Model SF80220RC 6 m
Model SF70220RC 8 m
Model SF60220RC 10 m
For illustrative purposes only.
Don't forget to try these other fine Intex products: pools, pool
accessories, inflatable pools and in-home toys, airbeds and boats
available at fine retailers or visit our website.
Due to a policy of continuous product improvement, Intex reserves
the right to change specifications and appearance, which may
result in updates to the instruction manual without notice.
Rechte vorbehalten. Printed in China/Imprimé en Chine/Impreso en China/Gedruckt in China.
®™ Trademarks used in some countries of the world under license from/®™ Marques utilisées dans certains pays sous
licence de/Marcas registradas utilizadas en algunos países del mundo bajo licencia de/Warenzeichen verwendet in einigen
Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O
Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European
Union by/Distribué dans l'Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union
durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal – The Netherlands
www.intexcorp.com
(195GS) SAND FILTER PUMP ENGLISH 7.5" X 10.3" PANTONE 295U 07/30/2014
IMPORTANT
SAFETY RULES
Read, understand, and follow
all instructions carefully before
installing and using this product.
©2014 Intex Marketing Ltd. - Intex Development Co. Ltd. - Intex Trading Ltd.
- Intex Recreation Corp.
All rights reserved/Tous droits réservés/Todos los derechos reservados/Alle
195
English
GS
3
3
3
195-*GS-R0-1507
Advertisement
Table of Contents
Related Manuals for Intex SF60220RC
Summary of Contents for Intex SF60220RC
- Page 1 Ländern der Welt in Lizenz von/Intex Marketing Ltd. to/à/a/an Intex Trading Ltd., Intex Development Co. Ltd., G.P.O Box 28829, Hong Kong & Intex Recreation Corp., P.O. Box 1440, Long Beach, CA 90801 • Distributed in the European Union by/Distribué dans l’Union Européenne par/Distribuido en la unión Europea por/Vertrieb in der Europäischen Union durch/Intex Trading B.V., Venneveld 9, 4705 RR Roosendaal –...
-
Page 2: Table Of Contents
Warnings................3 Parts References............. 4-5 Setup Instructions ............6-13 Product Specifications........... 8 Operating Instructions ........... 14-16 Intex Pools Operating Time Table........17 Non-Intex Pools Operating Time Table......18 Maintenance..............19 Long Term Storage............20 Troubleshooting Guide........... 21 Common Pool Problems..........22 General Aquatic Safety........... -
Page 3: Warnings
(195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English IMPORTANT SAFETY RULES Read, Understand and Follow All Instructions Carefully Before Installing and Using this Product. READ AND FOLLOW ALL INSTRUCTIONS WARNING • To reduce the risk of injury, do not permit children to use this product. Always supervise children and those with disabilities. -
Page 4: Parts References
(195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. 23 24 29 31 29 30 "... - Page 5 PARTS REFERENCE Before assembling your product, please take a few minutes to check the contents and become familiar with all the parts. SPARE PART NO. REF. NO. DESCRIPTION QTY. SF80220RC SF70220RC SF60220RC PRESSURE GAUGE 11411 11224 11224 6-WAY VALVE 11378...
- Page 6 (195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English POOL OUTLET - STRAINER & PLUNGER VALVE SETUP (optional) The strainer grid prevents large objects from jamming and/or damaging the filter pump. If your pool has an inflatable top ring, install the strainer, nozzle and plunger valve before inflating the pool liner top ring.
-
Page 7: Nozzle & Plunger Valve Setup
(195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English POOL INLET - NOZZLE & PLUNGER VALVE SETUP (optional) 1. In a counter-clockwise motion unscrew plunger valve union from the threaded strainer connector (26) (see drawing 5). Be careful not to lose the step rubber washer (23). -
Page 8: Setup Instructions
The sand filter removes suspended particles but does not sanitize your pool. Pool chemistry is a specialized area and you should consult your local pool service specialist for details. Model: SF80220RC SF70220RC SF60220RC Power: 220-240 Volt AC 220-240 Volt AC 220-240 Volt AC... - Page 9 • The mounting holes are 6.4 mm in diameter and spaced 100 mm for model SF80220RC (spaced 115 mm for model SF70220RC & SF60220RC) apart. • Use two bolts and lock nuts with a maximum of 6.4 mm in diameter.
