FCC and IC Compliance Statement
Xi5 ASM‑FT PEDAL, INC, WRLS FCC ID ‑ MVU09291
Xi5 ASM‑KEY FOB, TROLLING MOTR FCC ID ‑ MVU09305
ACMA: N2523
IC: 6094A‑09291, 6094A‑09305
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including
interference that may cause undesired operation.
This device complies with FCC Rules. Changes or modifications not
expressly approved by MotorGuide could void the user's authority to
operate the equipment.
The MotorGuide Xi5 trolling motor complies with Industry Canada
RSS‑210 standard. See RSS‑GEN 7.1.5. The term "IC:" before the
certification/registration number only signifies that registration was
performed based on a Declaration of Conformity indicating that Industry
Canada technical specifications were met. The term "IC:" before the
certification/registration number does not imply that Industry Canada
approved the equipment.
EU Compliance Statement
Attwood Corporation hereby declares that the Motorguide Xi5 trolling
motor is in compliance with the essential requirements and other relevant
provisions of the 99/5/EC R&TTE directive.
A copy of the original CE Declaration of Conformity is on our website at
http://www.motorguide.com/support/certifications.

Environmental Compliance Statement

All MotorGuide products that are subject to the 2002/96/EC WEEE
directive are compliant with the WEEE marking requirement. Such
products are marked with the "crossed‑out wheelie bin" WEEE symbol
(shown, below) in accordance with European Standard EN50419.
