Exhaust Pipe - RIEJU MRT 50 Chassis Workshop Manual

Removal

10. EXHAUST PIPE

* Remove the rear left-hand fairing and the silencer.
Loosen the clamp (A/F-20) attaching the exhaust pipe to the silencer.
Remove the 2 springs (B/F-21) attaching the exhaust to the engine at the front and the screw
(C/F-21) on the Silentbloc.
Then disconnect the breather pipe (AIS system) (D/F-22) and withdraw the exhaust pipe by
pulling it forwards.
ATTENTION: Before removing the exhaust pipe, make sure it has cooled down.
A
D
C
F-20
F-22
Chassis
B
F-21
33
