Summary of Contents for IC Realtime IC720
- Page 1 INSTRUCTION MANUAL...
- Page 2 TAB LE O F CO NTE NT S F e a t u res a n d S p e ci f i ca t i o n s We b GU I | I C72 0 M a n a g e m e n t a.
- Page 3 F E ATURE S AN D SPE CI F I CAT I ON S...
- Page 4 24/7 operation. Utilizing both H.264 video compression and A AC audio compression technolog y enables the highest qualit y of recorded audio/video, while maintaining the lowest bitrate utilization. The IC720 series camera is an HD, dual lens 12 MegaPixel IP Camera...
- Page 5 1b. FEATURES SD Card Storage: As a standalone device, the IPC can hold a 32GB IC Realtime IC720 series IP Cameras all support the following features: micro SD card suitable for storing video direct from the camera. HD, 360 x 360 Video Monitoring: This IP Camera uses two SONY 1c.
- Page 6 Low Qualit y: 5Mbit /s Recommended: 8Mbit /s 2560x2560@20fps H264-High Optical Configuration 2 x Fish Eye Lens; Back-to-Back High Qualit y: 12MBit /s (supported in IC720 application) Lens All Glass, FOV=194º, f/2.2 Electromagnetic IR-CUT IR CUT 2 x SONY IMX172...
- Page 7 1.d SPECIFICATIONS (Continued) IC Realtime NVR-8128; NVR-8256 Memory Slot Micro SD (up to 32GB) Power Supply 12VDC, PoE Power Consumption Mount Wall, Ceiling, Corner, Pole Mounts Size 4.2’’ x 11.7’’ x 2.9’’ (108mm x 293mm x 73mm) Weight ~3 lbs...
- Page 8 1.e DIMENSIONAL VIEWS Bottom view of the IC720 Camera. The cable harness extends out of the center. The ‘ front ’ of the IC720 Camera. Ceiling mount orientation. Note: If mounting the ALLie home with lenses pointing towards the ceiling and the ground be sure to have the side with the microphone pointing towards the ground.
- Page 9 CA M E R A I N S TALL AT I ON...
- Page 10 2.a CEILING INSTALLATION: STEP BY STEP This section outlines the proper way to mount and install an IC720 series IP Camera. Suitable methods of installing the IPC include either Ceiling installation, Corner installation, or Pole Installation. Note that hardware including screws and anchors are included for the camera installation.
- Page 11 Step 1: Install the Beauty Shroud Step 2: Install the Interface Plate Slide the shroud over the IC720 Camera body from the top. Attach the interface plate with (4) #10-24 Pan Head screws and locking washers. Tighten to secure the interface plate to the camera body.
- Page 12 Step 3: Connect Wiring Step 4: Secure the Camera Assembly to the Ceiling Mount Pass cables the cables through the pole mount and then connect Secure the assembly to the ceiling mount itself with (3) M3 your Ethernet and power cables (if not using Power Over Cap screws.
- Page 13 2.b CORNER/POLE MOUNT: STEP BY STEP This section outlines the proper way to mount and install an IC720 series IP Camera. Suitable methods of installing the IPC include either Ceiling installation, Corner installation, or Pole Installation. Note that hardware including screws and anchors are included for the camera installation.
- Page 14 Step 1: Install the Beauty Shroud Step 2: Install the Interface Plate Slide the shroud over the IC720 Camera body from the top. Attach the interface plate with (4) #10-24 Pan Head screws and locking washers. Tighten to secure the interface plate to the camera body.
- Page 15 Step 3: Connect Wiring Step 4: Secure the Camera Assembly to the Pole Mount Connect your Ethernet and power cables (if not using Power Over Secure the assembly to the ceiling mount itself with (4) M8 Ethernet). Once physical cable connections are established, the Pan Head screws.
- Page 17 WE B GU I | I C72 0 M ANAGE M E NT...
- Page 18 Step 2: Assign an IP address to the IP Camera. This section outlines how to assign an IP address to the camera, and how to access and configure the IC720 Beam via it ’s built in Web The IC720 Beam Series camera (and all ICR IP Cameras) are designed Interface.
- Page 19 3.b LOGGING IN, AND MAIN INTERFACE Step 1: Open up your Web Browser (Safari, Chrome, Firefox, or IE) and input the IP address of your IP camera. In Example, open Safari and browse to http://192.168.1.108 Step 2: Login to the camera with the default credentials By default, the username is ‘admin’...
- Page 20 Network Menu allows you to assign an IP address, as well as change the default port settings. System Menu allows for configuration of the Date/ Time, Language, as well as the IC720 Beam camera device logs. Accounts Menu allows you to manage accounts (Add/Delete/...
- Page 21 NVR should be a breeze. Each image of the camera (2 total) has an independent ONVIF port number for connection. Here’s an example of pairing the IC720 device to an IC Realtime NVR. Step 1: Login to the IC Realtime NVR series device, and navigate to the ‘Remote Devices’...
- Page 22 Step 3: Double click on the IP Address of your IC720 from the ‘Device Search’ menu to add the first IC720 sensor. This will automatically add this to your NVR, without needing to input any additional information. Step 4: Double click on the same IP Address again, if you want to add the second sensor (you will need to change the port number in the table below).
- Page 23 APPE N D IX: TOXI C AN D HA Z ARDOUS M ATE R IAL S RE POR T...
- Page 24 Note Toxic or Hazardous Materials or Elements Component Name This user manual is intended for reference only. Slight Cr VI PBDE dif ferences may be found in the user interface as products continually develop. Circuit Board Component Device Case All designs and sof tware herein are subject to change without prior written consent.
- Page 25 © 2015 IC Realtime, LLC. 3050 N Andrews Ave Ext Pompano Beach, FL 33064 Phone 866.997.9009 • Fax 866.860.3860...
