Intex Krystal Clear SF80110-2 Owner's Manual
Hide thumbs
Also See for Krystal Clear SF80110-2:
- Owner's manual (24 pages) ,
- Owner's manual (35 pages)
Table of Contents
Advertisement
Model SF80110-2
Model SF70110-2
Model SF60110-2
For illustrative purposes only.
Don't forget to try these other fine Intex products: pools, pool
accessories, inflatable pools and in-home toys, airbeds and boats
available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex
reserves the right to change specifications and appearance, which
may result in updates to the instruction manual without notice.
DO NOT RETURN PRODUCT TO STORE
To purchase parts and accessories or to obtain non-technical assistance, visit
For technical assistance and missing parts call us toll-free (for U.S. and Canadian Residents):
Monday through Friday, 8:30am to 5:00pm Pacific Time
(342PO) SAND FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 06/08/2018
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
IMPORTANT!
www.intexcorp.com
1-800-234-6839
342
English
PO
342-*PO-R0-1906
Advertisement
Table of Contents
Related Manuals for Intex Krystal Clear SF80110-2
Summary of Contents for Intex Krystal Clear SF80110-2
- Page 1 Model SF70110-2 Model SF60110-2 For illustrative purposes only. Don’t forget to try these other fine Intex products: pools, pool accessories, inflatable pools and in-home toys, airbeds and boats available at fine retailers or visit our website. Due to a policy of continuous product improvement, Intex reserves the right to change specifications and appearance, which may result in updates to the instruction manual without notice.
-
Page 2: Table Of Contents
Warnings................3 Parts References............4-5 Setup Instructions ............6-13 Product Specifications........... 8 Operating Instructions ........... 14-16 Intex Pools Operating Time Table........17 Non-Intex Pools Operating Time Table......18 Maintenance..............19 Long Term Storage............20 Troubleshooting Guide........... 21 Common Pool Problems..........22 General Aquatic Safety........... -
Page 3: Warnings
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with disabilities. -
Page 4: Parts References
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. Parts shown on this page are supplied with the pool package and are shown here for assembly purposes only. 23 24 23 24 23 28... - Page 5 (342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English SPARE PART NO. REF. NO. DESCRIPTION QTY. SF80110-2 SF70110-2 SF60110-2 PRESSURE GAUGE 11411 11224 11224 6-WAY VALVE 11378 11496 11496 DRAIN OUTLET COVER 11131 11131 11131 CLAMP 11380 11380 11380 TANK O-RING...
- Page 6 (342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English POOL OUTLET - STRAINER & PLUNGER VALVE SETUP (optional) The strainer grid prevents large objects from jamming and/or damaging the filter pump. If your pool has an inflatable top ring, install the strainer, nozzle and plunger valve before inflating the pool liner top ring.
- Page 7 (342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English POOL INLET - NOZZLE & PLUNGER VALVE SETUP (optional) 1. In a counter-clockwise motion unscrew plunger valve union from the inlet threaded air connector (42) (see drawing 5). Be careful not to lose the step rubber washer (23).
-
Page 8: Setup Instructions
Motor pre-filtering assembly setup: Remove the sand filter and its accessories from the packaging carefully and inspect for any visible damage. For missing or damaged parts contact the appropriate Intex Service Center listed in the separate “Authorized service Centers” sheet. - Page 9 (342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English SETUP INSTRUCTIONS (continued) 4. In a clockwise motion screw filter housing nut (17) onto the motor water inlet (see drawings 12.1 & 12.2). 12.2 12.1 5. Replace the basket (16) and leaf trap cover (14) back to the pre-filter housing (see drawings 13.1 &...
- Page 10 (342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English SETUP INSTRUCTIONS (continued) Sand loading: IMPORTANT: Use No. 20 silica sand or glass sand with particle size range 0.45 to 0.85 mm (0.018 to 0.033 inches) and a Uniformity Coefficient less than 1.75. NOTE: Before loading the tank with sand, ensure the center pipe hub assembly is securely in place at the bottom of the tank, and vertically centered inside the tank.
