1 Device Structure

1.1 Structure Components

Note:
The following figure is for reference only, which is used to know the components and cable port
function.
There are differences about structure components and cables between different models, please refer
to the actual object for more details.
You can refer to the following figure for component structure. See Figure 1-1.
Please refer to the following sheet for detailed information.
Component
1
2
Port
Port 3
Port 4

1.2 Framework and Dimension

The figures are for reference only, which are used to know the device dimension. See Figure1-2. The
unit is mm.
Figure 1-1 Component structure
Component Name
Dome module
Dome enclosure
Sheet 1-1
Port Name
Network port
Power port
Sheet 1-2
