- Page 1 HC1100 GN1100 H990 Steaming Hot Water Filtered 98°C water on tap Installation, Care & Use Manual...
- Page 2 If drilling a hole into a stainless steel sink or counter top, you can cut a mounting hole for the tap with a hole saw for stainless steel, or you can use a hole punch. Hole size requirements: – HC1100, a 35mm - 38mm hole is required. – All other models, hole requirement is 32mm - 38mm.
-
Page 3: In This Package
9.5mm White Tubes (2) “Y” Quick Connector Rubber O-Ring 19mm Screws (4) Hex Nut Quick Connector John Guest Fitting Semi-circular HC1100 Hex Tool Filter System (1-2 Supplied) (Australia Only) Mounting Plate 9.5mm White Tubes (2) Rubber O-Ring 19mm Screws (4) -
Page 4: Start Here
Identify locations for the tap, tank center of hole to wall thickness (depth) and filter (if applicable). HC1100 ..100mm ....76mm Check to make sure there is proper clearance (see chart at left) for tap GN1100 ..110mm ....76mm handles to be fully opened. - Page 5 INSTALLING THE T AP - SERIES 1100 HC1100 / GN1100 Unpack steaming hot water tap components. On a firm, flat surface, carefully straighten the copper tubing. Property Damage: Do not pinch or break copper tubing. Do not distort the last 1 inch of tubing.
- Page 6 INSTALLING THE TAP - H990 H990 Unpack steaming hot water tap components. On a firm, flat surface, carefully straighten the copper tubing. Property Damage: Do not pinch or break copper tubing. Do not distort the last 25mm of tubing. H990 Ensure that the black rubber gasket is properly seated into the base of the tap head and will surround the...
- Page 7 MOUNTING THE TANK Select a spot under the sink to mount tank vertically within reach of both Tank must be plumbing and electrical connections. mounted level Tank should be within 400mm or less of to ensure tap water lines and within 760mm or less proper operation.
- Page 8 Filtration standard on HC1100 & GN1100 INSTALLING FILTRATION Optional on H990 Mark hole locations for filter head and bracket in a spot that allows for filter replacement. Drill 3mm starter holes and attach bracket to wall with wood screws, turning until snug.
- Page 9 FINAL WATER CONNECTION UK/IRL AUS/NZ HC1100 / GN1100 At the other end of the white tube from the filter, press on the: (UK/IRL) 9.5mm to 15mm quick-connector and connect to a 15mm water supply. (AUS /NZ) 3/8" to 1/4" bspt John Guest fitting and connect to a female 1/4"...
-
Page 10: Warranty Information
Electric Shock Hazard: Using an ungrounded or improperly connected appliance can result in serious injury or death from electrical shock. This appliance must be earth (grounded). This steaming hot water tap is equipped with a cord that has a grounding conductor and earth ground pin. The plug must be connected to an appropriate outlet that is properly installed and earth (grounded) in accordance with all local codes and ordinances. -
Page 11: Care And Use
CARE AND USE Electric Shock Hazard: To prevent electrical shock, disconnect power before servicing unit. Use only a properly earth (grounded) and polarized electric outlet. ADJUSTING THE THERMOSTAT FILTER GUIDE AND REPLACEMENT approx. 96°C Factory temperature pre-set is 96˚C. Replace filter cartridge when there is an obvious To reset the thermostat to 96°C, decrease in water flow to the tap or if there is an turn the indicator one notch to... -
Page 12: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE WHAT TO DO Water and steam spits • Unit is boiling. • Depress tap lever to release some water from forcefully from spout the tank. May be normal during initial setup. without turning on the tap. •...
