Viking Installation Guide
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information,
call 1-888-VIKING1 (845-4641)
or visit the Viking Web site at
vikingrange.com
Professional & Designer 200/325/450 Series
Built-In Dishwashers
F20408F EN
(111109J)
Advertisement
Table of Contents
Related Manuals for Viking Professional & Designer 200 series
Summary of Contents for Viking Professional & Designer 200 series
- Page 1 Viking Installation Guide Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-VIKING1 (845-4641) or visit the Viking Web site at vikingrange.com Professional & Designer 200/325/450 Series Built-In Dishwashers F20408F EN (111109J)
-
Page 2: Table Of Contents
Table of Contents IMPORTANT– Please Read and Follow! • Before beginning–please read these • Please ensure that this product is properly instructions completely and carefully. grounded. • Do not remove permanently affixed labels, • The installer should leave these Warnings & Important Information ______________________________________ 3 warnings, or rating plates from the instructions with the consumer who should Dimensions &... - Page 3 • The required use of a GFI is normally related to the location of a receptacle with respect to any significant sources of water or moisture. • Viking Range Corporation will NOT warranty any problems resulting from GFI outlets which are not installed properly or do not meet the requirements below.
-
Page 4: Dimensions & Cutout Dimensions
Dimensions & Cutout Dimensions Specifications Professional Series 26-3/8” 26-3/8” Built-In Dishwasher (67.0 cm) (67.0 cm) 23-3/4” 23-1/8” Description 200/325/450 Models (60.3 cm) (59.0 cm) Overall width 23-7/8” (60.6 cm) Overall height from floor 33-7/8” (86.0 cm) min. 2-5/8” 3-3/16” 35” (89.0 cm) max. (6.7 cm) (8.1 cm) Overall depth from rear–Professional... -
Page 5: Custom Door Panel Specifications
Custom Door Panel (Installation Option) (Specifications for DFB Models - 200/450 Models) Have the overlay panel constructed per dimensions. The panel thickness MAY NOT exceed 5/8” (1.6 cm) for flush installation in most cabinets. Ensure that the design, construction, 11-17/32" 5-7/8"... -
Page 6: General Information
General Information General Information • Read these instructions carefully and • For service convenience, a shut-off valve Electrical Connections 3. The edges of the opening mentioned in completely before installing the dishwasher. (not supplied) should be installed in the Item (2) should, if the partition is wood, Grounding Instructions The installation should be carried out by a supply line in a readily accessible location... -
Page 7: Hardwire Conduit Option
Hardwire Conduit Option Trim Installation Options (not available on all units) To install dishwasher without trim, remove the 6 screws and washers (3 per side) and remove trim. To attach wiper gasket to dishwasher, pull protective film off adhesive back on wiper gaskets and apply to leading edge of dishwasher frame. - Page 8 Trim Installation Options (cont’d.) Trim Installation Options (cont’d.) (not available on all units) (not available on all units) Dishwasher will ship with trim installed for panel flush install. If needed, To install dishwasher cabinet flush with trim, remove the 6 screws and washers (3 attach wiper gasket by pulling protective film off adhesive back on wiper per side) holding side trim on.
-
Page 9: Counter Balance Spring Adjustment
Counter Balance Spring Adjustment - If Necessary Installation Procedure Increase tension Decrease tension Disconnect cable from hook. Set counter balance spring connector in appropriate location. Using tie strap attached to dishwasher, band water line, Carefully lay dishwasher on its back and attach the kick plate brackets. - Page 10 Installation Procedure (cont’d.) Installation Procedure (cont’d.) Front Panel Attached Minimum 20” (50.8 cm) from floor Front Panel Removed Attach screws through trim pieces Install High Loop Clip, which is provided, a minimum of into cabinets. 20” (50.8 cm) from the floor. Remove front panel to access the front leveling legs.
-
Page 11: Performance Checklist
Installation Procedure (cont’d.) Performance Checklist Air Gap Air Gap Testing for Leaks Unit Reset • If the unit should need to be reset for any A qualified installer should carry out the reason, push and hold the “START” button following checks: for 4 seconds. -
Page 12: Service & Registration
All servicing should be referred to a qualified technician. Contact Viking Range Corporation, 1-888-VIKING1 (845-4641), for the nearest service parts distributor in your area or write to:...
