- Page 1 TECHNICAL DATA & SERVICE MANUAL SCDF137C5TAA SCDF101R5TAA Model No. Product Code No. SCDF137C5TAA 39.7128.915 SCDF101R5TAA 39.7128.916 0.8180.524.1 12/2010...
- Page 2 IMPORTANT! • Ground the unit following local electrical codes. • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
Table of Contents Page 1. SPECIFICATIONS 1-1 Unit specifications 1-2 Major Component specifications 1-3 Other Component specifications 2. DIMENSIONAL DATA 2-1 Unit Dimensions 3. REFRIGERANT FLOW DATA 3-1 Refrigerant Flow Diagram Cooling model 3-2 Refrigerant Flow Diagram Heat pump model 4. -
Page 4: Specifications
1. SPECIFICATIONS 1-1 Unit Specifications SCDF101R5TAA SCDF137C5TAA COOLING PERFORMANCES COOLING HEATING 230 V ~ 50 Hz Power Source Voltage Rating 198 - 264 Available Voltage Range 5,60 Running Ampere 1245 1050 Power Input 0,96 0,91 Power Factor 3,21 3,22 3,67 C.O.P. -
Page 5: Major Component Specifications
1-2 Major Component Specifications SCDF137C5TAA SCDF101R5TAA Controller PCB SAC ON-OFF IDU Model Microprocessor Controls 250VAC - 3,15A - T Control Circuit Fuse (F1) 2,54mm - 5 pcs Jumper Setting JP1 … JP5 SAC WREM Remote Control Unit NTC (with Brass Pipe) Thermistor Coil Sensor Resistance at 25°C... -
Page 6: Other Component Specifications
SCDF137C5TAA SCDF101R5TAA UNIT MODEL Condensate Pump PC 95643 Model 230V - 50Hz Rating 12 ± 10% Nominal Input 122 ± 10% Coil Resistance at 20°C Ω Safety Float Switch Model F83161,3 10(4)A - 250VAC Contact Rating Open Float Close Down... -
Page 7: Dimensional Data
2. DIMENSIONAL DATA 2-1 Unit Dimensions SCDF137C5TAA - SCDF101R5TAA... -
Page 8: Refrigerant Flow Data
3. REFRIGERANT FLOW DATA 3-1 Refrigerant Flow Diagram Cooling model 3-2 Refrigerant Flow Diagram Heat pump model... -
Page 9: Electrical Data
4. ELECTRICAL DATA 4-1 Electric Wiring Diagram Cooling model Controller Switch Assy SWITCH Indoor fan motor Indicator assy Compressor motor Thermistor Overload relay Terminal plate Outdoor fan motor Float switch Capacitor Drain Pump Reverse valve 4-2 Electric Wiring Diagram Heat pump model... -
Page 10: Performance Data
Operation characteristics with relative humidity around 50%. SCDF137C5TAA 32 °C 27 °C 21 °C EXTERNAL TEMPERATURE (°C) SCDF101R5TAA 32 °C 27 °C 21 °C EXTERNAL TEMPERATURE (°C) -
Page 11: Functions
6.FUNCTION 6-1 Cool Mode Operation In Cooling Mode, the operation of the compressor (CM), Outdoor Fan (FMO) and Indoor Fan (FMI) are determined by the difference between the room air temperature (RAT) and the set point temperature (SPT) as shown in the graph. NOTES 1. -
Page 12: Heat Mode Operation
6-2 Heat Mode Operation HEAT PUMP MODELS The Heating mode operation is similar to the Cooling mode operation. The CM, FMO and FMI are mainly controlled by the value of (RAT – SPT). In the graph above, the FMI is operating in AUTO speed mode. Therefore, the FMI speed changes automatically according to the (RT - SPT). -
Page 13: Auto(Cool / Heat)Mode Operation
6-3 Auto (cool/heat) Mode Operation HEAT PUMP MODELS In Auto Mode, the unit switches automatically between the Auto Cooling and Auto Heating in order to maintain the room temperature (RAT) at the prescribed set point (SPT). The switching between the two modes is according to the above graph. Refer to the sections 5.1 COOLING MODE and 5.2 HEATING MODE for system operation details. -
Page 14: Dry Mode Operation
6-4 Dry Mode Operation Dry operation remove moisture from indoor air running, in cooling mode, at a low level without reducing the ambient temperature. This is done cycling ON and OFF indoor and outdoor units according to below. ROOM DRY LEVEL TEMP Operation according to COOLING mode ≥... -
Page 15: Forced Mode
6-7 Forced Mode In this mode the system operates (COOLING or HEATING mode – fixed settings) or is switched off by means of the MODE button of the indoor unit control board. The operation modes can be selected pressing the button in a cyclic way (OFF COOL HEAT OFF…). -
Page 16: Protection Operation In Heat Mode
