(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 06/26/2012
Krystal Clear
Filter Pump 14" (360mm)
Model SF15110
For illustrative purposes only.
Don't forget to try these other fine Intex products: pools, pool
accessories, inflatable pools and in-home toys, airbeds and boats
available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex
reserves the right to change specifications and appearance, which
may result in updates to the instruction manual, without notice.
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance,
Visit www.intexcorp.com
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
Monday through Friday, 8:30am to 5:00pm Pacific Time
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
™
Sand
IMPORTANT!
1-800-234-6839
English
161
161-***-R0-1306
Advertisement
Table of Contents
Related Manuals for Intex Krystal Clear SF15110
Summary of Contents for Intex Krystal Clear SF15110
- Page 1 Filter Pump 14” (360mm) Model SF15110 For illustrative purposes only. Don’t forget to try these other fine Intex products: pools, pool accessories, inflatable pools and in-home toys, airbeds and boats available at fine retailers or visit our website. Due to a policy of continuous product improvement, Intex reserves the right to change specifications and appearance, which may result in updates to the instruction manual, without notice.
-
Page 2: Table Of Contents
Warnings................3 Parts List & References..........4-8 Setup Instructions ............9-16 Product Specifications........... 11 Operating Instructions ........... 17-19 Intex Pools Operating Time Table........20 Non-Intex Pools Operating Time Table......21 Maintenance..............22 Long Term Storage............23 Troubleshooting Guide........... 24 Common Pool Problems..........25 General Aquatic Safety........... -
Page 3: Warnings
(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with disabilities. -
Page 4: Parts List & References
(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English PARTS LIST NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. SAVE THESE INSTRUCTIONS Page 4... - Page 5 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English PARTS LIST (continued) Optional Optional Optional NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. SAVE THESE INSTRUCTIONS Page 5...
- Page 6 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
- Page 7 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English PARTS REFERENCE (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale. SAVE THESE INSTRUCTIONS Page 7...
- Page 8 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English PARTS REFERENCE (continued) Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. SPARE PART REF. NO. DESCRIPTION QTY.
- Page 9 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English POOL OUTLET - STRAINER & PLUNGER VALVE SETUP The strainer grid prevents large objects from jamming and/or damaging the filter pump. If your pool has an inflatable top ring, install the strainer, nozzle and plunger valve before inflating the pool liner top ring.
- Page 10 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English POOL INLET - NOZZLE & PLUNGER VALVE SETUP 1. In a counter-clockwise motion unscrew plunger valve union from the threaded strainer connector (26) (see drawing 5). Be careful not to lose the step rubber washer (23).
-
Page 11: Setup Instructions
(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English PRODUCT SPECIFICATIONS The sand filter removes suspended particles but does not sanitize your pool. Pool chemistry is a specialized area and you should consult your local pool service specialist for details. - Page 12 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English SETUP INSTRUCTIONS (continued) 4. In a clockwise motion screw filter housing nut (17) onto the motor water inlet (See drawings 12.1 & 12.2). 12.2 12.1 5. Replace the basket (16) and leaf trap cover (14) back to the pre-filter housing (See drawings 13.1 &...
- Page 13 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English SETUP INSTRUCTIONS (continued) Sand loading: IMPORTANT: Use No. 20 silica sand or glass sand with particle size range 0.45 to 0.85 mm (0.018 to 0.033 inches) and a Uniformity Coefficient less than 1.75.
- Page 14 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English SETUP INSTRUCTIONS (continued) WARNING Improper tank valve and clamp assembly could cause the valve and clamp to blow off and cause serious injury, property damage or death. 6-way valve installation: Lower the 6-way valve over the tank slowly, and ensure the bypass pipe protruding underneath the 6-way valve fits securely into the center pipe hub (7)
- Page 15 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English SAND FILTER PUMP HOSE CONNECTION SETUP WARNING • Position this product away from the pool, so as to prevent children from climbing on it and accessing the pool. The 6-way valve has three hose connection ports. 1. Connect one hose (12) end to the pre-filter inlet and the other end of the hose to the lower plunger valve with the strainer.
