Control Panel Overview

1
1. On/Off Button
• To turn the dishwasher on and off.
Power On Light
• Illuminates when On/Off button is pressed.
2. Washing Cycle Indicator
• Illuminates when different washing cycle (pre-wash, main wash, rinse and drying) of the selected
programme is in progress.
Pre-wash
Main wash
Rinse
Drying
3. Rinse Aid Refill Warning Light
• Illuminates when the rinse aid dispenser needs refilling.
Salt Refill Warning Light
• Illuminates when the salt reservoir needs refilling.
4. Programme Control Dial
• Turn the dial to select your required washing programme.
5. Start/Reset Button
• To start or reset the dishwasher.
CDW60W10_IB_110324.indd 11
1 2
STRONG NORMAL ECONOMY RINSE
2 3
3 4 5 6
PROG 1
6
RAPID SOAK
5
2
START
3 RESET
4
4 5
GB-11
