ASSEMBLY& OPERATING INSTRUCTIONS
Important: Read these instructions for use carefully so as to familiarize yourself with the
appliance before using your charcoal kettle grill. Keep these instructions for future reference
Manufactured in China· Distributed by Mega Group · PO Box 15, Woodlands, 0027, South Africa· Tel: +27(0)12 802 1515
f
WARNING
d
FOR OUTDOOR USE ONLY
WARNING
To reduce the risk of fire burn hazard or other injury, read the manual carefully and
completely before using your charcoal kettle.
www.megamaster.co.za
.
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Megamaster 570 Elite
Summary of Contents for Megamaster 570 Elite
- Page 1 Important: Read these instructions for use carefully so as to familiarize yourself with the appliance before using your charcoal kettle grill. Keep these instructions for future reference www.megamaster.co.za Manufactured in China· Distributed by Mega Group · PO Box 15, Woodlands, 0027, South Africa· Tel: +27(0)12 802 1515...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions Installation Final Check List Package Content List Operating Instructions 17-20 Explode View Care and Maintenance Part List Trouble Shooting Hardware Contents Warranty Information Assembly Instructions 9-15 Safety Instructions Please read the following instructions carefully before attempting to assemble,operate or install the product.Failure to follow these instructions may result in serious bodily injury and/or property damage. -
Page 3: Safety Instructions
Safety Instructions 1. The charcoal kettle must never be used indoors or for heating purposes. 2. Do not repair or replace any part of the charcoal kettle unless specifically recommended in this manual. All other service should be referred to a qualified technician. This charcoal kettle is not intended to be installed in or on recreational vehicles or boats. -
Page 4: Package Content List
Package Content List Bowl ---1pc Leg cap, top ---3pcs Top leg ---3pcs Bottom leg C---1pc Bottom leg B ---1pc Bottom leg A ---1pc Wheel ---2pcs Cart bottom grate ---1pcs Wheel cap ---2pcs Lid handle assembly ---1pc... - Page 5 Package Content List Bowl vent assembly ---1pc Ash catcher ---1pc Charcoal grate ---1pc Cooking grate ---1pc Lid assembly ---1pc Temperature gauge ---1pc Lid handle decorative sheet Lid hook ---1pc ---1pc Bowl handle assembly---1pc Heat shield piece---1pc...
-
Page 6: Explode View
Parts Diagram... -
Page 7: Part List
Part List Warranty Part(Descreption) coverage(year) Lid handle assembly Mica plate Lid handle decorative sheet Heat shield piece Lid damper Temperature gauge Lid hook Hinged cooking grate Cooking grate Charcoal grate Bowl handle assembly Cooking grate support bracket Bowl Bowl pad Leg cap, top Top leg assembly Bottom leg C... -
Page 8: Hardware Contents
Tools Needed Hardware package list Truss head screw Truss Head Screw Nut M6 Axle Nut M5x 16mm M6x 15mm Flat Washer Flat Washer Teflon Washer Heat Insulating Spacer Wheel Axle... -
Page 9: Assembly Instructions
Assembly Instructions... -
Page 16: Installation Final Check List
Installation Final Check List 1. The cooking grate and charcoal grate are flat. 2. Ash catcher can not drop to floor. 3. Vents can be turned. 4. Leg spread and stand securely. Your charcoal kettle is ready to use! Charcoal kettle special features A. -
Page 17: Operating Instructions
Operating Instructions Warning: Please read the following instructions carefully before attempting to assemble, operate or install the product. The charcoal kettle becomes extremely hot and can cause burning. Failure to comply with these instructions may result in serious bodily injury. Note: Remove all packaging,including straps,before using the charcoal kettle. - Page 18 Tips and tricks for grilling success Wear Gloves Always wear a barbecue mitt or mitts when using your charcoal grill. Vents, dampers, handles, and the bowl will all get hot during the grilling process, so be sure to keep your hands and forearms protected.
- Page 19 Grilling Methods Grilling with direct heat Grillling with indirect heat Use the direct method for small, tender pieces of Use the indirect method for larger cuts of food that takes less than 20minutes to cook, such meat that require 20minutes or more of grilling time, or for foods so delicate that lHamburgers direct exposure to the heat would dry them...
-
Page 20: Care And Maintenance
If your grill is subject to a particularly harsh environment, you will want to clean the outside more often. Acid rain, chemicals and salt water can cause surface rusting to appear. Megamaster recommends wiping down the outside of your grill with warm soapy water. Follow up with a rinse and thorough drying. -
Page 21: Trouble Shooting
Rust spokes can be cleaned using a good quality grill or stainless steel cleaner, check your local Megamaster retailer for our range of cleaning products. Trouble Shooting Before calling for service If the charcoal kettle does not function properly, use the following check list before contacting your dealer for service. -
Page 22: Warranty Information
Warranty Information This charcoal kettle has one (1) year limited warranty. The warranty period is valid from the date of purchase. Please retain your proof of purchase. This is subject to correct assembly, use, storage and regular maintenance of the product. It is the responsibility of the product owner to safely store and protect the charcoal kettle from the elements. - Page 23 Failure to follow all instructions in this Use & Care Guide may lead to fire or explosion, which could result in property damage, personal injury or death. www.megamaster.co.za Manufactured in China· Distributed by Mega Group · PO Box 15, Woodlands, 0027, South Africa· Tel: +27(0)12 802 1515...