- Page 16 LARGE HOSE CLAMP POOL For INTEX pool size 16' and below: 1. In a counter-clockwise motion unscrew plunger valve union from the threaded strainer connector (26). Be careful not to lose the step rubber washer (23). 2. Grasp the plunger valve assembly. Make sure the step washer (23) is in place.
-
Page 17: Operating Instructions
(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English OPERATING INSTRUCTIONS WARNING • Risk of electric shock. Connect this product only to a grounding type receptacle protected by a ground-fault circuit interrupter (GFCI) or residual current device (RCD). Contact a qualified electrician if you cannot verify that the receptacle is protected by a GFCI/RCD. Use a qualified electrician to install the GFCI/RCD, which has a maximum rate of 30mA. - Page 18 (161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English OPERATING INSTRUCTIONS (continued) Initial startup and operation: Before operating, be sure that: • All the hoses have been connected and tightened securely, and correct amount of filter sand have been loaded. • The entire system is connected to a grounding type receptacle protected by a ground-fault circuit interrupter (GFCI) or residual current device (RCD). CAUTION The filter control valve has a closed position. The pump should never be on when the valve is in the closed position.
- Page 19 “BACKWASH” under “initial startup and operation” section. Vacuuming device (i.e. Intex auto pool cleaner) attached to the system may also cause the flow to diminish and the pressure to rise. Remove any vacuuming device from the system and check if the pressure gauge reading has dropped from the yellow zone to the green zone.
- Page 20 This table shows the required operating time for average use of the sand filter pump with above ground pools. If the system is attached to an “Intex Saltwater System” unit, the filter pump running time should be longer than the required operating time of the Intex Saltwater System unit.
-
Page 21: Non-Intex Pools Operating Time Table
(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English NON-INTEX POOLS OPERATING TIME TABLE This table shows the required operating time for average use of the sand filter pump with above ground pools. Sand filter pump operating... -
Page 22: Maintenance
(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English MOTOR PRE-FILTER CLEANING AND MAINTENANCE 1. Make sure the filter pump is switched off, then disconnect the power cord from the electrical outlet. 2. Turn both plunger valve handles fully clockwise until they stop. This closes the valve, prevents the water from flowing out of the pool. -
Page 23: Long Term Storage
(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English POOL CARE & CHEMICALS • All pools require care to keep the water clear and hygienically clean. With proper chemical control, your filter will help attain this objective. Consult your pool supply dealer for instructions regarding the proper use of chlorine, algaecide and other chemical agents required for sparkling clear water. -
Page 24: Troubleshooting Guide
• The vacuum release valve on • Turn off pump, if water leaking from the vacuum release valve, the plunger valve is leaking. then release valve needs to be replaced. Contact Intex Service Center immediately to order replacement. You may cover release valve with the cap temporarily if you ensure that the strainer cover / strainer grid is installed and you Do Not run the pump while pool is occupied. -
Page 25: Common Pool Problems
• Repair with a patch kit. LOW WATER on previous day. liner or hoses. • Finger tighten all caps. LEVEL • The drain valves are loose. SEDIMENT • Dirt or sand on • Heavy use, getting in • Use Intex pool vacuum to ON POOL pool floor. and out of pool. clean bottom of pool. BOTTOM SURFACE • Leaves, insects • Pool too close to • Use Intex pool skimmer. DEBRIS etc. -
Page 26: General Aquatic Safety
(161) MODEL SF15110 SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/26/2012 English GENERAL AQUATIC SAFETY Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and death. To reduce your risk of injury, read and follow all product, package and package insert warnings and instructions. -
Page 27: Limited Warranty
LIMITED WARRANTY PARTS LIST Your Sand Filter Pump has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies only to the Sand Filter Pump and accessories listed below. The provisions of this Limited Warranty apply only to the original purchaser and is not transferable.
