Page 1: Instruction Manual
Cameras: IP-PTZ IC REALTIME SECURITY SOLUTIONS ICIP-MP2008IR: IR IP PTZ Camera Instruction Manual... - Page 2 I C R E A L T I M E S E C U R I T Y S O L U T I O N S ICIP-MP2008IR IP PTZ Camera Instruction Manual IC Realtime 3050 N Andrews Ave Ext Pompano Beach, FL 33064 Phone 954.772.5327 •...
-
Page 3: Table Of Contents
T able of Contents 1. Features and Specifications ............... 1 a. Overview ..................1 b. Features .................... 1 c. Specifications ................... 3 d. Dimensions ..................5 2. Camera Installation ..................7 a. General Overview ................7 b. Step by Step Guide ................ 8 c. -
Page 4: Features And Specifications
Camera. It also outlines basic Architectural and Engineering specifications. 1.a Overview his IC Realtime series product is an excellent IP PTZ designed for the security field. It adopts an embedded Linux operating system to maintain reliable, 24/7 operation. Utilizing both H.264 video compression and G.711 audio compression technology enables the highest quality of recorded... - Page 5 R E A L T I M E S E C U R I T Y S O L U T I O N S Compression Format H.264 video and G.711 audio enables high quality video recording while maintaining the lowest file sizes possible.
-
Page 6: Specifications
R E A L T I M E S E C U R I T Y S O L U T I O N S 1.c Specifications Model MP2008IR Camera Image Sensor 1/3” Exmor CMOS Effective Pixels 1280(H) x 960(V) Scanning System Progressive Electronic Shutter Speed... - Page 7 R E A L T I M E S E C U R I T Y S O L U T I O N S Preset 80(ICR-SD), 255(Pelco-P/D) PTZ Mode 5 Pattern, 8 Tour, Auto Pan, Auto Scan Speed Setup Human-oriented focal length/ speed adaptation Power up Action Auto restore to previous PTZ and lens status after power failure...
-
Page 8: Dimensions
R E A L T I M E S E C U R I T Y S O L U T I O N S Power Supply AC 24V/2.2A (±10%) Power Consumption 10.5W, 26W (IR on, Heater on) Working Environment -40ºC ~ 60ºC / Less than 90% RH Ingress Protection IP66... -
Page 9: Wall Mount
R E A L T I M E S E C U R I T Y S O L U T I O N S Wall Mount... -
Page 10: Camera Installation
S O L U T I O N S Camera Installation This section outlines the proper way to mount and install an ICIP-MP2008IR series IP PTZ Camera. Suitable methods of installing the IPC include either Ceiling installation, Pole Installation, or Wall installations. -
Page 11: Step By Step Guide
R E A L T I M E S E C U R I T Y S O L U T I O N S 2.b Step by Step Guide Step 1: Install wall mount bracket Begin by first assuring that the wall you are mounting it on can support the bolts you will be using to hold the mount. -
Page 12: Connections & Dip Switch Settings
R E A L T I M E S E C U R I T Y S O L U T I O N S 2.c Connections & DIP Switch Settings This section will cover all connections of the MP2008IR PTZ. ... - Page 13 R E A L T I M E S E C U R I T Y S O L U T I O N S Dip switch settings are used to change the address, protocol, baud rate and parity of the PTZ. This is not needing to be changed if connecting it just over the network.
- Page 14 R E A L T I M E S E C U R I T Y S O L U T I O N S Parity: Note the chart below to set your parity. You should not need to change the parity in most cases. Baud Rate: Note the chart below to set your baud rate.
-
Page 15: Web Operation
(assuming that the IP address does not conflict with another device on your network). Alternatively, you can use our IP Auto Search utility to rapidly find and change IP addresses for IC Realtime series IP Cameras. The utility is available on our support page at : http://www.icrealtime.com/docs/IPAutoSearch.zip... - Page 16 R E A L T I M E S E C U R I T Y S O L U T I O N S Step 2: Follow the on screen prompts to install the plugin When you first access the IP Camera over your web browser, you will be prompted to install the plugin. See below: ...
-
Page 17: Ptz Controls
One of the primary features and functions of the IPC PTZ series cameras is the ability to Pan/Tilt/Zoom. Read on for a step-by- step guide on how to control the multiple functions of the ICIP-MP2008IR Once you are logged in, you should see the video of the camera appear in the middle of the viewing section. Off to the right you will find the PTZ controls of the camera. - Page 18 R E A L T I M E S E C U R I T Y S O L U T I O N S Note: To set these options above, you will need to click on the 'Setup' menu option and choose the 'PTZ' > 'Function' menu.
- Page 19 R E A L T I M E S E C U R I T Y S O L U T I O N S Chapter Appendix: Toxic or Hazard Materials Report Note This user manual is intended for reference only. Slight differences may be found in the user interface as products continually develop.