- Page 10 (195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English SETUP INSTRUCTIONS (continued) Sand loading: IMPORTANT: Use No. 20 silica sand or glass sand with particle size range 0.45 to 0.85 mm (0.018 to 0.033 inches) and a Uniformity Coefficient less than 1.75. NOTE: Before loading the tank with sand, ensure the center pipe hub assembly is securely in place at the bottom of the tank, and vertically centered inside the tank.
- Page 11 (195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English SETUP INSTRUCTIONS (continued) WARNING Improper tank valve and clamp assembly could cause the valve and clamp to blow off and cause serious injury, property damage or death. 6-way valve installation: Lower the 6-way valve over the tank slowly, and ensure the bypass pipe protruding underneath the 6-way valve fits securely into the center pipe hub (7) top opening (see drawing 19).
-
Page 12: Sand Filter Pump Hose Connection Setup
(195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English SAND FILTER PUMP HOSE CONNECTION SETUP WARNING • Keep this product more than 3.5m away from the pool. • Keep the plug of this product more than 4m away from the pool and at a height of 1.2m at least. - Page 13 LARGE HOSE CLAMP POOL For INTEX pool size 16' and below: 1. In a counter-clockwise motion unscrew plunger valve union from the threaded strainer connector (26). Be careful not to lose the step rubber washer (23). 2. Grasp the plunger valve assembly. Make sure the step washer (23) is in place. Connect adaptor B (28) to plunger valve union.
-
Page 14: Operating Instructions
(195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English OPERATING INSTRUCTIONS RCD OPERATING INSTRUCTIONS • Plug RCD into power outlet. Press RESET button on the RCD plug. Indicator should be "ON". See FIG. 23. • Press TEST button on the RCD plug. Indicator should be "OFF". See FIG. 24. •... - Page 15 (195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English OPERATING INSTRUCTIONS (continued) Initial startup and operation: Before operating, be sure that: • All the hoses have been connected and tightened securely, and correct amount of filter sand have been loaded.
-
Page 16: Operating Under Timer Mode Or Manually
“BACKWASH” under “initial startup and operation” section. Vacuuming device (i.e. Intex auto pool cleaner) attached to the system may also cause the flow to diminish and the pressure to rise. Remove any vacuuming device from the system and check if the pressure gauge reading has dropped from the yellow zone to the green zone. -
Page 17: Intex Pools Operating Time Table
This table shows the required operating time for average use of the sand filter pump with above ground pools. If the system is attached to an “Intex Saltwater System” unit, the filter pump running time should be longer than the required operating time of the Intex Saltwater System unit. -
Page 18: Non-Intex Pools Operating Time Table
(195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English NON-INTEX POOLS OPERATING TIME TABLE This table shows the required operating time for average use of the sand filter pump with above ground pools. Water Capacity Sand filter pump operating time (For one cycle) / (Hours) -
Page 19: Maintenance
(195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English MOTOR PRE-FILTER CLEANING AND MAINTENANCE 1. Make sure the filter pump is switched off, then disconnect the power cord from the electrical outlet. 2. Turn both plunger valve handles fully clockwise until they stop. This closes the valve, prevents the water from flowing out of the pool. -
Page 20: Long Term Storage
(195GS) SAND FILTER PUMP ENGLISH 7.5” X 10.3” PANTONE 295U 07/30/2014 English POOL CARE & CHEMICALS • All pools require care to keep the water clear and hygienically clean. With proper chemical control, your filter will help attain this objective. Consult your pool supply dealer for instructions regarding the proper use of chlorine, algaecide and other chemical agents required for sparkling clear water. -
Page 21: Troubleshooting Guide
• Tighten hose nuts, check hose for • Faulty motor or the impeller is damage. jammed. • Contact Intex service center. • Sand tank o-ring missing. • Remove 6-way valve cover and ensure the 6-WAY VALVE/COVER • Sand tank o-ring dirty. -
Page 22: Common Pool Problems
• Finger tighten all caps. • The drain valves are loose. SEDIMENT • Dirt or sand on • Heavy use, getting in • Use Intex pool vacuum to clean ON POOL pool floor. and out of pool. bottom of pool. -
Page 23: Limited Warranty
This Limited Warranty applies only to those parts and components sold by Intex. The Limited Warranty does not cover unauthorized alterations, repairs or disassembly by anyone other than Intex Service Center personnel.