6-9 Protection operations in Heat Mode HEAT PUMP MODELS 5-9.1 Cold draft This feature prevents the supply of cold air forcing the indoor fan to a speed which cannot be changed by the user. As soon as the protection mode is exited speed can be changed manually through the remote controller. - Page 17 6-9.3 Overheat This feature prevents the build up of high pressure in the indoor heat exchanger during heating operation SCDF101R5TAA A (°C) B (°C) C (°C)
-
Page 18: I Feel Function
6-10 I FEEL Function As standard configuration the air conditioner operates detecting the room temperature through the sensor equipped in the wireless remote controller (icon I FEEL shown on the display). This feature provides a personalised environment since the temperature can be detected where the remote controller is located. It is possible to de-activate this option pressing the I FEEL button on the remote controller. -
Page 19: Diagnostic
7. DIAGNOSTIC With this feature is possible to have a visual signal that a trouble is occurring. This mode is always active and the signalling is made through the display board LEDS . In case of no troubles the LEDS status follows its normal function. NOTES The troubles are showed according a priority list that is in case of more than one trouble present, is always showed, at first, the one with the highest priority (1... -
Page 20: Jumpers Configuration
8. JUMPERS CONFIGURATION Jumpers are located on the indoor PCB near the MODE button. HEAT PUMP MODELS COOLING MODELS Unit is shipped with jumpers set according to the following table: JUMPER STATUS COOLING STATUS HEAT PUMP open open closed open open open closed... -
Page 21: Maintenance
9. MAINTENANCE Changing the Address of the Air Conditioner In case of more than one air conditioner operating in the same room, it may be necessary to assign an address to each unit in order to avoid operation conflicts. Address is set acting on the dip-switches located on the indoor PCB and on the remote controller. -
Page 22: Troubleshooting
10. TROUBLESHOOTING CHECK BEFORE AND AFTER «TROUBLESHOOTING» (A) Check power supply wiring. • Check the power supply wires are correctly connected. (B) Check power supply. • Check that voltage is in specified range (±10% of the rating). • Check that power is being supplied. •... - Page 23 2 • The unit does not run. C WATER LEVEL ALARM - OPERATION LAMP IS BLINKING. Malfunctioning of the condensate drainanege system. NOTE: In case of emergency the air conditioner can work by draining the condensate from the little pipe into a rather short container. Extract the little pipe and remove the cap.
- Page 24 D UNIT AND COMPRESSOR DO NOT RUN. The unit does not run when air conditioner is in the follwing conditions: • When the room temperature is below the setting temperature. • During the protection modes.
- Page 25 E SOME PARTS OF THE AIR CONDITIONER DO NOT OPERATE.
- Page 26 F AIR CONDITIONER OPERATES, BUT ABNORMALITIES ARE OBSERVED.
- Page 28 G POOR COOLING OR HEATING.
- Page 29 H EXCESSIVE COOLING OR HEATING. I A SENSOR IS DEFECTIVE.
-
Page 30: Checking Electrical Components
11 CHECKING ELETRICAL COMPONENTS 11-1 Measurement of Insulation Resistance The insulation is in good condition if the resistance exceeds 1 MOhm a) Power Supply Wires Clamp the earthed wire of the power supply wires with the lead clip of the insulation resistance tester and measure the resistance by placing a probe on either of the power wires (fig.1). -
Page 31: Checking Continuity Of Fuse On Pcb Assy
11-2 Checking Continuity of fuse on PCB assy Remove PCB assy from electrical component box (fig.5) Then pull out the fuse from PCB assy Check continuity of fuse by the multimeter (fig.6) 11-3 Checking Motor Capacitor Remove the lead wires from the capacitor terminals, and then place a probe on the capacitor terminals as shown in fig.7. - Page 32 R.D. 28 Reyrieux BP 131 - 01601 Trévoux CEDEX France Tél. 04.74.00.92.92 - Fax 04.74.00.42.00 R.C.S. Bourg-en-Bresse B 759 200 728...
