Page 1: Instruction Manual
Cameras: HD-IP IC REALTIME SECURITY SOLUTIONS ICIP-D2360: 360 Degree Series IP Camera Instruction Manual... - Page 2 I C R E A L T I M E S E C U R I T Y S O L U T I O N S ICIP-D2360 IP Camera Instruction Manual IC Realtime 3050 N Andrews Ave Ext Pompano Beach, FL 33064 Phone 954.772.5327 •...
-
Page 3: Table Of Contents
T able of Contents 1. Features and Specifications ............... 1 a. Overview ..................1 b. Features .................... 1 c. Specifications ................... 3 d. Dimensions ..................4 2. Camera Installation ..................6 a. General Overview ................6 b. Step by Step Guide ................ 7 c. -
Page 4: Features And Specifications
Architectural and Engineering specifications. 1.a Overview his IC Realtime series product is an excellent situational awareness IP Camera designed for the security field. It adopts an embedded Linux operating system to maintain reliable, 24/7 operation. Utilizing both H.264 video compression and G.711 audio compression technology enables the highest quality of recorded audio/video, while maintaining the lowest bitrate utilization. - Page 5 R E A L T I M E S E C U R I T Y S O L U T I O N S Compression Format H.264 video and G.711 audio enables high quality video recording while maintaining the lowest file sizes possible.
-
Page 6: Specifications
R E A L T I M E S E C U R I T Y S O L U T I O N S 1.c Specifications Model ICIP-D2360 (PAL) ICIP-D2360 (NTSC) Camera Image Sensor 1/3” 2Megapixel Exmor CMOS Effective Pixels... -
Page 7: Dimensions
R E A L T I M E S E C U R I T Y S O L U T I O N S Max. User Access 10 users Smart Phone iPhone, iPad, Android, Windows Phone General Power Supply DC12V, PoE(802.3af) Memory Slot Micro SD... - Page 8 R E A L T I M E S E C U R I T Y S O L U T I O N S...
-
Page 9: Camera Installation
S O L U T I O N S Camera Installation This section outlines the proper way to mount and install an ICIP-D2360 series IP Camera. Suitable methods of installing the IPC include either Ceiling installation, Ground Installation, or Wall installations. Note that hardware including screws and anchors are included for the camera installation. -
Page 10: Step By Step Guide
R E A L T I M E S E C U R I T Y S O L U T I O N S 2.b Step by Step Guide Step 1: Remove the cameras dome cover Using the included hex wrench from the accessories kit, unfasten the 3 hex screws on the dome camera enclosure and then remove it. -
Page 11: Sd Card Installation
R E A L T I M E S E C U R I T Y S O L U T I O N S 2.c SD Card Installation Step 1: Disconnect power source from the IP Camera SD cards shall not be installed or removed while the camera is powered and operational. Doing so can potentially result in damage to the camera, and any data stored on the SD card. -
Page 12: Web Operation
(assuming that the IP address does not conflict with another device on your network). Alternatively, you can use our IP Auto Search utility to rapidly find and change IP addresses for IC Realtime series IP Cameras. The utility is available on our support page at : http://www.icrealtime.com/docs/IPAutoSearch.zip... - Page 13 R E A L T I M E S E C U R I T Y S O L U T I O N S Step 2: Follow the on screen prompts to install the plugin When you first access the IP Camera over your web browser, you will be prompted to install the plugin. See below: ...
-
Page 14: Eptz Controls
One of the primary features and functions of this series IP Cameras is its virtual Pan/Tilt/Zoom Capabilities. Read on for a step- by-step guide on how to control the multiple viewing options of the ICIP-D2360. Before Using the EPTZ function, you must configure the Installation Mode. - Page 15 R E A L T I M E S E C U R I T Y S O L U T I O N S Set your desired display mode next. There are 4 options: o 360° 1 Window: This shows the panoramic view of the camera in 1 window, and does not offer EPTZ control.
-
Page 16: Appendices
R E A L T I M E S E C U R I T Y S O L U T I O N S... - Page 17 R E A L T I M E S E C U R I T Y S O L U T I O N S Chapter Appendix: Toxic or Hazard Materials Report Note This user manual is intended for reference only. Slight differences may be found in the user interface as products continually develop.
