48
Removal

37. FRONT WHEEL

MRT SM
Unscrew the nut on the left-hand side.
Loosen the 2 shaft securing bolts (A/F-78) lo-
cated on the forks.
Unscrew the wheel shaft and remove it.
MRT
Loosen the wheel shaft securing bolt (A/F-79)
located on the forks.
Unscrew the wheel shaft and remove it.

38. FRONT BRAKE CYLINDER

Disconnect the brake micro-switch terminals.
Unscrew the connector (A/F-80) securing
the pipe to the cylinder.
Then unscrew the bolt and the screw (B/F-
80) and remove the front brake cylinder.
ATTENTION: The copper gaskets should
be renewed and the circuit bled when refit-
ting the brake cylinder.
ATTENTION: Brake fluid is corrosive.
Chassis
A
A
A
MRT SM
F-78
MRT
F-79
B
F-80
