Removal

43. REAR BRAKE CALLIPER

MRT SM
Unscrew the connector using the bolt
(A/F-89).
Then unscrew the 2 bolts (B/F-89) securing
the calliper to the calliper bracket.
MRT
Unscrew the connector using the bolt
(A/F-90).
Next, remove the rear wheel to free the ca-
lliper.
ATTENTION: The copper gaskets should
be renewed and the circuit bled when refitting
the calliper.
ATTENTION: place a container underneath
to collect the brake fluid.

44. REAR BRAKE DISK

* Remove the front wheel.
Unscrew the bolts (A/F-91-92) securing the disk.
A
B
MRT SM
A
F-91
Chassis
MRT SM
A
B
F-89
MRT
A
F-90
MRT
F-92
51
