Range Specifications
DC Current
40A
400A (0 to 150A)
400A (150 to 200A)
400A (200 to 400A)
AC Current
4A (0 to 500mA)
4A (500mA to 4A)
40A
100A (0 to 100A)
400A (100 to 200A)
400A (200 to 400A)
Frequency (Hz)
40Hz to 250Hz
250Hz to 10kHz
All rights reserved including the right of reproduction in whole or in part in any form
Resolution Accuracy (of rdg + digits)
10mA
100mA
100mA
100mA
Resolution 50/60Hz
1mA ±(1.5% + 7d)
1mA ±(1.5% + 3d)
10mA ±(1.5% + 3d)
100mA ±(1.5% + 3d)
100mA ±(2.2% + 3d)
100mA ±(4.0% + 3d)
Resolution Accuracy
0.01 to 0.1Hz ±(0.5% + 2d)
0.1 to 1Hz ±(0.5% + 2d)
Copyright © 2014 FLIR Systems, Inc.
www.extech.com
±(1.0% + 2d)
±(1.0% + 2d)
±(2.2% + 2d)
±(4.0% + 2d)
40Hz - 1kHz
±(2.0% + 7d)
±(2.0% + 4d)
±(2.0% + 4d)
±(2.0% + 4d)
±(2.5% + 4d)
±(5.0% + 4d)
Sensitivity
3.0A
0.3A
6
Overload Protect
400A DC
400A DC
400A DC
400A DC
Overload Protect
400A AC
400A AC
400A AC
500A AC
500A AC
500A AC
Overload Protect
500A AC
500A AC
