHM 1/2W 1%
548 2400 334 RES 2.21K OHM 1/2W 1%
548 2400 369 RES 5.11K OHM 1/2W 1%
548 2400 451 RES 33.2K OHM 1/2W 1%
548 2400 530 RES 200K OHM 1/2W 1%
604 0905 000 SW, PB MOMENTARY
610 0679 000 PLUG, SHORTING, .25" CTRS
610 0870 000 PLUG, NON-INS SHORTING
610 0933 000 JUMPER, PWB TEST POINT
610 0981 000 HDR 20C 2ROW VERTICAL
610 0984 000 HDR 34C 2ROW VERTICAL
610 0999 000 HDR, 10 PIN, PC BD
610 1027 000 HEADER, MALE 12 PIN
612 0904 000 JACK, PC MT GOLD PLATED
612 1176 000 DIP STRIP, FEMALE 10 POS
839 7855 174 SCHEM, MOD ENCODER
843 5100 092 PWB, MOD ENCODER
917 2099 051 FIRMWARE, MOD ENCODER, DX25U
HARRIS P/N DESCRIPTION
328 0071 000 WASHER, STEEL COMPRESSION
358 1929 000 JUMPER 1/2 LG 1/8H
358 3314 000 STANDOFF 4-40 X .250 L
380 0414 000 XSTR, 2N3799 ESD
380 0681 000 XSTR IRFP350 ESD
382 0368 000 IC, 78L15AWC VOLTAGE REG. ESD
382 0593 000 IC TL072ACP ESD
384 0205 000 DIODE SILICON 1N914/4148 ESD
384 0731 000 * DIODE, SWITCHING 1N4607 ESD
384 0782 000 RECT, MR754 400V 6A ESD
386 0085 000 ZENER, 1N4740A 10V ESD
386 0090 000 ZENER 1N4756A 47V 5% 1W ESD
386 0164 000 ZENER, 1N4754A 39V ESD
404 0673 000 SOCKET 8 PIN DIP (DL)
410 0413 000 INSULATOR PAD FOR TO-247
Rev.Y1: 5/24/1999
Table 7-6. DRIVER SUPPLY REGULATOR - 992 8006 001
WARNING: Disconnect primary power prior to servicing.
R235 R236 R237 R238 R239 R240 R241 R242
R243 R244 R245 R246 R247 R248 R249 R250
R251 R252 R253 R254 R255 R256 R257 R258
R259 R260 R261 R262 R263 R264 R265 R266
R267 R268 R269 R270 R271 R272 R273 R274
R275 R276 R277 R278 R279 R280
R281 R282 R283 R284 R285 R286 R287 R288
R289 R290
1.0 EA R232
1.0 EA R231
2.0 EA R229 R230
1.0 EA R039
1.0 EA R038
13.0 EA R040 R041 R042 R043 R044 R045 R046 R047
R048 R049 R050 R051 R052
2.0 EA R036 R053
1.0 EA R035
8.0 EA R001 R002 R003 R004 R005 R006 R007 R008
1.0 EA R054
1.0 EA S002
2.0 EA P020 P021
64.0 EA
15.0 EA TP001 TP002 TP003 TP004 TP005 TP006
TP007 TP008 TP009 TP010 TP011 TP012
TP013 TP014 TP015
8.0 EA J001 J002 J003
J004 J005 J006 J007 J008
1.0 EA J017
1.0 EA J019
1.0 EA J018
10.0 EA P010 P011 P012 P015 3#J020 #3J021
10.0 EA
0.0 EA
1.0 EA A014
1.0 EA
QTY/UM REF. SYMBOLS/EXPLANATIONS
7.0 EA #Q002 #Q003 #Q004 #Q005 #Q006 #Q007
#Q008
1.0 EA P001
6.0 EA
1.0 EA Q001
7.0 EA Q002 Q003 Q004 Q005 Q006 Q007 Q008
1.0 EA U001
1.0 EA U002
2.0 EA CR005 CR006
4.0 EA CR001 CR002 CR003 CR004
2.0 EA CR013 CR015
6.0 EA CR008 CR011 CR012 CR014 CR016 CR017
2.0 EA CR009 CR010
1.0 EA CR007
1.0 EA #U002
7.0 EA
888-2297-002
Section VII - Parts List
7-9
