Specifications

MultiSync LCD
1810X
Display 46 cm (18.1 inch) viewable image size; 1280 x 1024
native resolution (Pixel Count); active matrix;
thin film transistor (TFT); liquid crystal display (LCD);
0.28 mm dot pitch; 200 cd/m
300:1 contrast ratio, typical
Input Signal Video
(Analog)
Sync
Input Signal
(Digital)
Display Colours Analog/Digital:
Synchronisation Horizontal
Range
Vertical
Resolutions Landscape
Supported
(Analog/Digital)
Portrait
CN912B-2/LCD1810X/78135322
2 white luminance, typical;
Analog 0.7 Vp-p 75
Separate sync. TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Composite sync. (Positive/Negative)
(TTL Level)
Sync on Green video (Positive) 0.7
Vp-p and sync. Negative 0.3 Vp-p
TMDS
16,777,216
(Depends on the graphics board)
31.0 kHz to 82.0 kHz (Automatically)
56.0 Hz to 85.0 Hz (Automatically)
1
720 x 400* : VGA text
1
640 x 480* at 60 Hz to 85 Hz
800 x 600* 1 at 56 Hz to 85 Hz
832 x 624* 1 at 75 Hz
1024 x 768* 1 at 60 Hz to 85 Hz
1152 x 900* 1 *
1
1280 x 960* *
2
1280 x 1024*
1
480 x 640* at 60 Hz to 85 Hz
1
600 x 800* at 56 Hz to 85 Hz
624 x 832* 1 at 75 Hz
768 x 1024* 1 at 60 Hz to 85 Hz
960 x 1280* 1 *
1024 x 1280* 2
36
Specifications
3 at 66 Hz (SUN)
3
at 60 Hz to 75 Hz
at 60 Hz to 75 Hz
3 at 60 Hz to 75 Hz
at 60 Hz to 75 Hz
