Instruction Manual
4x4 HDMI Matrix Switch w/ Picture-and-
Picture – 1080p
VS424HDPIP
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 10/10/2014
*actual product may vary from photos
Advertisement
Table of Contents
Related Manuals for StarTech.com VS424HDPIP
Summary of Contents for StarTech.com VS424HDPIP
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 10/10/2014...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Product Diagram ..................2 Front View ..............................2 Rear View ..............................2 Hardware Installation ................3 Hardware Operation ................3 Matrix Operation ............................3 Dual Mode Operation ..........................3 TV Wall Mode Operation ........................4 On Screen Display Menu ........................ -
Page 4: Introduction
Introduction Packaging Contents • 1 x HDMI Matrix Switch (VS424HDPIP) • 1 x Remote control • 1 x Mounting brackets • 1 x Universal Power Adapter (NA/UK/EU/AUS) • 1 x Quick Install Guide System Requirements • Up to 4 x HDMI-enabled Video Source Devices (i.e. computer, Blu-ray Player) •... -
Page 5: Product Diagram
Product Diagram Front View 1. IR Sensor 8. Save Button / LED 2. Power Button / LED 9. Lock Button / LED 3. Menu Button / LED 10. Recall Button 4. Menu Operation Buttons / LEDs 5. Output Selection Buttons / LEDs 6. -
Page 6: Hardware Installation
Hardware Installation 1. Connect up to four HDMI cables (not included) from each of your HDMI video source devices (i.e. computers, Blu-ray Players) to each of the HDMI input ports on the matrix switch. 2. Connect up to 4 HDMI cables (not included) from each HDMI output port on the matrix switch to the HDMI input ports on your display devices (i.e. -
Page 7: Tv Wall Mode Operation
Note: Dual A group are output A and B, Dual B group are output C and D. Each group will output the same image simultaneously. 3. To switch the audio source between output A or B, Press button A or B for 3 seconds. 4. - Page 8 DUAL AL Enables you to select Dual mode DUAL AR with your desired video outputs DUAL BL selected. DUAL BR OUT A Enables you to select OUT B TV WALL mode with your desired video OUT C output. OUT D RESET Restores default output settings.
- Page 9 Enables you to define your available audio specification to your LPCM audio source device. LPCM 2CH, LPCM, 6CH, LPCM 8CH, BIT-STREAM, HD AUDIO EDID Note: Whichever is selected will limit the audio distributed by your source device. Returns to Main EXIT Menu.
- Page 10 Enables you to CORRECTION ON, OFF define image compensation for the bezel size of your 0~ by output BEZEL H CORRECTION monitors for when resolution CORRECTION the switch is in TV WALL mode. 0~ by output V CORRECTION resolution Returns to Main EXIT Menu.
-
Page 11: Ir Remote Control Operation
Returns to Main EXIT Menu. EXIT Closes OSD Menu. IR Remote Control Operation An IR remote control is included with the VS424HDPIP for hassle-free remote operation. Please review the legend below for a detailed description of each remote control function. Instruction Manual... - Page 12 1. Power: Press this button to switch on the device or press it again to set it to standby mode. 2. Info: Press this button to show the device’s firmware version. 3. Out A~D and In 1~4: Press out¬put A~D and then press input 1~4 to select display input.
-
Page 13: Rs232 Serial Operation
To adjust the IR addressing of the switch itself please access the below setting in the OSD menu. Others -> IR addressing RS232 Serial Operation RS232 Pin Assignment VS424HDPIP Serial Controller (PC) Assignment Definition RS232 Protocols... - Page 14 RS232 Telent Commands Note: All commands will be not executed unless followed with a carriage return (0x0D) and commands are case-sensitive. Command Action Return Dual A Audio channel in AUA001 AUA001 Left side Dual A Audio channel in AUA002 AUA002 Right side Check Dual A audio channel AUA999...
- Page 15 Horizontal (H) Bezel correc- BEH??? BEH??? tion???=000 ~ Maximum Check the current BEH998 Horizontal(H) Bezel BEH??? correction Maximum value Check the current BEH999 Horizontal(H) Bezel BEH??? correction setting value Vertical (V) Bezel BEV??? correction???=000 ~ BEV??? Maximum Check the current Vertical(V) BEV998 Bezel correction Maximum BEV???
-
Page 16: Ip Operation Using Web Browser
• Power Status must be set to on, and source status must be unlocked • Ensure step 5. of hardware Setup has been completed. • Obtain the IP address of the VS424HDPIP using the OSD menu. Access the following sub menu: ETHERNET ->... - Page 17 Advanced Menu The Advanced menu is available on the left hand side of the GUI, and enables you to navigate between advanced sections of operation. Descriptions outlining navigation as well as the available functionality for each tab are listed below. Image Adjust By default, the Image Adjust tab is the first window displayed when the web GUI is opened.
- Page 18 Notes: • 1080i@50/60 are supported in Matrix mode only. • Selecting NATIVE enables the VS424HDPIP to use EDID to determine the best output resolution automatically. OSD Settings To access the OSD settings tab, click OSD Settings on the side menu.
- Page 19 Note: TIMEOUT =OFF means MENU and INFO will continue showing on the Screen. Window Convert To access the Window Convert tab, click Window Convert on the side menu. The Window Convert tab enables you to implement transition effects while switching between video sources.
- Page 20 Ethernet To access the Ethernet tab, click Ethernet on the side menu. The Ethernet section enables you to define Network communication protocols for remote operation. Instruction Manual...
-
Page 21: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 22 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
