e 906
Instruction manual
Stage Microphones

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the evolution e 906 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sennheiser evolution e 906

  • Page 1 e 906 Instruction manual Stage Microphones...
  • Page 2 · »...
  • Page 3 0° 0° 30° 30° 125 Hz 60° 60° 250 Hz 500 Hz 1,000 Hz 90° 90° 2,000 Hz 4,000 Hz 8,000 Hz 120° 120° 16,000 Hz 150° 150° 180° 180° - 40 - 50 - 60 - 70 - 80 - 90 (0°, 1 m)
  • Page 4: Important Safety Information

    • Only use attachments, accessories or spare parts specified by Sennheiser. During operation • Liquids entering the product can short-circuit the electronics or damage the mechanics. Keep all liquids away from the product.
  • Page 5: Delivery Includes

    The e 906 A more direct sound – more directly from the amp. The e 906 captures the guitar sound just as you want it to be: from clean to distorted, from gentle to aggressive. It provides a high- resolution, natural sound without unwanted coloration. The transient response of the e 906 convinces in every style: it even transmits riffs with an extremely hard punch directly and straightforward.
  • Page 6: Using The Microphone

    Using the microphone Positioning the microphone an a guitar amp Pos. Resulting sound Commentary • many trebles microphone directed towards the dome of the loudspeaker • aggressive sound • less trebles good starting position: • more lower mids • microphone directed towards the middle between dome and edge of •...
  • Page 7 Adapting the sound characteristics The e 906 features a switchable presence filter which allows to adapt the microphone to the different sound requirements and styles (see also the frequency response curve D). Use a pointed tool such as a small screwdriver to move the 3-positi- on slide switch to the desired position.
  • Page 8: Specifications

    Specifications Transducer principle dynamic Frequency response 40 … 18,000 Hz Pick-up pattern super-cardioid Sensitivity (free field, no load at 1 kHz) 2.2 mV/Pa 350 Ω Nominal impedance (at 1 kHz) Min. terminating impedance 1 kΩ Connector XLR-3 Dimensions 55 mm x 34 mm x 134 mm Weight 140 g The polar diagram and the frequency response curve...
  • Page 9: Manufacturer Declarations

    Manufacturer Declarations Warranty Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our website at www.sennheiser.com or contact your Sennheiser partner. FOR AUSTRALIA ONLY Sennheiser goods come with guarantees that cannot be excluded under the Australian Consumer Law.
  • Page 12 Sennheiser electronic GmbH & Co. KG Am Labor 1, 30900 Wedemark, Germany www.sennheiser.com Publ. 08/15, 094277/A02...
