Installation and Operation Manual
FOR YOUR SAFETY: This product must be installed and serviced by a professional service
technician, qualified in pool/spa installation. The procedures in this manual must be followed exactly.
Improper installation and/or operation can create dangerous electrical hazards which can cause high
voltages to run through the electrical system, possibly causing death, serious injury or property
damage. Improper installation and/or operation will void the warranty.
HHPlus Series Pumps
(Models PHP & PHPU)
WARNING
ATTENTION INSTALLER:
This manual contains important information about the installation,
operation and safe use of this product. This information should be
given to the owner/operator of this equipment.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jandy HHPlus Series
Summary of Contents for Jandy HHPlus Series
- Page 1 Installation and Operation Manual HHPlus Series Pumps (Models PHP & PHPU) WARNING FOR YOUR SAFETY: This product must be installed and serviced by a professional service technician, qualified in pool/spa installation. The procedures in this manual must be followed exactly.
-
Page 3: Table Of Contents
Installation Size of Suction Pipe......5 SECTION 10. Exploded View and Size of Discharge Pipe......5 Replacement Parts List Installation Tips........6 10.1 Jandy PHP & PHPU Pump Series..14 ® SECTION 5. Electrical Verification and SECTION 11. Pump Curves Installation 11.1 Jandy PHP &... -
Page 4: Safety Information
Pumps are powered by a high voltage electric motor and must be installed by a ® licensed or certified electrician or a qualified swimming pool service technician. 6. Due to the potential risk of fire, electric shock, or injuries to persons, Jandy ® Pumps must be installed in accordance with the National Electric Code, all local electrical and safety codes, and the Occupational Safety and Health Act (OSHA). -
Page 5: General Information Introduction
2.1 Introduction required. This manual contains information for the proper installation, operation and maintenance of Jandy ® 3.2.3 The pump and other circulation equipment HHPlus Pumps. Procedures in this manual must be should be located a minimum of five (5) feet followed exactly. -
Page 6: Installation Tips
(5) feet of the inside walls of the pool, spa, or hot tub. 4.3.6 Always use properly sized valves. Jandy Diverter Valves and Jandy Ball Valves WARNING typically have the best flow capabilities. -
Page 7: Electrical Wiring
Jandy ® Pumps Page 7 5.3 Electrical Wiring If the pump is located below the water level of 5.3.1 The pump motor must be securely and the pool, opening the filter pressure release adequately grounded using the green screw valve will prime the pump with water. -
Page 8: Use And Maintenance
Page 8 SECTION 7. Open the pressure release valve on the filter, and make sure it is clean and ready for operation. Use and Maintenance Turn on the power to the pump. Once all the air 7.1 General Maintenance has been evacuated from the filter, close the The pump will collect any large debris present in pressure release valve. -
Page 9: Troubleshooting
The impeller is what moves Troubleshooting the water and has vanes that can become 8.1.1 Jandy strongly recommends that you call a blocked with debris. See "Blocked Impeller" qualified service technician to perform any (Section 9.1) under the "Specialty Service"... -
Page 10: Speciality Service
If you are not replacing the motor, do not disconnect the electrical wiring. Note: If you are replacing the motor, Jandy Pull the motor and mounting bracket out of the strongly recommends that a qualified service pump body. -
Page 11: Replacing The Impeller
Jandy ® Pumps Page 11 Remove the shaft cover on the back of the Hand tighten the lid to make an air tight seal. Do motor by prying it off with a flat head not use any tools to tighten the lid, hand tighten screwdriver. -
Page 12: Mechanical Seal Replacement
Page 12 9.4 Mechanical Seal Replacement Rubber Gasket Follow steps 1-7 of section 9.2, "Removing the Impeller." Ceramic Seal Remove the ceramic seal from the impeller first, by prying between the ceramic and the rubber gasket working in a circle, then remove the Impeller side of the rubber seal. -
Page 13: Motor Replacement
Jandy ® Pumps Page 13 9.5 Motor Replacement Have a qualified service technician or electrician properly disconnect the electrical wiring at the pump motor. Follow steps 1-7 of section 9.2, "Removing the Impeller." Remove the four (4) bolts holding the mounting bracket to the motor. -
Page 14: Exploded View And
SECTION 10. Exploded View & Replacement Kit Part Numbers To order or purchase parts for Jandy pumps, contact your nearest Jandy dealer. If they cannot supply you with what you need, contact Jandy customer service at 800.227.1442 or send an e-mail message to info@jandy.com. - Page 15 Jandy ® Pumps Page 15 19 (Qty 2) 13 (Qty 2) (Qty 6) 17 (Qty 4) Figure 9. PHP & PHPU Exploded View...
-
Page 16: Pump Curves
Page 16 SECTION 11. Pump Curves 11.1 Jandy™ PHP & PHPU Pump Curves PHP.75/PHPU1.0 PHP1.0/PHPU1.5 PHP1.5/PHPU2.0/PHP1.5-2/PHPU2.0-2* PHP2.0/PHPU2.5/PHP2.0-2/PHPU2.5-2* PHP3.0 Total Discharge Head Feet Flow Rate, GPM * High-speed only... -
Page 17: Jandy ® Php & Phpu Pump Dimensions
Jandy ® Pumps Page 17 SECTION 12. Pump Dimensions 12.1 Jandy PHP & PHPU Pump Dimensions ® MODEL VOLTAGE PIPE CARTON OVERALL LENGTH (A) SIZE WEIGHT Franklin Century PHP.75 115/230 2" 44lbs. 26 " 26½" PHP1.0 115/230 2" 49lbs. 26½"... - Page 18 Page 18 Notes:...
-
Page 20: Limited Warranty
EXCLUSIONS: The liability of Laars and Jandy shall not exceed the repair or replacement of defective parts and does not include any costs for labor to remove and reinstall the defective part, transportation to or from the factory, and any other materials required to make the repair.
