2X2 HDMI® Matrix Switch - 4K
VS222HDQ
*actual product may vary from photos
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 10/21/2013
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com VS222HDQ
Summary of Contents for StarTech.com VS222HDQ
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 10/21/2013...
-
Page 2: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 3: Table Of Contents
Table of Contents Product Diagram ..................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Hardware Installation ................3 Hardware Operation ..........................3 Remote Control ............................5 Specifications ..................6 Technical Support ..................7 Warranty Information ................7 Instruction Manual... -
Page 4: Product Diagram
Product Diagram EDID Power EDID Port Copy Adapter HDMI HDMI HDMI Selection Button Port Input #1 Input #2 Output Switch Manual Switch Mode Manual LED Port Switch Selection Selection Switch Indicator Instruction Manual... -
Page 5: Introduction
Introduction Packaging Contents • 1x HDMI® Matrix Switch • 1x Universal Power Adapter • 1x Remote control • 1x Instruction Manual System Requirements • 2x Video source devices (i.e. computer, Blu-ray Player) • 2x HDMI® enabled display device (i.e. television, projector) •... -
Page 6: Hardware Installation
Hardware Installation 1. Connect two HDMI® cables (not included) from each of the HDMI® Output ports on the switch to each of the HDMI® enabled display devices (i.e. televisions, projectors). 2. Connect an HDMI® cable (not included) from each input device to the HDMI® Input Ports on each video source device (i.e. - Page 7 Matrix Mode Matrix mode allows you to output either display to one or both of the video sources. Each display is represented by each of the Manual Switches. 1. Press Manual Switch #1, one time to output Input 1, or two times to output signal 2. 2.
-
Page 8: Remote Control
Remote Control Auto/Priority/Manual Mode Press 1, or 2 to switch between Input source #1, or Input source #2 respectively. Matrix Mode 1. S1 or S2 to select video output #1 or video output #2 respectively. 2. Then Press 1, or 2 to output Input#1 or Input source #2 respectively. Instruction Manual... -
Page 9: Specifications
Specifications Input Ports Ouput Ports AV Input HDMI® AV Output HDMI® Audio Max Distance 10m / 33ft Max Resolution 1080p Wide Screen Supported Instruction Manual... -
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