- Page 11 (342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English SETUP INSTRUCTIONS (continued) WARNING Improper tank valve and clamp assembly could cause the valve and clamp to blow off and cause serious injury, property damage or death. 6-way valve installation: Lower the 6-way valve over the tank slowly, and ensure the bypass pipe protruding underneath the 6-way valve fits securely into the center pipe hub (7) top opening (see drawing 19).
- Page 12 (342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English SAND FILTER PUMP HOSE CONNECTION SETUP WARNING • Position this product away from the pool, so as to prevent children from climbing on it and accessing the pool. The 6-way valve has three hose connection ports.
- Page 13 Connect the hose (12) to the pool inlet/outlet connection with a large hose clamp. Tighten securely. LARGE HOSE CLAMP POOL For INTEX pool with 1-1/4” (32mm) connections/hoses: Make sure the air jet valve (39) is securely tighten onto the pool inlet air adaptor (43) and facing (Adaptor B) (Adaptor B) Page 13...
-
Page 14: Operating Instructions
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English OPERATING INSTRUCTIONS WARNING • Risk of electric shock. Connect this product only to a grounding type receptacle protected by a ground-fault circuit interrupter (GFCI) or residual current device (RCD). Contact a qualified electrician if you cannot verify that the receptacle is protected by a GFCI/RCD. - Page 15 “BACKWASH” under “initial startup and operation” section. Vacuuming device (i.e. Intex auto pool cleaner) attached to the system may also cause the flow to diminish and the pressure to rise.
- Page 16 (342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English OPERATING INSTRUCTIONS (continued) Operating the system under “TIMER” mode or manually: To operate the sand filter pump in “FILTER” mode under “TIMER” control: 1. Activate the unit: Press button.
-
Page 17: Intex Pools Operating Time Table
This table shows the required operating time for average use of the sand filter pump with above ground pools. If the system is attached to an “Intex Saltwater System” unit, the filter pump running time should be longer than the required operating time of the Intex Saltwater System unit. -
Page 18: Non-Intex Pools Operating Time Table
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English NON-INTEX POOLS OPERATING TIME TABLE This table shows the required operating time for average use of the sand filter pump with above ground pools. Water Capacity Sand filter pump operating time (For one cycle) / (Hours) -
Page 19: Maintenance
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English MOTOR PRE-FILTER CLEANING AND MAINTENANCE 1. Make sure the filter pump is switched off, then disconnect the power cord from the electrical outlet. 2. Turn both plunger valve handles fully clockwise until they stop. This closes the valve, prevents the water from flowing out of the pool. -
Page 20: Long Term Storage
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English POOL CARE & CHEMICALS • All pools require care to keep the water clear and hygienically clean. With proper chemical control, your filter will help attain this objective. Consult your pool supply dealer for instructions regarding the proper use of chlorine, algaecide and other chemical agents required for sparkling clear water. -
Page 21: Troubleshooting Guide
• An air leak on the intake hose. • Tighten hose nuts, check hose for damage. • Faulty motor or the impeller is • Contact Intex service center. jammed. • Sand tank o-ring missing. • Remove 6-way valve cover and ensure the 6-WAY VALVE/ •... -
Page 22: Common Pool Problems
• Finger tighten all caps. LEVEL • The drain valves are loose. SEDIMENT • Dirt or sand on pool floor. • Heavy use, getting in and • Use Intex pool vacuum to ON POOL out of pool. clean bottom of pool. BOTTOM SURFACE •... -
Page 23: General Aquatic Safety
(342PO) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 06/08/2018 English GENERAL AQUATIC SAFETY Water recreation is both fun and therapeutic. However, it involves inherent risks of injury and death. To reduce your risk of injury, read and follow all product, package and package insert warnings and instructions. -
Page 24: Limited Warranty
Your Sand Filter Pump has been manufactured using the highest quality materials and workmanship. All Intex products have been inspected and found free of defects prior to leaving the factory. This Limited Warranty applies only to the Sand Filter Pump and accessories listed below.
