Control Panel Overview

1
1. On/Off Button
• To turn the dishwasher on and off.
Power on light
• Illuminates when On/Off button is pressed.
2. Washing Cycle Indicator
• Illuminates when different washing cycle (pre-wash, main wash, rinse and drying) of the selected
programme is in progress.
Pre-wash
Main wash
Rinse
Drying
3. Rinse Aid Refill Warning Light
• Illuminates when the rinse aid dispenser needs refilling.
Salt Refill Warning Light
• Illuminates when the salt reservoir needs refilling.
4. Half Load Button
• Press the button to select the half load washing cycle.
1
Half load indicator light
2
• Illuminates when the half load washing cycle is selected.
5. Programme Control Dial
• Turn the dial to select your required washing programme.
6. Start/Reset Button
• To start or reset the dishwasher.
1
INTENSIVE NORMAL ECONOMY RINSE
2 3
2 3 4 5 6
RAPID
SOAK
PROG 1
2
6
START
1
3 RESET
5
2
4
4 5 6
