38
Removal

19. GEAR LEVER

Unscrew the securing bolt (A/F-37).
Then pull off the lever, taking care not to
damage the shaft splines.

20. KICK-START LEVER

Unscrew the bolt (A/F-38) and extract the
lever by pulling it off.
ATTENTION: Refitting the lever in a diffe-
rent position to the original may reduce the
travel during kick-starting.

21. REAR BRAKE PEDAL

Unscrew the cotter pin (A/F-39).
Then remove the bolt (B/F-39), the pedal and
the internal spring (C/F-39).
Chassis
A
C
A
B
A
F-37
F-38
F-39
