Home Smart Switch (with Wireless Extender)
Ÿ
THA-103AC
Quick Installation Guide (1)
Ÿ
THA-103AC (V1) /06.08.2015

Advertisement

loading
Need help?

Need help?

Do you have a question about the THA-103AC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TRENDnet THA-103AC

Summary of Contents for TRENDnet THA-103AC

  • Page 1 Home Smart Switch (with Wireless Extender) Ÿ THA-103AC Quick Installation Guide (1) Ÿ THA-103AC (V1) /06.08.2015...

  • Page 2: Before You Start

    1. Before You Start Package Contents Ÿ THA-103AC Ÿ Quick Installation Guide Ÿ CD-ROM (User’s Guide) Minimum Requirements Ÿ Existing Wireless AC or N network Ÿ Mobile device (e.g. Smartphone, Tablet) with Android (version 2.3 or higher) or iOS (version 6.1 or higher)
  • Page 3 2. WPS Setup with iOS Device 1. For the initial installation, plug the THA-103AC into a power outlet near your router or access point. Toggle the power switch down to the “On” position, and wait 30 seconds while the unit boots up.
  • Page 4 3. Press and hold the WPS button on the THA-103AC. To connect to a 2.4GHz network, press and hold the button for three seconds and the WPS LED will flash. To connect to a 5GHz network, press and hold the button for seven seconds, the WiFi LED will flash.
  • Page 5 7. Tap the Add (+) icon 8. Click LAN Search.
  • Page 6 9. Select the THA-103AC smart switch. 10. Enter the default password: admin. 11. Tap Done to save the changes.
  • Page 7 Blue ON Red OFF 14. Wireless extender’s setup is also finished. The THA-103AC can be moved to its final location. To project the strongest signal from the built-in wireless extender, put the unit in an area where your mobile device has at minimum three signal bars...
  • Page 8 It is recommended that you change your password to ensure your device is secure. To change the password, open the TRENDnet Smart Home app, and locate your device. Click on the Device Settings icon, then select Advanced Settings. It is also recommended that you change your wireless passwords.
  • Page 9 1. To project the strongest signal from the built-in wireless extender, put the THA-103AC in an area where your mobile device has at least three signal bars from your wireless network. Toggle the power switch to the “On” position, and wait 30 seconds while the unit boots up.
  • Page 10 3. Enable the Wi-Fi settings on your iOS mobile device, and connect to the THA-103AC. 4. Enter the wireless password and tap Join. The default password is password. 5. Open the TRENDnet Smart Home app. 6. Tap the Add (+) icon...
  • Page 11 7. Tap LAN Search. 8. Select the THA-103AC smart switch.
  • Page 12 9. Enter the default device password: admin 10. Tap Done to save your changes. 11. Tap the Device Settings icon.
  • Page 13 12. Tap Advanced Setting. 13. Tap WiFi Setting then tap WiFi.
  • Page 14 14. Select your wireless network. The THA-103AC is capable of extending both 2.4GHz and 5GHz networks. If your router supports dual-band networking, you will have to choose which network to connect with the unit. 15. Enter your network's WiFi password and tap OK.
  • Page 15 It is recommended that you change your password to ensure your device is secure. To change the password, open the TRENDnet Smart Home app, and locate your device. Click on the Device Settings icon, then select Advanced Settings. It is also recommended that you change your wireless passwords.
  • Page 16 Device, or Section 3, Manual Setup with iOS Mobile Device. 1. For the initial installation, plug in the THA-103AC into a power outlet near your router or access point. Toggle the power switch down to the “On” position, and wait 30 seconds while the unit boots up.
  • Page 17 3. Press and hold the WPS button on the THA-103AC. To connect to a 2.4GHz network, press and hold the button for three seconds and the WPS LED will flash. To connect to a 5GHz network, press and hold the button for seven seconds, the WiFi LED will flash.
  • Page 18 7. Tap the Add (+) icon. 8. Tap LAN Search.
  • Page 19 9. Select the THA-103AC smart switch. 10. Enter the default password: admin.
  • Page 20 11. Press the Add (+) icon. 12. Select the THA-103AC smart switch.
  • Page 21 Blue ON Red OFF 14. Wireless extender's setup is also finished. The THA-103AC can be moved to its final location. To project the strongest signal from the built-in wireless extender, put the unit in an area where your mobile device has at least three signal bars from your wireless network.
  • Page 22 1. To project the strongest signal from the built-in wireless extender, put the THA-103AC in an area where your mobile device has at least three signal bars from your wireless network. Toggle the power switch to the “On” position, and wait 30 seconds while the unit boots up.
  • Page 23 4. Enter the wireless password and tap OK. The default password is password. 5. Open the TRENDnet Smart Home app.
  • Page 24 6. Tap the Add (+) icon.
  • Page 25 7. Tap LAN Search. 8. Select the THA-103AC smart switch.
  • Page 26 9. Enter the default device password: admin 10. Tap the Add (+) icon.
  • Page 27 11. Tap the Right Arrow icon. 12. Tap Advanced.
  • Page 28 13. Tap Loading. 14. Select your wireless network. The THA-103AC is capable of extending both 2.4GHz and 5GHz networks. If your router supports dual-band networking, you will have to choose which network to connect with the unit.
  • Page 29 16. Close the app. 17. Connect your mobile device to your wireless network and re-launch the TRENDnet Smart Home app. 18. Tap on the THA-103AC. 19. Tap the power icon to verify if the outlet will turn on/off. Blue ON...
  • Page 30 It is recommended that you change your password to ensure your device is secure. To change the password, open the TRENDnet Smart Home app, and locate your device. Click on the Device Settings icon, then select Advanced Settings.It is also recommended that you change your wireless passwords.
  • Page 31 Model Number: Product Name: Radio Spectrum & Health Title: Director of Technology Name: Sonny Su Signature:...
  • Page 32 à ce produit. Garantía Limitada TRENDnet garantiza sus productos contra defectos en los materiales y mano de obra, bajo uso y servicio normales, durante el siguiente periodo de tiempo a partir de la fecha de compra. Garantía: 3 años (Cuando proceda: 1 año de garantía para componentes de adaptadores de corriente, fuente de...
  • Page 33 THA-103AC Garantia Limitada TRENDnet garante seus produtos contra defeitos em material e mão de obra, sob condições normais de uso e serviço, pelo seguinte tempo a partir da data da compra. Garantia: Garantia limitada de 3 anos. (Quando aplicável: 1 ano de garantia para adaptador de tensão, fonte e componentes de ventoinhas).
  • Page 34 Please recycle where facilities equipo conectado. El adaptador de alimentación debe exist. Check with your Local Authority or operar con voltaje y frecuencia de la energia electrica Retailer for recycling advice. domiciliaria exitente en el pais o zona de instalación. THA-103AC(V1) /06.08.2015...
